Extron electronics SMP 300 Series User Manual

Streaming media processor
Hide thumbs Also See for SMP 300 Series:
Table of Contents

Advertisement

Quick Links

User Guide
Streaming AV Product
SMP 300 Series
Streaming Media Processor
68-2238-01 Rev. P
08 22

Advertisement

Table of Contents
loading

Related Manuals for Extron electronics SMP 300 Series

Summary of Contents for Extron electronics SMP 300 Series

  • Page 1 User Guide Streaming AV Product SMP 300 Series Streaming Media Processor 68-2238-01 Rev. P 08 22...
  • Page 2 Safety Instructions...
  • Page 3 Copyright © 2016-2022 Extron. All rights reserved. www.extron.com Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks ( ® ), registered service marks ( ), and trademarks ( ) are the property of RGB Systems, Inc. or Extron (see the current list of trademarks on the Terms of Use page at www.extron.com):...
  • Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Conventions Used in this Guide Notifications The following notifications are used in this guide: ATTENTION: • Risk of property damage. Risque de dommages matériels. • NOTE: A note draws attention to important information. A tip provides a suggestion to make working with the application easier. TIP: Software Commands Commands are written in the fonts shown here:...

  • Page 7: Table Of Contents

    File Management ..........95 Picture Control Menu ........30 Record and Stream Configuration Menu ..33 Add a Network Share ........96 Upload and Download Files Using Input Configuration Menu ......39 an SFTP Client ..........96 SMP 300 Series • Contents...
  • Page 8 Table or Wall Mounting ......... 138 Rack Mounting ..........138 Supported File Types, Drive Formats, Browsers, and Browser Plugins ...... 140 File Formats ..........140 Drive Formats ..........140 Browsers ............. 140 Browser Plugins ........... 140 SMP 300 Series • Contents viii...

  • Page 9: Introduction

    • About the SMP 300 Series The Extron SMP 300 Series is a compact, high performance H.264 recording and streaming processor that provides the ability to record a presentation and output an HDMI signal to a local display, and, if needed, stream the AV content live while recording.
  • Page 10 Planning Preparation Training Evaluation Ethernet Needs Analysis Student Selection Instructor Observation Student Proposal & Estimate Instructor Selection Evaluation Presentations Course Schedule Text Selection Questionnaire Student Evaluations Student Feedback Course Review Figure 2. Typical SMP 352 Application SMP 300 Series • Introduction...

  • Page 11: Pc Requirements

    Extron products. Each LinkLicense can be purchased separately from the SMP and activated as the need arises. LinkLicense upgrades available for the SMP 300 Series include the following: Dual Recording Upgrade — This LinkLicense upgrades an SMP 351 or SMP 351 •...

  • Page 12: Licensed Third-Party Software

    Enables the ability to schedule recordings directly from Panopto. • Enables the unit to stream live media to Panopto using RTMP or RTMPS. For more information on each LinkLicense, see the SMP 300 Series Embedded Web Pages Help File. Licensed Third-party Software The following table lists the licensed third-party software used by the SMP models.
  • Page 13 Licensed Third-party Software Used in the SMP 300 Series Package License Package License freetype GPLv2 Dual FTL/GPLv2 nfs-utils gnupg BSD-2c GPLv2 nginx heirloom-mailx GPLv2 BSD-4c, Bellcore (base64), nmap OpenVision (imap_gssapi), RSA Data Security (md5), Network Working Group (hmac), MPLv1.1 (nss)

  • Page 14: General Product Overview

    General Product Overview Input The SMP 300 Series can accept up to three HDMI inputs and one component or composite video input. The SMP 351 3G-SDI and SMP 352 3G-SDI are identical to the SMP 351 and SMP 352 with the addition of the 3G/HD/SDI input (input 5). All models accept digital audio embedded on HDMI signals or analog audio input via captive screw connectors.

  • Page 15: File Storage

    480 GB internal, solid state storage. View the total storage size for a model in the storage information table found on the Recording Controls embedded web page (see Storage Information in the SMP 300 Series Embedded Web Pages Help File) or by checking the part number (Configuration > System Settings > Unit Identification). From...

  • Page 16: Control Options

    RS-232 via the rear panel Remote captive screw connector, or USB via the front panel Config port. • SMP 300 Series embedded web pages over Ethernet connection. USB mouse and keyboard ports provide direct connection of a keyboard and mouse to •...
  • Page 17 Current, previously recorded, or archived media files can be added to Opencast, making everything accessible from a single point. Opencast ensures recordings with metadata are packaged for playback within the player environment. SMP 300 Series • Introduction...

  • Page 18: Features

    SMP is a cost-effective solution for AV recording and streaming. • Save recordings to internal solid state drive, external USB storage, or a defined network storage directory — Recordings can be saved to pre-defined locations most convenient to users. SMP 300 Series • Introduction...
  • Page 19 Panopto video platform as well as streaming live video using RTMP and RTMPS to Panopto. Basic ad-hoc recording and publishing to Panopto and automating the system operation does not require a LinkLicense, but does require installation of the complimentary FlexOS application framework. SMP 300 Series • Introduction...
  • Page 20 Adjustable recording and streaming bit rates — Select video bit rates from 200 • Kbps to 10 Mbps for video and audio bit rates from 16 Kbps to 384 Kbps based on the viewing application, storage, streaming, or network conditions. SMP 300 Series • Introduction...
  • Page 21 Picture controls for brightness, contrast, signal sampling, and overscan — • Sixteen user memory presets are available for each input to store all image settings. SMP 300 Series • Introduction...
  • Page 22 Internal Extron Everlast power supply — Provides worldwide power compatibility, with high demonstrated reliability and low power consumption for reduced operating cost. • Extron Everlast Power Supply is covered by a 7 year parts and labor warranty. SMP 300 Series • Introduction...

