User's Manual
Color LCD Monitor
Important
Please read this "User's Manual", and "PRECAUTIONS" (separate
volume) carefully to familiarize yourself with safe and effective
usage.
• See the Setup Guide for monitor installation and connection.
• For the latest product information including the "User's Manual", refer to
our web site:
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo FlexScan S1934
Summary of Contents for Eizo FlexScan S1934
- Page 1 User’s Manual Color LCD Monitor Important Please read this "User’s Manual", and "PRECAUTIONS" (separate volume) carefully to familiarize yourself with safe and effective usage. • See the Setup Guide for monitor installation and connection. • For the latest product information including the "User’s Manual", refer to our web site: www.eizoglobal.com...
-
Page 2: Location Of Caution Statement
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. -
Page 3: About This Product
• The backlight of the LCD panel has a fixed lifetime. Depending on the usage pattern, such as usage for long continuous periods, the lifespan of the backlight may run out sooner, requiring replacement. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. -
Page 4: About The Installation
About This Product • Do not press on the LCD panel surface or edge of the frame strongly, as this may result in display malfunctions, such as moiré patterns, etc. If pressure is continuously applied to the LCD panel surface, the liquid crystal may deteriorate or the LCD panel may be damaged. -
Page 5: Table Of Contents
CONTENTS CONTENTS Location of Caution Statement ................. About This Product ....................About the Usage of This Product ................ About the LCD Panel ..................About the Installation................... Cleaning ......................To Use the Monitor Comfortably ................. 1 Introduction ........................ Features ......................1.1.1 Reduction of Power Consumption ............ - Page 6 CONTENTS Imaging Problems (or Both Digital and Analog) ..........27 Imaging Problems (Analog only) ................. 28 Other Problems ....................28 6 Reference ........................30 Attaching an Optional Monitor Arm ..............30 Connecting Multiple PCs..................32 Specifications ...................... 33 6.3.1 LCD Panel....................33 6.3.2 Video Signals ..................
-
Page 7: Introduction
Introduction | 1 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1.1 Features 1.1.1 Reduction of Power Consumption This product provides a function that automatically adjusts the screen brightness to reduce power consumption . Power Reduction, CO Reduction, and Eco Performance Level can be checked on the "EcoView Settings"... -
Page 8: Controls And Functions
1 | Introduction 1.2 Controls and Functions 1.2.1 Front 1. Ambient light sensor Detects ambient brightness. If you use Auto EcoView, the screen brightness is automatically adjusted according to the ambient brightness (see Auto EcoView [} 13]). 2. Operation switches Displays menus (see Switch Operation Method [} 11]). -
Page 9: Back
Introduction | 1 1.2.2 Back 1. Security lock slot Complies with Kensington's MicroSaver security system. 2. Speakers Outputs audio. 3. Headphone jack Connects to headphones. 4. Cable holder Holds the monitor cables. 5. Stand Adjusts the height and angle (tilt and swivel) of the monitor. The monitor can also be rotated vertically. -
Page 10: Supported Resolutions
1 | Introduction 1.3 Supported Resolutions The monitor supports the following resolutions: ✓: Supported, -: Not supported Resolution Vertical scan DisplayPort DVI-D D-Sub frequency (Hz) 640 x 480 59.940 ✓ ✓ ✓ 640 x 480 60.000 ✓ 720 x 480 59.940 ✓ 720 x 480 60.000 ✓... -
Page 11: Basic Adjustment/Setting
Basic Adjustment/Setting | 2 2 Basic Adjustment/Setting This product enables users to change the brightness according to personal preference or to suit the usage environment, and to reduce power consumption to conserve energy. This chapter describes the basic functions that can be adjusted and set by pressing the switches on the front of the monitor. -
Page 12: Color Modes
2 | Basic Adjustment/Setting By switching the color mode according to the purpose and contents of the display, you can display images in an appropriate manner. 2.3.1 Color Modes Color mode Purpose User1 / User2 Select either of these modes to set a user-defined display mode. sRGB This mode is suitable for matching color reproduction with peripheral devices that support sRGB, such as when printing photos taken using a digital... -
Page 13: Adjusting Brightness
Basic Adjustment/Setting | 2 Note • The power saving level (Power Reduction, CO Reduction, and Eco Performance Level) can be checked on the "EcoView Settings" menu. The more indicators that light up representing the Eco Performance Level, the higher the power saving level attained. –... -
Page 14: Adjusting Volume
2 | Basic Adjustment/Setting 2.6 Adjusting Volume Settings: "0" to "30" The volume of the speakers and headphones can be set individually. Speaker volume Headphone volume (When the headphones are connected) -
Page 15: Advanced Adjustments/Settings
Advanced Adjustments/Settings | 3 3 Advanced Adjustments/Settings This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see Basic Adjustment/Setting [} 11]. 3.1 Basic Operation of the Setting Menu 1. Press any switch (except The operation guide appears. 2. -
Page 16: Setting Menu Functions
3 | Advanced Adjustments/Settings 3.2 Setting Menu Functions 3.2.1 Color The color mode settings can be adjusted according to personal preference. The adjusted settings are saved for each color mode. Functions that can be adjusted differ depending on the color mode. ✓: Adjustable, -: Not adjustable Function Color Mode User1... - Page 17 Advanced Adjustments/Settings | 3 Brightness Settings: "0" – "100" The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Note • If the image is too dark even when the brightness is set to 100, adjust the contrast. Contrast Settings: "0"...
