XAPP168 (v1.1) February 8, 2000
Summary
Introduction
© 2000 Xilinx, Inc. All rights reserved. All Xilinx trademarks, registered trademarks, patents, and disclaimers are as listed at
http://www.xilinx.com/legal.htm. All other trademarks and registered trademarks are the property of their respective owners.
XAPP168 (v1.1) February 8, 2000
Getting Started With the MultiLINX™
R
Cable
Author: Carl Carmichael
This application note provides a quick introduction to the MultiLINX cable hardware. Topics
covered are a description of the cable, how to order a MultiLINX system, a list of features, what
the cable may be used for, the current software support, and how to integrate cable access into
a users' board. For more information on the MultiLINX cable and other hardware products from
Xilinx, please refer to the Hardware User's Guide.
The MultiLINX Cable, shown in
Xilinx in 1999. This cable is primarily used for the purpose of downloading configuration and
programming data to Xilinx FPGAs and CPLDs, in a users' target system, from a host
computer.
The MultiLINX cable supports a USB interface which increases communication speeds up to
12 Mbits/s, thus reducing download times by a factor of 120X compared to previous cable
products. The MultiLINX Cable is also outfitted with all the appropriate flying leads for multiple
configuration mode support, as well as supporting multiple readback modes such as
verification, Capture, and the Virtex SelectMAP interface. This allows for quick and easy
functional verification of applications that use Programmable Logic.
Additionally, the MultiLINX cables' internal hardware is upgraded via software. This allows for
future expansion of cable features and software support. Upgrades are completely seamless
and invisible to the user.
Figure
1, is a new peripheral hardware product released by
www.xilinx.com
1-800-255-7778
Application Note: HW-MultiLINX
1

Advertisement

loading

Summary of Contents for Xilinx MultiLINX

  • Page 1 This application note provides a quick introduction to the MultiLINX cable hardware. Topics covered are a description of the cable, how to order a MultiLINX system, a list of features, what the cable may be used for, the current software support, and how to integrate cable access into a users’...
  • Page 2 Obtaining the Alliance and Foundation 2.1i software packages are shipped with a mail-in form to purchase the MultiLINX cable. The MultiLINX cable may also be purchased over the internet, or by credit MultiLINX Cable card orders by contacting the Xilinx Customer Service Hotline.
  • Page 3 SelectMAP interface. The SelectMAP interface uses a byte-wide parallel data bus. The high speed USB connection to the MultiLINX Cable is supported on Windows 98 and 95c platforms. The RS232 serial connection is supported on Windows 95/98/NT and Solaris/HP UNIX platforms.
  • Page 4: Connecting To The Host Computer

    Connecting to The MultiLINX cable pod may be connected to either the RS232 serial cable or the USB cable. Only one cable should be used at a time. However, if both cables are connected the RS232 the Host serial cable will override the USB connection.
  • Page 5 Getting Started With the MultiLINX™ Cable MultiLINX Connectors CS0 (CS) RD (TDO) TRIG CLK2-IN CCLK CLK2-OUT DONE (D/P) RS (RDWR) PROG CLK1-IN INIT RDY/BUSY CLK1-OUT Circuit Board V CC Xilinx Device User I/O: RESET INIT PROG DONE V CC CCLK...
  • Page 6 Getting Started With the MultiLINX™ Cable MultiLINX Connectors CS0 (CS) RD (TDO) TRIG CLK2-IN CCLK CLK2-OUT DONE (D/P) RS (RDWR) PROG CLK1-IN INIT RDY/BUSY CLK1-OUT Circuit Board V CC Xilinx Device User I/O: RESET INIT PROG DONE V CC CCLK...
  • Page 7 Getting Started With the MultiLINX™ Cable MultiLINX Connectors CS0 (CS) RD (TDO) TRIG CLK2-IN CCLK CLK2-OUT DONE (D/P) RS (RDWR) PROG CLK1-IN INIT RDY/BUSY CLK1-OUT Circuit Board INIT BUSY/DOUT PROG WRITE DONE CCLK Xilinx Device V CC V CC V CC V CC V CC V CC Note: Pull-up resistors are 4.7k ohm...
  • Page 8 Getting Started With the MultiLINX™ Cable MultiLINX Connectors CS0 (CS) RD (TDO) TRIG CLK2-IN CCLK CLK2-OUT DONE (D/P) RS (RDWR) PROG CLK1-IN INIT RDY/BUSY CLK1-OUT Circuit Board GCK (x) BUSY/DOUT WRITE User I/O User Logic Filp-flops and Latches, LUTRAMs, and Block RAMs...
  • Page 9 Getting Started With the MultiLINX™ Cable MultiLINX Connectors CS0 (CS) RD (TDO) TRIG CLK2-IN CCLK CLK2-OUT DONE (D/P) RS (RDWR) PROG CLK1-IN INIT RDY/BUSY CLK1-OUT Circuit Board Xilinx Device INIT PROG (See Data Sheet of the Device, if Applicable) Note: Pull-up resistors are 4.7k ohm...
  • Page 10 MultiLINX can communicate with the host computer via an RS232 compatible serial port. A DB9F connector is used for the RS232 port on the MultiLINX Cable. A DB9F to DB9M cable is supplied. Two DB9 to DB25 adapters (M & F) are also supplied for connecting to workstation platforms.
  • Page 11 Notes: Each of MultiLINX Cable’s Flying wires is capable of driving a total capacitive load of 100 pF; Each of MultiLINX Cable’s Flying wires is capable of driving a total pull-up resistance of 500 ohms; Each of MultiLINX Cable’s Flying wires is capable of driving a total pull-down resistance of 5000 ohms.