  • Page 23: Installation

    3.5 mm, 5-pole captive screw port for channel A Reset button and LED analog stereo audio input 3 BNC connectors for component or composite RJ-45 Ethernet port for LAN connection video input 3 HDMI input 4 SMP 300 Series • Installation...

  • Page 24: Power Connection

    The default network settings are: IP Address: 192.168.254.254 255.255.0.0 Subnet Mask: Default Gateway: 0.0.0.0 DHCP: NOTE: To connect the SMP 300 Series directly to a computer Ethernet port, use a crossover Ethernet cable (see Connection Options on page 106). SMP 300 Series • Installation...

  • Page 25: Input Connections

    (–). Left Left Ring NO Ground Here Sleeve(s) Sleeve(s) Right Right Do not tin the wires! Ring NO Ground Here Balanced Audio Output Unbalanced Audio Output Figure 6. Audio Output Captive Screw Connector Wiring SMP 300 Series • Installation...
  • Page 26 B dual mono or a mix of both channel A and channel B dual mono. NOTE: The default audio channel is channel A and channel B. When dual mode is enabled, the default output is channel A and channel B dual mono. SMP 300 Series • Installation...

  • Page 27: Rear Panel Reset

    NOTES: • The reset modes listed in the SMP 300 Series Reset Modes table on page 20 close all open IP and Telnet connections and all sockets. The table has details comparing the reset modes and detailing affected configuration settings and user content.
  • Page 28 SMP 300 Series Reset Modes Mode Activation Result Purpose and Notes Hold in the recessed rear The SMP 300 Series reverts to the Use mode 1 to revert to panel Reset button while factory default firmware for a single the factory default firmware applying power to the unit.

  • Page 29: Front Panel Operation

    Disconnecting a USB device while recording to it may result in corrupt or lost • data. • Déconnecter un périphérique USB alors qu’un enregistrement y est effectué, peut engendrer une altération ou une perte de données. SMP 300 Series • Front Panel Operations...
  • Page 30 Press NEXT ( ) to activate it. Press SWAP to switch Channel A and B inputs between the two layout windows. The button illuminates green for 1 second to indicate the input swap. SMP 300 Series • Front Panel Operations...

  • Page 31: Layout Presets (For Composite Mode Only)

    Press LAYOUT PRESET (see figure 9, ) to open the menu on the front panel display Use either ADJUST knob ( ) to cycle through the presets. When the desired layout name appears on the output display, stop. SMP 300 Series • Front Panel Operations...
  • Page 32 NOTE: In order to preserve the aspect ratios of the windows, some layouts can have slightly different spacing at lower resolutions. It is recommended to save custom layouts at the resolution at which they are to be recalled. SMP 300 Series • Front Panel Operations...

  • Page 33: Power Up Procedure

    The default display cycle varies depending on the input video signal and output stream selection. It shows the selected inputs and their resolutions, stream bit rate, and output resolution. During recording, the current length of the recording and time remaining are added to the default cycle. SMP 300 Series • Front Panel Operations...

  • Page 34: Front Panel Menu Operation

    Figure 13. Default Display Cycle for Composite Mode SMP 300 Series • Front Panel Operations...
  • Page 35 Submenu details with configuration and options for each setting are on the following pages. A complete schematic of the menus and submenus is in the reference section (see Front Panel Menu Diagrams starting on page 160). SMP 300 Series • Front Panel Operations...

  • Page 36: Presets Menu

    Encoder presets save the following parameters: ENCODER PRESETS Video Resolution Record Mode Profile Type Video Bit Rate GOP Length Profile Level Frame Rate Preset Name Audio Bit Rate Bit Rate Control IDR Interval Audio Delay SMP 300 Series • Front Panel Operations...
  • Page 37 User presets can be saved on one input rate and recalled on a different input rate. There are 16 user presets per input. User presets save the following parameters (per input): Color Preset name • • • Tint • Aspect ratio Contrast Brightness • • SMP 300 Series • Front Panel Operations...

  • Page 38: Picture Control Menu

    Press to save the Position. the new preset. Within the submenu, use the ADJUST knobs to select Press to continue. and change values as required. Press MENU to exit the submenu. SMP 300 Series • Front Panel Operations...
  • Page 39 The range of settings is dependent on the output resolution. • Rotate the right ( ) ADJUST knob to change the vertical size of the video for the selected input. The range of settings is dependent on the output resolution. SMP 300 Series • Front Panel Operations...
  • Page 40 Rotate the right ( ) ADJUST knob to adjust the tint (appearance of colors) of the video for the selected input. The range of settings is 000 to 127. The default is 064. SMP 300 Series • Front Panel Operations...

  • Page 41: Record And Stream Configuration Menu

    Archive — Provides the highest quality stream but uses the most bandwidth and • resources. The settings also apply to the recordings. • Confidence — Provides a lower quality stream, typically for confidence monitoring. SMP 300 Series • Front Panel Operations...
  • Page 42 Secondary — The archive stream is recorded to the internal drive and the drive connected to one of the USB ports (front, rear, or RCP). Off — Recording is off. • NOTE: If Dual Channel mode is selected, rotate either knob to select Single or Off. SMP 300 Series • Front Panel Operations...
  • Page 43 When that drive is full, the SMP uses the next drive with available space in the priority list (see Start an Ad Hoc Recording on page 61). Figure 20. Recording Media Selection and Limit For more information about recording media selection, please refer to the SMP 300 Series Embedded Web Pages Help File. SMP 300 Series • Front Panel Operations...
  • Page 44 Rotate { to change address. Rotate { to change address. NEXT NEXT NEXT Figure 21. Streaming Submenus The following submenus appear only when the encoder selection is ARCHIVE. Confidence encodes have independent stream settings. SMP 300 Series • Front Panel Operations...
  • Page 45 When the ARCHIVE encoder is selected, an option is provided to output audio and video or video only. Rotate either ADJUST knob to select an output mode (see figure 22 on the next page): AUDIO/VIDEO or VIDEO. SMP 300 Series • Front Panel Operations...
  • Page 46 If the archive and confidence aspect ratios do not match, the source material can appear stretched on the confidence stream. • A custom rate is defined with the web‑based UI. For composite mode, the confidence encode cannot have a higher resolution than • the archive encode. SMP 300 Series • Front Panel Operations...

