Important
Please read PRECAUTIONS, this User's Manual, and the Setup Guide
(separate volume) carefully to familiarize yourself with safe and effective
usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC to using the monitor.
• The latest User's Manual is available for download from our web site:
http://www.eizo.com
Advertisement
Table of Contents
Related Manuals for Eizo FlexScan S1923
Summary of Contents for Eizo FlexScan S1923
-
Page 1: Cover
(separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the Setup Guide for basic information ranging from connection of the monitor to a PC to using the monitor. • The latest User’s Manual is available for download from our web site: http://www.eizo.com... - Page 2 [Location of the Caution Statements]...
- Page 3 EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation.
-
Page 4: Notice For This Monitor
The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. - Page 5 Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. NOTE •...
-
Page 6: Table Of Contents
2-3 Utility Disk ............14 ● Disk contents and software overview ....14 Chapter 5 Reference ......... 26 ● To use ScreenManager Pro for LCD (DDC/CI)/ EIZO ScreenSlicer ..........14 5-1 How to Attach the Optional Arm ...... 26 2-4 Screen Adjustment ..........15 5-2 Power Saving Mode .......... 27 Digital Input ............15 Analog Input ............15 5-3 Specifications ............ -
Page 7: Chapter 1 Features And Overview
Chapter 1 Features and Overview Thank you very much for choosing an EIZO color LCD monitor. 1-1 Features • Applicable to the resolution of 1280 × 1024 • Stereo speakers • Power saving function Suppressing the power consumption* reduces the carbon dioxide emissions. * Reference values: Maximum power consumption: 41W This product is equipped with various power saving functions. -
Page 8: Buttons And Indicators
Turns the power on or off. Power indicator Indicates monitor’s operation status. Blue: Operating Orange: Power saving Off: Power off ScreenManager is an EIZO’s nickname of the Adjustment menu. See “Basic operation of Adjustment menu” (page 11) for how to use. Chapter 1 Features and Overview... - Page 9 Rear Security lock slot Complies with Kensington’s MicroSaver security system. Adjusts the height and angle (tilt and swivel) of the monitor. Stand Power connector Connects the power cord. Input signal connectors Left: DVI-D connector/Right: D-Sub mini 15-pin connector Stereo mini jack Connects the stereo mini jack cable. Covers the monitor cables.
-
Page 10: Functions And Basic Operation
1-3 Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 11 for operation) (for analog signal input only) page 15 Screen Adjustment (Automatic Adjustment) ● To adjust flickering and position [Screen] …………………………… see page 15 ● To adjust color gradation automatically [Range] …………………………… see page 17 • The Adjustment menu and the EcoView menu cannot be displayed at the same time. page 16 Screen Adjustment EcoView menu... - Page 11 [Power Indicator] …………………… see page 20 ● Enabling/Disabling DDC/CI communication [DDC/CI] ………………………… see page 22 Resumption of Default Setting ● Setting EIZO logo display ON/OFF ● To reset all adjustments to the factory default …………………………………… see page 22 settings [Reset] …………………… see page 22 Basic operation of Adjustment menu...
-
Page 12: Chapter 2 Settings And Adjustments
Chapter 2 Settings and Adjustments 2-1 Set a Sync-on-Green Signal When inputting a sync-on-green signal, the [SoG] setting for the monitor must be changed in advance according to the procedure below (for analog signal). (1) Press to turn off the monitor. (2) Press holding down to turn on the monitor. (3) Select “On”... -
Page 13: Setting Resolution
Setting Resolution When you connect the monitor to the PC and find that the resolution is improper, or when you want to change the resolution, follow the procedure below. ● Windows 8 / Windows 7 1. For Windows 8, click the “Desktop” tile on the Start Screen to display the desktop. 2. -
Page 14: Utility Disk
2-3 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. ● Disk contents and software overview The disk includes software programs for adjustment, and User’s Manual. Refer to “Readme.txt” file on the disk for software startup procedures or file access procedures. -
Page 15: Screen Adjustment
17). NOTE Prepare the display pattern for the analog display adjustment. • For details and instructions on opening Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen the “Screen adjustment pattern files”, adjustment pattern files”. refer to the “Readme.txt” file. Chapter 2 Settings and Adjustments... - Page 16 Perform the auto adjustment again with the analog screen adjustment pattern displayed. ● To adjust flickering, screen position, and screen size automatically [Screen] (1) Display Pattern 1 of the “Screen adjustment pattern files” in full screen on the monitor. (2) Choose <Screen> from the <Auto Adjustment> menu, and press The <Screen> menu appears. (3) Select “Execute” with , and press Flickering, screen position, and screen size are corrected by the auto- adjustment function.
