GT SERIES
Multi-Tenant Entry Security
Quick Start Installation Guide
ATTENTION:
This is an abbreviated Installation Manual, addressing wiring and programming of the GT Series. The complete
GT Series Installation Manual is supplied with the GT-BC Bus Control Unit. If installing a digital entry system, the
program for loading names and numbers for each tenant can be downloaded from www.aiphone.net.

Advertisement

Table of Contents
loading

Summary of Contents for Aiphone GT Series

  • Page 1 This is an abbreviated Installation Manual, addressing wiring and programming of the GT Series. The complete GT Series Installation Manual is supplied with the GT-BC Bus Control Unit. If installing a digital entry system, the program for loading names and numbers for each tenant can be downloaded from www.aiphone.net.
  • Page 2: Table Of Contents

    Programming (addressing tenants via dip switch method)....................19 Programming (entering guard station and entrance station information)...............20 Programming (transfer data to other guard/entrance stations)..................21 Programming (uploading to GT-MCX via LAN)......................22 DIP Switch ID Chart...............................23 - 24 2 | GT Series Quick Start Guide...
  • Page 3: Standard System Wiring (Audio Only)

    4-15/16" 1-1/4" Max. wire distance from distribution point to any tenant is 980’. Max. cumulative wire distance is 8200’. Refer to the GT Series Installation Manual for complete wire distance information. WIRE TYPE Homerun Wiring Method GT Standard Configuration Sample...
  • Page 4: Standard System Wiring (Audio/Video)

    Tenant stations shown Strike Lock are the GT-1C7. The GT-1M3 and GT-2C tenant stations can also be used and wired in CN100 the same manner. PS24 Note: GT-2C requires a CN100 separate PS-24 power supply. 4 | GT Series Quick Start Guide...
  • Page 5: Expanded System Wiring

    ( Org ) guard station option connectors and for technical specifications ( Blu ) External Signaling (GT-RY) ( Wht ) for each connection, refer to the GT Series Installation Manual. ( Gry ) Option contact output ( Blk ) 4-15/16"...
  • Page 6: Dip Switch Settings (Entrance And Guard Station Id Settings)

    When using the GT-DMB(-N, -LVN), the settings listed below will be done via the keypad / display while in programming mode. Refer to the GT Series Installation Manual for instructions. Make sure power is removed from the system before making any dip switch changes.
  • Page 7: Programming

    PROGRAMMING: ENTERING TENANT INFORMATION The GT-DMB(-N, -LVN), GT-MKB-N, and modular digital entrance stations must be programmed with the resident’s information before tenant stations can be addressed. The resident’s information can be entered using the keypad or by using the GT Setup Tool software. Programming entrance stations using the GT Setup Tool on Windows Step 1: Open the GT Setup Tool and click the Create new site radio button.
  • Page 8: Addressing Tenants Via Dip Switch Method

    128 64 32 16 8 4 2 1 Step 3: Enter the ID from the correlation table in Step 1 into the Unit Link-ID Setting for each station. Step 4: Click Save , and then Yes . 8 | GT Series Quick Start Guide...
  • Page 9: Entering Guard Station And Entrance Station Information

    PROGRAMMING: ENTERING GUARD STATION AND ENTRANCE STATION INFORMATION Programming Guard/Entrance Information Step 1: Click the + Guard Station , then select the guard station to program. Click Entrance Info, then enter 1 for the Section ID. Enter the Entrance ID (1-16), Entrance #, and Entrance Name (not required). Step 2: Click Guard St Info, then enter 1 for the Section ID.
  • Page 10: Transfer Data To Other Guard Stations And Entrance Stations

    Repeat process to copy Entrance Info and Guard Info. Click Exit when done. Repeat till the Resident information has been copied to all desired stations. Step 4: Click Save , and then Yes . 10 | GT Series Quick Start Guide...
  • Page 11: Uploading To Stations Via Usb

    GT SETUP TOOL FOR ANDROID The Aiphone GT Setup Tool for Android app can be used to create and upload setting files to the GT-DMB(-N, -LVN) and GT-DB-VN entrance stations as well as the GT-MKB-N video guard station. It is recommended to use the GT Support Tool for Windows for the initial setting file creation and loading to the stations, then use the app for downloading and editing the setting file when changes need to be made.
  • Page 12: Editing Settings