  • Page 47: Input Configuration Menu

    **Input 5 is only available on the SDI models. Rotate [ to adjust TTL pixel width. Rotate [ to adjust TTL pixel width. Rotate { to adjust phase. Rotate { to adjust phase. SMP 300 Series • Front Panel Operations ASPECT RATIO IN[1] ASPECT RATIO IN[1] <FILL> <FILL>...
  • Page 48 • Rotate the right ( ) ADJUST knob to move the pixel sampling point for the selected input. The range of settings is 000 to 063. The default is 032. SMP 300 Series • Front Panel Operations...
  • Page 49 ADJUST knob to select the desired EDID from the EDID table active input. page 42. IN[1] AUDIO SELECT <LPCM 2CH> Rotate either to select an audio input source for the selected input. SMP 300 Series • Front Panel Operations IN[1] AUDIO LEVEL <0 dB> Rotate either to set the...
  • Page 50 HDTV HDMI 2‑Ch 1080p 50 Hz HDTV HDMI 2‑Ch 1080p 24 Hz HDTV HDMI 2‑Ch 1080p 60 Hz HDTV HDMI 2‑Ch User Loaded Slot 1 User Loaded Slot 2 User Loaded Slot 3 SMP 300 Series • Front Panel Operations...

  • Page 51: Background Recall Menu (For Composite Mode Only)

    Rotate either to select enabled recalls the default sampling settings for the the drive restriction. NEXT detected input rate. RESET <NONE> Rotate either to select reboot or to reset all advanced configurations. NEXT SMP 300 Series • Front Panel Operations...
  • Page 52 (not based solely on H/V frequency). For example, the RGBHV RESET <NONE> 1024x768 @ 60 Hz input lookup table entry can only have a single associated Auto Memory. Rotate either to select reboot or to reset all advanced configurations. NEXT SMP 300 Series • Front Panel Operations...
  • Page 53 NEXT. The selected test pattern is immediately output to the display. The test pattern displays until another pattern is selected, OFF is selected from the Test Pattern drop‑down list, or unit power is recycled. SMP 300 Series • Front Panel Operations...

  • Page 54: Comm Settings (View And Edit) Menu

    Rotate [ to select octet field. Rotate { to change address. NEXT SUBNET 255.255.000.000 Rotate either to change mask. NEXT GATEWAY 000.000.000.000 Rotate [ to select octet field. Rotate { to change address. SMP 300 Series • Front Panel Operations...
  • Page 55 NEXT from the 192.168 192.168 GATEWAY submenu. XXX.XXX 254.254 NOTE: The subnet mask is changed using either Rotate { to change address. Rotate { to change address. ADJUST knob. SMP 300 Series • Front Panel Operations...

  • Page 56: Status Menu

    Press NEXT to return to the STATUS menu. Exit Menu From this submenu, press MENU to return to the PRESETS menu cycle, or press NEXT to exit the menu and return to the default cycle. SMP 300 Series • Front Panel Operations...

  • Page 57: Front Panel Lockout (Executive Modes)

    SMP 300 Series, what they mean, and how they are cleared. NOTE: All active alarms can be manually cleared by an administrator via the web page (see Alarms on page 100). SMP 300 Series • Front Panel Operations...
  • Page 58 USB Overcurrent The offending device is removed from the SMP. A USB port current draw of a connected mouse (keyboard and mouse) or keyboard exceeds the 0.5 A limit of the ports. SMP 300 Series • Front Panel Operations...
  • Page 59 (fail to load). • Successfully reconnect the stream. • V1 or V2 is selected but the unit detects • Manually cleared by the Admin. stream errors (cannot connect to stream). SMP 300 Series • Front Panel Operations...

  • Page 60: Web-Based User Interface

    SMP via a PC on the same network. NOTE: In figure 25, the home page for a standard SMP 300 Series device is shown. If the Horizontal Video Mirroring LinkLicense is purchased, there will be an additional Mirroring LinkLicense tab and Horizontal Video Mirroring Status section.

  • Page 61: Web Browser Requirements

    Configure automatic uploads (publishing) of completed recordings to a designated • server or video publishing system. • Remote control and active monitoring of the SMP. • View the AV content that is being recorded and streamed in a small embedded video window.
  • Page 62 The main user interface opens to the Recording Controls page (see figure 26). Figure 26. SMP 300 Series Main User Interface NOTE: In figure 26, the home page for a standard SMP 300 Series device is shown. If the Horizontal Video Mirroring LinkLicense is purchased, there will be an additional Mirroring LinkLicense tab and Horizontal Video Mirroring Status section displaying the status of the horizontal mirroring of each input.

  • Page 63: Page Overview

    Page Overview The SMP 300 Series pages are organized by function and further organized within those main functions. Click the tabs to open the pages. Tabs The pages in the SMP 300 Series are grouped within five main tabs at the top of the page: Figure 27.
  • Page 64 Pages Within Tabs The Scheduled Events, Configuration, and Troubleshooting tabs each include several pages. To access each page, click the corresponding function within the second tier of tabs (sub-tabs) located below the main tabs near the top of the page (see Configuration >...

  • Page 65: Logging Out And Logging In

    Web Page Idle (Timeout) To conserve resources (memory, bandwidth) on the PC, if the web browser is idle for more than about an hour, the SMP 300 Series web page enters idle mode. During idle mode, status updates and video confidence (preview) display image updates are suspended, and the following message is displayed in front of the page: Idle Communication with the device is being temporarily suspended to conserve...