- Page 17 ● To correct screen position [Hor. Position], [Ver. Position] NOTE • Since the number of pixels and the (1) Choose <Hor. Position> and or <Ver. Position> from the <Screen> pixel positions are fixed on the LCD menu, and press monitor, only one position is provided to display images correctly. The The <Hor.
-
Page 18: Color Adjustment
2-5 Color Adjustment ● To select the display mode (FineContrast mode) This function allows you to select the best display mode for monitor brightness, etc. FineContrast mode Mode Purpose Custom Available for making desired setting. Allows the brightness to be set lower than possible with EyeCare other modes. Produces a printed paper effect. -
Page 19: To Set/Adjust Color
NOTE Menu Description Adjustment range • Using the “ScreenManager Pro Brightness To adjust the full screen 0 to 100% for LCD (DDC/CI)” allows you to brightness as desired perform the color adjustment by using NOTE the mouse and keyboard of your PC. •... -
Page 20: Turning Off The Monitor Automatically [Eco Timer]
2-6 Turning off the monitor automatically [Eco Timer] This function allows you to switch the setting to turn off the monitor automatically after a specified time has passed in the power saving mode. Adjustable range: Disable, Enable (0, 1, 2, 3, 5, 10, 15, 20, 25, 30, 45 min, 1-5h) (1) Choose <Others>... -
Page 21: Setting Language [Language]
2-10 Setting Language [Language] This function allows you to select a language for the adjustment menu or displaying message. Selectable languages English, German, French, Spanish, Italian, Swedish, Simplified Chinese, Traditional Chinese, Japanese (1) Choose <Language> menu from the Adjustment menu, and press The <Language> menu appears. (2) Choose a language with , and press The setting is completed. -
Page 22: Enabling/Disabling Ddc/Ci Communication
(2) Press holding down to turn on the monitor. The EIZO logo display setting is toggled by performing the operation in step 2. 2-16 Resuming the Default Setting [Reset] Attention • After resetting, you cannot undo the There are two types of Reset. One is to reset the color adjustment only to the operation. -
Page 23: Chapter 3 Connecting Cables
Chapter 3 Connecting Cables 3-1 Connecting Multiple PCs to the Monitor Multiple PCs can be connected to the DVI-D, D-Sub mini 15 pin connector on the back of the monitor to switch the display. Connection examples D-sub mini DVI-D connector 15-pin Connector To PC 2 To PC 1 D-sub mini 15-pin DVI connector Connector Signal cable (Digital) -
Page 24: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. • No-picture problems → See No.1 - No.2. • Imaging problems (digital input) → See No.6 - No.11. • Imaging problems (analog input) → See No.3 - No.11. - Page 25 • Adjust using <Brightness> or <Contrast>. (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, turn on Auto EcoView. (page 21) The monitor detects the environmental brightness to adjust the screen brightness automatically.