    EDITING SETTINGS Step 1 Step 2 Make the necessary edits to the Tap the menu button, then tap Save. downloaded setting file. Step 3 Enter a file name (i.e. Job Name) and tap OK. 12 | GT Series Quick Start Guide...
  • Page 13: Uploading Settings

    GT SETUP TOOL FOR ANDROID: UPLOADING SETTINGS Step 1 Step 2 Step 3 Tap UPLOAD SETTING Select the file to upload, tap the Enter the appropriate passcode BY NFC. appropriate authorization level, then (default: Admin *1111, Manager #2222). tap OK. Ensure that Upload Unit Link-ID settings is checked, then tap OK.
  • Page 14: Programming (Addressing Tenants Via Handshake Method)

    Download the program file to the GT Support Tool from the GT-DB(-V, -VN) audio module with the USB cable provided. Click then select the station to download from and click OK . Step 9: Click to save the file to the computer. 14 | GT Series Quick Start Guide...
  • Page 15 PROGRAMMING: ADDRESSING TENANTS VIA HANDSHAKE METHOD (continued) GT-DMB-N(-LVN) Entrance Station Addressing Step 1: Using the GT Support Tool for Windows, upload the program file to the GT-DMB-N(-LVN) with the then select the station to upload to and click OK . USB cable provided.
  • Page 16: Standard System Wiring With Gt-Mcx

    (GTW-DP) Available in N. America.This can be any Door device that parallels or Strike PQRS PQRS WXYZ WXYZ commons the R1 / R2 connection. (Terminal PS24 strip, punch down block, wire nuts, etc.) 16 | GT Series Quick Start Guide...
  • Page 17: Dip Switch Settings (Gt-Mcx)

    GT-MCX: Network Adaptor The GT-MCX connects a GT system to a network, allowing multiple GT systems to be tied together. Each system now becomes known as a section and requires its own GT-MCX. There are two types of sections, the tenant section and the main section.
  • Page 18: System Programming With Gt-Mcx

    Click the + MCX and then click Resident. Enter a Unit # (required) and a Resident Name (not required). If using the GT-SW, enter the Call Button #. Step 5: , and then Yes . Click Save 18 | GT Series Quick Start Guide...
  • Page 19: Programming (Addressing Tenants Via Dip Switch Method)

    PROGRAMMING: ADDRESSING TENANTS VIA DIP SWITCH METHOD Step 1: Create an ID correlation table for the tenant stations using the binary / SW2 Dip Switch - ID chart. The chart below is for the first 48 stations in a non-expanded or expanded system. Refer to the full chart on pages 23 and 24 for the dip switch settings for an expanded system.
  • Page 20: Programming (Entering Guard Station And Entrance Station Information)

    Click Guard Info. Enter 1 for Section ID, Guard St ID (2-4), Guard #, and Guard Name (not required). The GT-MCX uses Guard ID 1. Step 3: Click Save , and then Yes . 20 | GT Series Quick Start Guide...
  • Page 21: Programming (Transfer Data To Other Guard/Entrance Stations)

    PROGRAMMING: TRANSFER DATA TO OTHER GUARD/ENTRANCE STATIONS Compare and Merge (copy data to other devices in the system) Step 1: Click Compare and Merge Settings to copy data to other entry panels and guard stations. Step 2: In the Comparison-1 column, select the MCX radio button that was programmed. In the Comparison-2 column, select the desired entrance station/guard station that you want to copy the data to.
  • Page 22: Programming (Uploading To Gt-Mcx Via Lan)

    3. Check that the NIC setting for the GT Support Tool is set correctly. Check this under Connection > Network Interface Card: NIC 4. Ensure that you can ping the GT-MCX from your PC. 22 | GT Series Quick Start Guide...
  • Page 23: Dip Switch Id Chart

    DIP Switch ID chart: System without the GT-BCXB-N: Use ID’s S1-S48 System with the GT-BCXB-N: Use ID’s A1-A250 for stations on sub trunk A of GT-BCXB-N Use ID’s B251-B500 for stations on sub trunk B of GT-BCXB-N Dip Switch ID’s Dip Switch ID’s Dip Switch...
  • Page 24 A149 / B399 A174 / B424 A199 / B449 A224 / B474 A249 / B499 A150 / B400 A175 / B425 A200 / B450 A225 / B475 A250 / B500 Aiphone Co., Ltd 24 | GT Series Quick Start Guide www.aiphone.net...