  • Page 66: Av Controls Panel

    To log in to an SMP 300 Series: Open a web browser. Enter the IP address of the SMP into the address field and navigate to that unit. The Authentication Required (Chrome or Firefox) or Windows Security (Microsoft Edge) login dialog box opens. Enter the appropriate user or administrator user name and corresponding password into the fields.
  • Page 67 Separate preview window — To open the live preview in a separate, larger window, • click the Launch Preview button (see figure 31, on page 58) in the upper right corner of the AV Controls panel. When the separate live preview window opens, preview audio is enabled and the preview window within the panel is disabled.
  • Page 68 Progress bar A progress bar (see figure 34, ) below the recording control buttons is a horizontal bar graph that shows how much recording time has elapsed and, if it is a scheduled session rather than an ad hoc recording, how long the presentation is expected to last.

  • Page 69: Start An Ad Hoc Recording

    To enable the meters, select the Enable Meter checkbox below the meters (see figure 36). Left and right channel indicators display the audio output level (in dBFS) when there is an active audio output. The boxes at the top of the meters are red when audio clipping occurs and black when audio is not clipped.
  • Page 70 If the unit is NOT set to limit the recording destination, recording destination options are • as follows: • auto — The recording is saved to the first available storage location that is not full. The priority is front USB port, rear USB port, internal memory. If a USB drive has more than one logical volume, only the volume with the largest free space for that port in the Recording Destination drop-down list is used to store content.
  • Page 71 Recording Profile and Metadata After selecting the recording destination, a preconfigured, saved recording profile can be selected or metadata can be entered for the ad hoc recording (see figure 39). NOTE: When a recording profile is selected from the drop-down list, the metadata fields are grayed out.

  • Page 72: Recording Controls

    Ad Hoc Recording on page 61 for details). NOTE: In figure 40, the home page for a standard SMP 300 Series device is shown. If the Horizontal Video Mirroring LinkLicense is purchased, there will be an additional Mirroring LinkLicense tab and Horizontal Video Mirroring Status section displaying the status of the horizontal mirroring of each input.
  • Page 73 Storage Information The storage information table (see figure 41) the Stream URL panel (also available in File Management on page 95) displays the names of the available connected storage devices, their locations (internal, USB front panel port, USB rear panel port, USB RCP port), total capacity, and amount of used and available storage space.

  • Page 74: Scheduled Events

    Scheduled Events The Scheduled Events page includes three secondary tabs, Recording Calendar, Schedule Settings (see page 67), and Publish Settings (see page 69), with corresponding pages that allow administrators to create scheduled recordings, publish (upload) them, and review the status of recordings. Recording Calendar The Recording Calendar page lists the currently selected scheduling source, publishing destination, when the schedule was last synchronized, and has a file cleanup schedule.

  • Page 75: Schedule Settings

    Microsoft Exchange Server schedule, and an Opencast Matterhorn Server. NOTE: The SMP 300 Series device has the basic Schedule Settings and Publish Setting tabs while operating with firmware v2.xx (xx = latest version).
  • Page 76 (see figure 45). Scheduling must be set up using this page. Scheduling options are available from the selected FlexOS app. NOTE: The SMP 300 Series device has the Flex OS app options Schedule Settings and Publish Setting tabs while operating with firmware v3.xx (xx = latest version).

  • Page 77: Publish Settings

    (uploading), and to automatically delete internal recording folders after successfully publishing the folders. NOTE: The SMP 300 Series device has the basic Schedule Settings and Publish Setting tabs while operating with firmware v2.xx (xx = latest version).
  • Page 78 Panopto app, the recorded file is automatically set to publish (upload) to the applicable server. NOTE: The SMP 300 Series device has the Flex OS app options Schedule Settings and Publish Setting tabs while operating with firmware v3.xx (xx = latest version).
  • Page 79 Figure 48. Publish Settings Page for Panopto Users Enter the Panopto account user name into the Administrator Username field. Enter the Panopto account password in the Administrator Password field . Enter the Panopto Folder ID in the Default Folder ID field. To locate the Panopto Folder ID number: Log in to your Panopto account in a web browser.

  • Page 80: Configuration

    Configuration The eight pages within the Configuration page contain the core controls needed during initial setup, for upgrading the unit, and restoring a configuration. NOTE: Administrators can view and make changes to all settings. Those logged in as users do not have access to the Configuration tab. Figure 49.

  • Page 81: Configuration Tab Features

    Configuration Tab Features Figure 50. Configuration Tab and Sub-tabs The pages within Configuration include the following (see figure 50): Input/Output Settings (see page 74) — Change the name for each input, select the video format for input 3, select an aspect ratio type, and enable or disable Auto-Image, Auto Memory, HDCP authorization for each input.

  • Page 82: Input/Output Settings

    Input/Output Settings The three expandable panels within Input/Output Settings allow an administrator to select a number of settings for video input, test the output, and select options for audio output format and mute. When using firmware v3.04 or higher, the virtual inputs are available with a fourth panel to configure the additional two virtual inputs.
  • Page 83 These two features can work together depending on the configuration the user chooses. See the table below for more information on the settings. Auto Memory and Auto-Image Features Auto Memory Auto-Image Information "New" signals or rates not previously detected by the device are initially set up using default parameters.
  • Page 84 Changing the Font and Text for the Input Switching On-screen Display If optional fonts are uploaded to the SMP 300 Series, you can select and use one for displaying OSD text instead of the default font. Size and color can be selected for the OSD text.
  • Page 85 Outputting and using a video test pattern NOTE: No input signal is needed when using a test pattern for display device setup. The OSD Configuration panel in the Input/Output Settings page allows selection and immediate output of one of eight internally stored test patterns to the local HDMI preview output from the SMP, as well as to the recording and output stream.
  • Page 86 Setting up the universal OSD test pattern To set up the universal OSD test pattern (for composite mode only): Open the Input/Output Settings page. Expand the OSD Configuration panel at the bottom of the page. Select Universal OSD from the Test Patterns drop-down list. The fields and drop- down menus in the Universal OSD section become accessible.