-
Page 18: Signal
3 | Advanced Adjustments/Settings Advanced Settings - Hue Settings: "-50" – "50" Adjusts the hue. Note • Using this function may prevent some color gradations from being able to be displayed. Advanced Settings - Saturation Settings: "-50" – "50" Adjusts the color saturation. Note •... - Page 19 Advanced Adjustments/Settings | 3 • For DisplayPort / DVI input Functions that can be adjusted differ depending on the input signal. ✓: Adjustable, -: Not adjustable Function Input Signal DisplayPort D-SUB Sharpness ✓ ✓ ✓ Sound Source ✓ Analog Adjustment ✓ Sharpness Settings: "-2"...
- Page 20 3 | Advanced Adjustments/Settings Analog Adjustment - Auto Range Adjust The signal output level can be automatically adjusted to enable display of all color gradations (0 to 255). When you select "Auto Range Adjust", a message will appear. Select "Yes". Analog Adjustment - Clock Flickering of vertical lines or part of the screen can be minimized.
-
Page 21: Preferences
Advanced Adjustments/Settings | 3 3.2.3 Preferences The monitor’s settings can be configured to suit the usage environment or personal preference. Menu Rotation Settings: "0°" / "90°" When the monitor is used in a portrait position, the direction of the Setting menu can also be changed. -
Page 22: Languages
3 | Advanced Adjustments/Settings 3.2.4 Languages Settings: "English" / "German" / "French" / "Spanish" / "Italian" / "Swedish" / "Japanese" / "Simplified Chinese" / "Traditional Chinese" The display language for menus and messages can be selected. Attention • The display language of the "Administrator Settings" menu (English) cannot be changed. 3.2.5 Information You can check the monitor information (model name, serial number (S/N), firmware version, usage time) and the input signal information. -
Page 23: Administrator Settings
Administrator Settings | 4 4 Administrator Settings This chapter describes how to configure monitor operation using the "Administrator Settings" menu. 4.1 Basic Operation of the "Administrator Settings" Menu 1. Press to turn off the monitor. 2. While pressing the leftmost switch, press for more than 2 seconds to turn on the monitor. -
Page 24: Functions Of The "Administrator Settings" Menu
• Even when the mouse or keyboard are used, the PC does not return from sleep. On-Screen Logo Settings: "On" / "Off" When the monitor is turned on, the EIZO logo and certification standard logo appears on the screen. When this function is set to "Off", the logos do not appear. - Page 25 Administrator Settings | 4 • "Menu" Locks the switch. • "All" Locks all switches except the power switch.
-
Page 26: Troubleshooting
5 | Troubleshooting 5 Troubleshooting 5.1 No Picture Power indicator does not light up. • Check whether the power cord is connected properly. • Press Power indicator is lighting white. • Increase "Brightness", "Contrast", or "Gain" in the Setting menu (see Color [} 16]). -
Page 27: Imaging Problems (Or Both Digital And Analog)
[} 16]). (The LCD monitor backlight has a limited life span. If the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, try changing the Auto EcoView setting to "On". The monitor... -
Page 28: Imaging Problems (Analog Only)
5 | Troubleshooting 5.3 Imaging Problems (Analog only) Screen is misaligned • Use "Hor. Position" or "Ver. Position" in the Setting menu to adjust the positioning of the screen (see Analog Adjustment - Hor. Position / Ver. Position [} 20]). • If the graphics board's utility has a function to change the position of the image, use that function to adjust the position. - Page 29 Troubleshooting | 5 Power indicator is flashing orange • This issue may occur when a PC is connected to the DisplayPort connector. Use a signal cable recommended by us for the connection. Turn the monitor off and on. Even when the mouse or keyboard are used, the PC does not return from sleep.
-
Page 30: Reference
6 | Reference 6 Reference 6.1 Attaching an Optional Monitor Arm An optional arm (or optional stand) can be attached by removing the stand section. Please refer to our web site for optional arms (or optional stand) that are supported. (www.eizoglobal.com) When attaching an arm or stand, the installable orientations and movement range (tilt angle) are as follows: •... - Page 31 Reference | 6 1. Lay the LCD monitor on a soft cloth spread over a stable and flat surface with the LCD panel surface facing down. 2. Remove the stand. Prepare a screwdriver. Use the screwdriver to remove the screws that secure the unit to the stand. 3.
-
Page 32: Connecting Multiple Pcs
6 | Reference 6.2 Connecting Multiple PCs This product can be connected to multiple PCs and allows you to switch between the connections for display. Connection Examples DisplayPort D-Sub DisplayPort cable DVI cable D-Sub cable (DisplayPort - DisplayPort) (DVI - DVI) (D-Sub - D-Sub) PP200 FD-C39D MD-C87... -
Page 33: Specifications
Reference | 6 6.3 Specifications 6.3.1 LCD Panel Type IPS (Anti-Glare) Backlight Size 19" (48.0 cm) Resolution 1280 dots x 1024 lines Display Size (H x V) 374.8 mm x 299.8 mm Pixel Pitch 0.293 mm x 0.293 mm Display Colors 8-bit colors 16.77 million colors Viewing Angle (H / V, typical) 178˚... -
Page 34: Operating Environmental Requirements
6 | Reference Net Weight (Without Stand) Approx. 3.8 kg Height Adjustment Range 100.0 mm Tilt Up 30˚, down 0˚ Swivel 70˚ Vertical Rotation Right 90˚ 6.3.6 Operating Environmental Requirements Temperature 5 ˚C – 35 ˚C Humidity 20 % – 80 % R.H. (no dew condensation) Air Pressure 540 hPa –... -
Page 35: Appendix
ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. - Page 36 03V60223A1 UM-S1934-2 Copyright © 2022 EIZO Corporation. All rights reserved. 1st Edition – June, 2022...
