2.3
Detaching the arm (for VESA wall
mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1.
Have the front of the monitor face down on a table.
2.
Loosen the screw on the base. (Figure 1)
3.
Remove the base (Figure 2).
4.
Use a screwdriver to remove the screw on the hinge (Figure 3), then remove
the hinge.
(Figure 1)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
ASUS TUF Gaming Monitor VG249QM1A series
(Figure 2)
(Figure 3)
2-3