  • Page 87: Image Settings

    See figure 57 for examples of how the configuration settings (on the left) translate to the universal OSD (on the right). REC1,CPU Usage 56% 00:10:33,20:10:51 OSD, SMP 351,1*4,up*100*full Figure 57. Universal OSD Information Selection and Display Input Switching OSD Select the Display "No Source" OSD to indicate no video input checkbox to remove the check mark and disable this OSD.
  • Page 88 The Image Settings page opens (see figure 60). Figure 60. Image Settings Page This page has a collapsible panel with seven sections (see figure 60): Input Config — Select the input to be configured. NOTE: You must select an input from the Input Config panel in the upper left of this page before you can adjust the image settings or save or recall presets.

  • Page 89: Encoding & Layout

    Selecting SDI-specific Settings For input 5 of an SMP 351 3G-SDI and SMP 352 3G-SDI you can select the quantization range, which sets the black and white level for the RGB data of the SDI input. To set the quantization: Select one of the following options from the Quantization Range drop-down list: Figure 61.
  • Page 90 Encoding Presets Encoding presets are combinations of settings for audio and video encoding. The recording uses the highest quality signal encoding (archive encoding), and the preview (confidence view) displayed within the embedded web pages uses the lowest quality encoding (confidence encoding) of the encoding streams. SMP 351 models support up to two encodes (archive and confidence), one recording, •...
  • Page 91 Streaming Presets Streaming Presets allow the user to quickly switch between various streaming options. There are 32 streaming presets that can be saved or recalled to archive and confidence. Streaming presets save the following parameters: STREAMING PRESETS Preset name Multicast IP/destination (for Multicast only) Streaming method and protocol QoS (for Push streaming only) Stream port...
  • Page 92 • Confidence • Local HDMI preview output The SMP 300 Series has two independent recording options, which can be selected together or independently: • Recording Enabled — Select this checkbox to record a video as an mp4/m4v file. The drop-down list provides two video recording options: Audio + Video and Video Only.
  • Page 93 Changing the Font Used for the Metadata Overlay If optional fonts are uploaded to the SMP, they are available to select for displaying metadata text instead of the default font. NOTES: • The SMP supports TrueType™(.ttf) and OpenType (.otf) fonts. ®...

  • Page 94: Users And Roles

    Users and Roles In the Users and Roles page within Configuration, an administrator can set up both administrator and user level passwords. Passwords are not required, though they are recommended for controlling access to configuration functions. Passwords can be set up only via this page or using SIS commands (see Remote Communication and Control starting on page 106).
  • Page 95 Set both an administrator level password and a user level password — This • allows administrators to log in and manage all aspects of the SMP 300 Series. Users can log in to use just the AV Controls panel and the Recording Controls page. Figure 65.

  • Page 96: Alarms And Traps

    Alarms and Traps In the Alarms and Traps page within Configuration, an administrator can configure e-mail account and communication settings to allow the unit to send notification e-mails. This is also the location for selecting whether to log, display a message about, or send an email about various conditions and errors experienced by the SMP 300 Series.

  • Page 97: System Settings

    System Settings Controls within eight of the twelve panels in the System Settings page are essential during initial setup of the unit. The four other panels contain features used infrequently for updating the unit, restoring a configuration, or limiting access to front panel controls. NOTE: A user must be logged in as an administrator to see or change these settings.
  • Page 98 Setting the Default Recording Media To choose where a recording is saved during its creation: NOTE: Secondary storage mode is not available and cannot be selected if dual channel encoding mode is active. In the System Settings page, click the Recording Media Selection panel bar. Figure 69.
  • Page 99 To save recordings to two locations at once (dual recording mode): NOTE: Secondary storage mode is not available and cannot be selected if dual channel encoding mode is active. Select (check) the Secondary Recording Enabled checkbox (see figure 70, Figure 70. Recording Media Selection - Enable Dual Recording The selection in the Recording Destination: field changes to Internal •...
  • Page 100 To set a recording file size limit: In the System Settings page, click the Recording Limits panel bar. Figure 71. Limit Recording Size Select (check) the Recording File Size Limiter checkbox (see figure 71, Enter a number into the Maximum File Size field or use the Up and Down arrows ( next to the field to select a number.

  • Page 101: Advanced Features

    Advanced Features Page Using an Internal Browser Client, a Keyboard and Mouse to Control the SMP 300 Series Configure the SMP to run a web browser client application for direct control, if a stand-alone computer is not available on site. If enabled, the internal browser provides access to a subset of the Network (IP) Settings configuration pane.
  • Page 102 By default, the local output shows the preview (confidence) image on the connected monitor or display. To switch between viewing the preview and viewing the embedded web pages, press the <Ctrl + Alt + S> keys on the keyboard connected to the SMP 300 Series.

  • Page 103: File Management

    File Management The File Management page contains a directory of files stored in the SMP 300 Series and any connected shared drives on the network, which can be deleted, renamed or locked. It also contains a file upload utility to add new files to the SMP for use as background images. Use this page to connect the SMP to shared network drives and upload or download files from the SMP through an SFTP client.

  • Page 104: Add A Network Share

    NOTES: Recordings stored on the internal drive can be automatically uploaded to a • network server (configured in Configuration > Schedule Settings > Publish Settings). If internal storage space is nearly full, the SMP uses a disc cleanup feature to make room for new recordings. As needed, the unit automatically deletes old recordings that have already been uploaded to a server, starting with the oldest recordings, until there is enough free space on the disk.