-
Page 26: Chapter 5 Reference
Please refer to our web site for the corresponding optional arm (or follow the instructions of their user’s optional stand). manual. http://www.eizo.com • When using another manufacturer’s arm or stand, confirm the following in [Attaching] advance and select one conforming to the VESA standard. -
Page 27: Power Saving Mode
5-2 Power Saving Mode Analog input This monitor complies with the VESA DPMS standard. [Power Saving System] Attention Power Monitor • Unplugging the power cord Indicator completely shuts off power supply to Operating Operating Blue the monitor. Power saving STAND-BY Power saving Orange • Power consumption varies even SUSPENDED when the stereo mini jack cable is connected. -
Page 28: Specifications
5-3 Specifications LCD Panel 19.0-inch (48 cm) TFT color LCD with hard coating, LED backlight Viewing angle: Horizontal 178°, Vertical 178° (CR: 10 or more) Dot Pitch 0.294 mm Horizontal Scan Frequency Analog: 31 - 80 kHz Digital: 31 - 64 kHz Vertical Scan Frequency Analog: 50 - 75 Hz (Non-interlace) Digital: 59 - 61 Hz (VGA Text: 69 - 71 Hz) (Non-interlace) - Page 29 TILT 405 (15.9) 378.4 (14.9) 13.3 (0.52) 13.3 (0.52) 152.5 (6.0) 100 (3.9) 152.5 (6.0) 47.5 (1.87) 205 (8.1) Option List Cleaning Kit EIZO ScreenCleaner For the latest information about the accessories, refer to our web site. http://www.eizo.com Chapter 5 Reference...
-
Page 30: Glossary
5-4 Glossary Clock The analog signal input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog signal is converted to a digital signal for image display. This is called clock adjustment. - Page 31 TMDS (Transition Minimized Differential Signaling) A signal transmission system for digital interface. VESA DPM (Video Electronics Standards Association - Display Power Management) VESA specifications achieve increased energy efficiency for computer monitors. This involves standardization of signals sent from the computer (graphics board). DPM defines the status of signals transmitted between the computer and monitor. Chapter 5 Reference...
-
Page 32: Preset Timing
5-5 Preset Timing The following table shows factory preset video timing (for analog signal only). Attention • Display position may be deviated Frequency depending on the PC connected, Mode Dot clock Polarity Horizontal: kHz which may require screen adjustment Vertical: Hz using Adjustment menu. Horizontal 31.47 Negative •... -
Page 33: Fcc Declaration Of Conformity
Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... -
Page 34: Hinweise Zur Auswahl Des Richtigen Schwenkarms Für Ihren Monitor
Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß... -
Page 35: Limited Warranty
Warranty. EIZO and Distributors will cease to hold or store any parts of the Product upon expiration of seven (7) years after the production of such parts is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards. - Page 36 Rahmen dieser Garantie hinaus hinsichtlich des Produkts keinerlei Haftung oder Verpfl ichtung dem Erstkäufer oder Dritten gegenüber. EIZO und die Vertriebe verpfl ichten sich, Ersatzteile für das Produkt über einen Zeitraum von sieben (7) Jahren nach Einstellung der Produktion der Ersatzteile zu lagern bzw. anzubieten. EIZO und seine Vertriebspartner verpfl ichten sich, bei einer etwaigen Reparatur des Monitors ausschließlich Produkte gemäß...
- Page 37 EIZO et ses Distributeurs cesseront de tenir ou conserver en stock toute pièce de ce Produit après l’expiration de la période de sept (7) ans suivant l’arrêt de la production de telles pièces. Pour réparer le moniteur, EIZO et ses distributeurs utiliseront des pièces de rechange conformes à...
- Page 38 (en lo sucesivo el “Comprador original”) que compró el producto especifi cado en este documento (en lo sucesivo el “Producto”) a EIZO o a sus Distribuidores, que EIZO y sus Distribuidores, a su propio criterio, repararán o sustituirán el Producto de forma gratuita si el Comprador original detecta dentro del periodo de la Garantía (indicado posteriormente) que el Producto no funciona correctamente o que se ha averiado durante el uso normal del mismo de acuerdo con las indicaciones del manual de instrucciones suministrado con el Producto (en lo sucesivo el “Manual del...
