GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your OptiPlex 5000
Micro.
Table 15. GPU—Integrated
Controller
Intel UHD Graphics 710
Intel UHD Graphics 730
Intel UHD Graphics 770

Multiple display support matrix

The following table lists the multiple display support matrix for your OptiPlex 5000 Micro.
Table 16. Optiplex 5000 Micro—Two DP1.4 (HBR2) + optional VGA/HDMI2.0/DP1.4 (HBR3)/Type-C ALT
mode DP1.4 (HBR3)
Description
Intel UHD 710/730/770 Graphics
External display support
Two DisplayPort 1.4 ports
Two DisplayPort 1.4 ports
Two DisplayPort 1.4 ports
Number of
displays
1
2
3
Memory size
Shared system memory
Shared system memory
Shared system memory
Maximum resolution
● On board integrated DP1.4 (4096x2304 @ 60 Hz)
● Option card with VGA (1920x1200 @ 60 Hz)
● Option card with DP1.4 (5120x3200 @ 60 Hz)
● Option card with HDMI 2.0 (4096x2160 @ 60 Hz)
● Option card with Type-C (5120x3200 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + On board
integrated DP1.4(4096x2304 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + Option card
with VGA (1920x1200 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + Option card
with DP1.4 (5120x3200 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + Option card
with HDMI 2.0 (4096x2160 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + Option card
with Type-C (5120x3200 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + On board
integrated DP1.4(4096x2304 @ 60 Hz) + Option card with VGA
(1920x1200 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + On board
integrated DP1.4(4096x2304 @ 60 Hz) + Option card with
DP1.4 (5120x3200 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + On board
integrated DP1.4(4096x2304 @ 60 Hz) + Option card with
HDMI 2.0 (4096x2160 @ 60 Hz)
● On board integrated DP1.4 (4096x2304 @ 60 Hz) + On board
integrated DP1.4 (4096x2304 @ 60 Hz) + Option card with
Type-C (5120x3200 @ 60 Hz)
Specifications of OptiPlex 5000 Micro
Processor
th
12 Generation Intel Pentium
Gold G7400T processor
th
12 Generation Intel Core
i3-12100T, i3-12300T, and
i5-12400T processors
th
12 Generation Intel Core
i5-12500T, i5-12600T, and
i7-12700T processors