  • Page 105: Troubleshooting

    If an administrator username and password are set for the unit, enter those in the appropriate fields in the SFTP client. Log into or connect to the SMP. Use the SFTP client software to copy files (recordings, logs, background images) to and from the internal storage folders on the SMP.

  • Page 106: Status

    Status The Status page within the Troubleshooting page displays factory-defined and user-defined information about the unit. This page contains the unit name, part number, firmware version, MAC address, location description, and related information about the unit. It also displays the current audio bit rate and the video bit rates for all encoding streams. Some of the information in this page can also be found using SIS commands (see Command and Response Tables starting on page 114) or the front panel (see...

  • Page 107: Logs

    Logs The Logs page within Troubleshooting displays a list (log) of alerts and notices for any event set up for a status other than Disabled in the Configuration > Alarms and Traps > Alarm Message panel. All log entries are read-only. The logs can be sorted, filtered, searched, or exported to a comma-separated values (CSV) file.

  • Page 108: Alarms

    Alarms The Alarms tab within Troubleshooting displays a list of alerts for events as determined in Configuration > Alarms and Traps > Alarm Message List. Alarm list entries are read-only. The alarm list can be sorted, filtered, searched, or exported to a comma-separated values (CSV) file.

  • Page 109: Diagnostic Tools

    Diagnostic Tools The Diagnostic Tools page within Troubleshooting provides a convenient way to test network connections using a ping utility, a trace route (tracert) function, and an Nmap network discovery tool. Also, generate a log file to send to Extron support staff to aid in troubleshooting problems with the unit or the system.

  • Page 110: System Resets

    System Resets The System Resets page within Troubleshooting contains options to initiate a unit reboot, delete all stored content and format the internal storage, or perform one of five different types of reset. Some of the reset options offered here can also be performed using SIS commands or the front panel menu.

  • Page 111: Mirroring Linklicense

    Mirroring LinkLicense If the SMP has been upgraded with the Horizontal Video Mirroring LinkLicense, the web UI will have a Mirroring LinkLicense tab. The Mirror LinkLicense page has two panels: Recording Settings, and Horizontal Video Mirroring Settings that are used to configure the SMP for one button recording.

  • Page 112: Flexos Applications

    FlexOS Applications This section provides basic instructions on how to use each supplemental plug-in application (app) available for the SMP 300 Series. When an app is downloaded and installed, a user must have administrator privileges to access the Advanced Features page and to use the applications. The apps are available on the SMP 300 Series product page at www.extron.com.

  • Page 113: Kaltura

    Kaltura This optional application enables scheduling, RTMP streaming, and publishing directly to Kaltura KMC. The Kalutua app requires firmware v3.00 or newer. Scheduling and RTMP/RTMPS streaming to Kaltura KMC are enabled by Enhanced Kaltura Features LinkLicense. iCalendar This optional application enables ingesting periodic schedules from Outlook, Google Calendar, and other shceduing servies.

  • Page 114: Remote Communication And Control

    Connect to a host computer for configuration using SIS commands with DataViewer, available at www.extron.com. To connect the SMP 300 Series to a host computer, download the USB driver, follow the on‑screen instructions, and configure the SMP as required.

  • Page 115: Ethernet (Lan) Port

    RJ-45 Ethernet Connector Pin Assignments To establish a network connection to the SMP: Open a TCP socket to port 23 using the SMP 300 Series IP address. NOTE: If the local system administrators have not changed the value, the factory‑specified default, 192.168.254.254, is the correct value for this field.

  • Page 116: Host-To-Device Communications

    The SMP 300 Series initiates messages under specific conditions. No response is required from the host. The SMP 300 Series initiated messages are listed here. © Copyright 2014-2022, Extron Electronics, SMP 351, Vn.nn, 60– 1324-01 Day, DD MMM YYYY HH:MM:SS © Copyright 2014-2022, Extron Electronics, SMP 351 3G-SDI, Vn.nn, 60–...

  • Page 117: Password Information

    The SIS commands are not case sensitive. The ASCII to Hex conversion table below is for use with the command and response table. ASCII to Hex Conversion Table Space • Figure 94. ASCII to Hex Conversion SMP 300 Series • Remote Communication and Control...
  • Page 118 The parameter is case sensitive, and must use 1 = CVBR capital D or capital L. The response is returned with 2 = CBR leading zeros. X4# = Video bit rate — 200 to 10000 SMP 300 Series • Remote Communication and Control...
  • Page 119 X50@ = Output channel 1 = A (input 1 and 2) 2 = B (input 3, 4, and 5) X50# = Encoding mode 0 = Composite mode 1 = Dual channel mode SMP 300 Series • Remote Communication and Control...
  • Page 120 Horizontal size — 120 to 4096 13 = Internal + USBRear X61# = Vertical size — 64 to 4096 14 = Internal + USBRCP X56# = Encoder Presets — 1 to 32 SMP 300 Series • Remote Communication and Control...
  • Page 121 (default = Not Specified) SNMP public community string, up to 64 characters X62# = (default = public) NOTE: SNMP names and community strings can be up to 64 alphanumeric characters including hyphens, underscores and periods. SMP 300 Series • Remote Communication and Control...