- Page 39 GARANZIA LIMITATA EIZO Corporation (a cui si farà riferimento da qui in poi con “EIZO”) ed i Distributori autorizzati da EIZO (a cui si farà riferimento da qui in poi con “Distributori”) garantiscono, secondo i termini di questa garanzia limitata (a cui si farà...
- Page 40 Garantin är endast giltig i de länder där det finns Distributörer. Garantin begränsar inte några av den Ursprunglige köparens lagstadgade rättigheter. Oavsett andra villkor i denna garanti ska inte EIZO Distributörer under några villkor ha något ansvar i något av de fall som beskrivs nedan: (a) När någon bristfällighet hos Produkten kan härledas till att ha uppstått vid frakt, modifiering, ändring, felaktigt...
- Page 41 «Εγγύηση»), στον αρχικό αγοραστή (στο εξής «Αρχικός Αγοραστής») ο οποίος αγόρασε το προϊόν που καθορίζεται στο παρόν έγγραφο (στο εξής «Προϊόν») από την EIZO ή τους Διανομείς, η οποία εξασφαλίζει ότι η EIZO και οι Διανομείς, σύμφωνα με τη διακριτή ευχέρειά τους, είτε θα επισκευάσουν είτε θα αντικαταστήσουν το Προϊόν χωρίς χρέωση εάν ο...
- Page 42 Гарантия действительна только в странах или регионах, где расположены Дистрибуторы. Гарантия не ограничивает никакие законные права Первоначального покупателя. Несмотря на другие условия этой Гарантии EIZO и Дистрибуторы не несут никаких обязательств согласно этой Гарантии в любом из перечисленных ниже случаев: (а) Любые...
- Page 43 本产品的任何部件停产七 (7) 年后 EIZO 和经销商将不再保留或保管任何这类部件 维修显示器时 EIZO 与经销商将使 用符合我方质量控制标准的替换零件 本保证书仅对于设有经销商的国家或地区有效 本保证书并不限定原买方的任何法律权利 无论本保证书的任何其他条款如何规定 对于任何下列情况之一 EIZO 和经销商将不承担本保证书规定责任 (a) 由于运输损害 改装 改动 滥用 误用 意外事故 错误安装 灾害 维护不善和 / 或由除 EIZO 和经销商以外的 第三方进行不适当的修理造成本产品的任何故障 (b) 由于可能发生的技术变更和 / 或调整造成本产品的任何不兼容性 (c) 传感器的任何劣化 (d) 由于诸如液晶显示屏 LCD 和 / 或背灯等消耗品部件的老化造成的任何显示性能低劣 如亮度变化 亮度均一性变化...
-
Page 44: Recycling Information
Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una fi lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizo.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale. - Page 45 Ten produkt po zużyciu powinien być zbierany i przetwarzany zgodnie z krajowymi przepisami dotyczącymi ochrony środowiska. Wyrzucając ten produkt, należy skontaktować się z lokalnym dystrybutorem lub partnerem. Adresy kontaktowe można znaleźć we wskazanej poniżej witrynie internetowej fi rmy EIZO. http://www.eizo.com...
- Page 46 Při likvidaci produktu musí být produkt vyzvednut a recyklován podle zákonů příslušné země, aby nedocházelo k zatěžování životního prostředí. Zbavujete-li se produktu, kontaktujte distributora nebo pobočku ve své zemi. Kontaktní adresy jsou uvedeny na následující webové stránce společnosti EIZO. http://www.eizo.com Ringlussevõtu alane teave...
- Page 47 вашата страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: http://www.eizo.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
-
Page 48: China Measures For Rohs Compliance In Chinarohs
关于电子信息产品污染控制标识 本标识根据「电子信息产品污染控制管理办法」 ，适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在自制造日起算的年限内，不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr（VI） ） （PBB） （PBDE） 印刷电路板 × ○ ○ ○ ○ ○ 机箱 ○ ○ ○ ○ ○ ○ 液晶显示器 × ○ ○ ○... - Page 49 1st Edition-June, 2013 03V24680A1 Copyright © 2013 EIZO Corporation All rights reserved. (U.M-S1923)