  • Page 122: Command And Response Tables

    ]] after the last license. Query number of Number of users. connected users Query system processor Returns a percentage of total. usage Query system processor Returns a percentage of total. idle SMP 300 Series • Remote Communication and Control...
  • Page 123 <app name>*<ver#>*<enable/disable> Digital I/O*2.08.0013*0 Example: Panopto*1.00.0002*1 Sync Schedule Trigger schedule sync Sync with schedule (return error STRGR TrgrS code if scheduling is off or not supported) Unsolicited response TrgrS Schedule is refreshed. SMP 300 Series • Remote Communication and Control...
  • Page 124 The factory configured passwords for all accounts on this device have been set to the device serial number. In the event of a complete Users and Roles system reset, the passwords convert to the default, which is no password (see on page 86 to change a password). SMP 300 Series • Remote Communication and Control...
  • Page 125 Operate like Telnet (port 23). 0ECHO Echo 0 X( ] View Echo status View the Echo setting ECHO 0 = Disabled/off (default) 1 = Enabled/on (Returns command entered along with response). KEY: = Enable/On or disable/off SMP 300 Series • Remote Communication and Control...
  • Page 126 Disable SNMP access Disable SNMP access. E0SNMP SnmpE*0 X( ] View SNMP state View the SNMP access setting. ESNMP KEY: = Enable/disable 0 = Off or disable (default), 1 = On or enable SMP 300 Series • Remote Communication and Control...
  • Page 127 View DNS server IP View the DNS server IP address. address Default IP address: 192.168.254.254 KEY: = IP Address Default Gateway: 0.0.0.0 Default DNS: 0.0.0.0 X1& = Subnet Mask Default: 255.255.0.0 00-05-A6- = Hardware MAC address SMP 300 Series • Remote Communication and Control...
  • Page 128 Executive mode on 99 * 1X Exe99*1 Executive mode off 99 * 0X Exe99 *0 X( ] Query status 99 * X KEY: = On/off 0 = Disabled/off (default), 1 = Enabled/on SMP 300 Series • Remote Communication and Control...
  • Page 129 0 = Disabled (default), 1 = Enabled Delete Recording Event and Files by DB_ID X59@ X59@] Delete recording event RCDR RcdrZ and file X59@ KEY: = Delete recording by DB_ID Valid DB_ID number (integer) SMP 300 Series • Remote Communication and Control...
  • Page 130 X( ] View video mute status 00 = Unmuted, 01 = Muted 0 = Unmuted (default), 1 = Muted KEY: = Muted/unmuted X50@ = Output channel 01 = A, 02 = B SMP 300 Series • Remote Communication and Control...
  • Page 131 Audio-only Recording Enable audio‑only A1 * 1RCDR RcdrA1 *1 recording Disable audio‑only A1 * 0RCDR RcdrA1 *0 recording X( ] View status A1RCDR 0 = Disabled (default), 1 = Enabled KEY: = On/off SMP 300 Series • Remote Communication and Control...
  • Page 132 = Input number 1 to 5 X50@ = Output channel 1 = Channel A, 2 = Channel B X53) 1 to 32 = Preset Number X53! Up to 16 characters = Preset Name SMP 300 Series • Remote Communication and Control...
  • Page 133 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel only) KEY: 3 = Confidence X51$ Up to 16 characters = Encoder/Streaming preset name X56# 1 to 32 = Encoder presets SMP 300 Series • Remote Communication and Control...
  • Page 134 Set RSTP virtual input * <username> PLYR PlyrV * <username> username X59% View RSTP virtual input PLYR <username> username X59% KEY: = Virtual input 1 = Virtual input 1, 2 = Virtual input 2 SMP 300 Series • Remote Communication and Control...
  • Page 135 3 by one pixel. X60%] View total pixels View total pixels for input 3. 3 TPIX X60% KEY: = Total pixels Up to +512 of the default value for the detected range SMP 300 Series • Remote Communication and Control...
  • Page 136 3 by one pixel. X60^] X60^ View active lines 3 ALIN View the active lines value of input 3. X60^ KEY: = Active lines Up to +256 of the default value for the detected resolution SMP 300 Series • Remote Communication and Control...
  • Page 137 Horizontal centering and horizontal size values are adjusted in multiples of 8. If a value is entered that is not a multiple of 8, the closest NOTE acceptable value is applied and returned. X50@ 01 = A, 02 = B KEY: = Output channel X61@ = Horizontal size 00120 to 04096 (5‑digit response). SMP 300 Series • Remote Communication and Control...
  • Page 138 0 = Disabled (default), 1 = Enabled KEY: = Enable/disable X50) 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel mode only), = Stream selection 3 = Confidence SMP 300 Series • Remote Communication and Control...
  • Page 139 Rcdr X4* View virtual input 1 X4RCDR record status Set virtual input 2 RCDR Rcdr X5* View virtual input 2 X5RCDR record status = Enabled/Disabled 0 = Disabled (default), 1 = Enabled KEY: SMP 300 Series • Remote Communication and Control...
  • Page 140 OMOD Omod Set HDMI output to X6$ ] Query HDMI output OMOD 0 = Channel A full screen, 1 = Channel B full screen, 2 = Confidence layout KEY: = HDMI output SMP 300 Series • Remote Communication and Control...
  • Page 141 E X4* X4* ] Set preview output RATE Rate refresh rate X4* ] View output refresh rate RATE KEY: = Output refresh rate 1 = 60 Hz (default), 2 = 50 Hz SMP 300 Series • Remote Communication and Control...
  • Page 142 0 = No sink/source detected, 1 = HDCP detected, 2 = Sink/source detected but no HDCP = HDCP status X51@ = HDCP notification 0 = Off (mute output to black), 1 = On (green HDCP notification‑screen, default) SMP 300 Series • Remote Communication and Control...
  • Page 143 Set the audio delay to zero to disable it. X56$ X56$ ] Set audio delay ADLY Adly1* X56$ ] View 1 ADLY View audio delay value. X56$ KEY: = Audio delay 000 to 999 ms (default 0 ms, 3‑digit response) SMP 300 Series • Remote Communication and Control...
  • Page 144 .bin file, carrying 128 or 256 bytes of binary data. X6& KEY: = EDID User loaded slots 1, 2, and 4 = EDID number EDID Values on page 137 X50! = Input number 1 to 5 SMP 300 Series • Remote Communication and Control...
  • Page 145 1080p 50 Hz HDTV HDMI 2‑Ch 1080p 24 Hz HDTV HDMI 2‑Ch 1080p 60 Hz HDTV HDMI 2‑Ch User Loaded Slot 1 User Loaded Slot 2 User Loaded Slot 3 * Default SMP 300 Series • Remote Communication and Control...

  • Page 146: Reference Information

    Reference Information This section provides information about: Mounting the SMP 300 Series • • Supported File Types, Drive Formats, Browsers, and Browser Plugins DataViewer • • Streaming Method Overview • Estimating Storage Requirements for a Recording Front Panel Menu Diagrams • •...
  • Page 147 UL Rack Mounting Guidelines The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the SMP 300 Series in a rack. CAUTION: • Elevated operating ambient temperature — If the unit installed in a closed or multi‑unit rack assembly, the operating ambient temperature of the rack environment can be greater than room ambient temperature.

  • Page 148: Supported File Types, Drive Formats, Browsers, And Browser Plugins

    Supported File Types, Drive Formats, Browsers, and Browser Plugins File Formats The SMP 300 Series creates *.m4v and mp4 video and m4a audio files, and *.jpg thumbnail and chapter marker images. They use still image files for background material. Optional fonts can be used for on‑screen displays.

  • Page 149: Dataviewer

    DataViewer DataViewer is an enhanced terminal emulation program that facilitates analysis of RS‑232, USB, and TCP/IP communication with Extron devices. The software allows users to send commands to a device and view the responses in ASCII or hexadecimal format. Command and response logs can be saved in text or HTML format.

  • Page 150: What Is An Ip Address

    Sending commands using a TCP/IP connection Configure the network settings of a control PC to connect it to the same network as the SMP 300 Series. Connect the control PC to the network with an RJ‑45 cable. Start the DataViewer program (see Start the DataViewer program on page 141) and follow the steps to connect to the SMP 300 Series via TCP/IP.

  • Page 151: Private And Public Address Ranges

    The parts of the address used to identify the network and host. • The most common IP address classes are: Class Valid Address Range Identifier Arrangement Class A NNN.HHH.HHH.HHH 0.0.0.1 to 127.255.255.254 Class B NNN.NNN.HHH.HHH 128.0.0.1 through 191.255.255.254 Class C NNN.NNN.NNN.HHH 192.0.0.1 through 223.255.255.254 NOTES:...

  • Page 152: Port Number

    Port Number A port number is combined with the IP address to create an application‑specific or process‑specific address. The port number can uniquely identify an application or process on a computer and thereby enable the computer to share a single Ethernet connection for multiple requirements.

  • Page 153: Using The Ping Utility To Test Communications

    The table below shows an example of an invalid class C addressing scheme. Device IP Address Subnet Mask Device 1 208.132.180.41 255.255.255.0 Device 2 255.255.255.0 192.157.180.42 Device 3 208.132.180.41 255.255.255.0 Assuming the IP address for device 1 is valid, the IP address for device 2 is invalid because the network identifier for each address must begin with 208.132.180.xxx.

  • Page 154: Multicast Ip Addressing For Multiple Smp 300 Series Installations

    SMP 300 Series. For most applications, the multicast address should use 239 as the first octet and should be unique for each SMP 300 Series. The port number can remain at the default (12340) as shown in the next table.
  • Page 155 SMP 300 Series waits for viewing devices to request the stream before broadcasting. Streaming Streaming Protocol Protocol Viewing SMP 300 Series NETWORK device (encoder) SMP 300 Series sends data Streaming Protocol Viewing to a multicast group. device Streaming Protocol Viewing device Streaming...
  • Page 156 SMP 300 Series waits for an individual viewing device to request the stream before broadcasting. 1 to n Device 1 Viewing SMP 300 Series NETWORK device (encoder) SMP 300 Series sends data to Device 2 Viewing specified devices. device Device 3 Viewing device Device n...

  • Page 157: Streaming Playback Methods

    (pull streaming). Push Streaming Viewers select an active stream from SMP 300 Series. Stream Stream Viewing SMP 300 Series...
  • Page 158 Push Stream and Pull Stream Playback URLs To verify a running stream, use the templates below to place the stream into the VLC "Open Network Stream" dialog (see step 5 of Playing a Pull Stream Using VLC Media Player on page 153). Substitute the SMP IP address for <SMP35x_IP>. Substitute the destination IP address and port number for <DESTINATION_IP>:DESTINATION_PORT.

  • Page 159: Streaming Capabilities And System Scalability

    NOTES: <SMP35x_IP> is the IP address of the SMP 300 Series. • • For push URLs, the Destination Port is the lowest port in the Port Range set from the web page. UDP://@:DESTINATION_PORT default is UDP://@:12340. • Some dependencies may apply with certain versions of VLC. •...
  • Page 160 Available Multicast Streams The SMP 300 Series uses the IGMP multicast protocol to push or pull streams. The IGMP multicast protocol provides increased bandwidth efficiency because the SMP 300 Series only sends data when a connection is made by the user. All network switches and routing equipment must be properly configured to support IGMP snooping and IGMP query to avoid flooding all endpoints with unnecessary streaming traffic.

  • Page 161: Playing A Pull Stream Using Vlc Media Player

    Use the following procedure to play and view an SMP 300 Series stream using the VLC media player. If you know the stream URL, go to step 5. Otherwise, to obtain the stream URL, access the web‑based user interface of the SMP 300 Series (see Accessing the Web-Based User Interface on page 53)
  • Page 162 The Open Network Media dialog box opens. Using the stream URL that was noted in step 2 on the previous page (rtsp://192.168.13.1/extron1), enter it into the Please enter a network URL: field (see figure 102, Figure 102. Enter Stream URL Information and Play Click Play ( ).

  • Page 163: Playing A Push Stream Using Stream Announcement Protocol (Sap)

    Playing a Push Stream Using Stream Announcement Protocol (SAP) In order to play a push stream, the VLC player uses SAP to identify streams: Open VLC. From the View menu, select Playlist (see figure 103). Figure 103. VLC Playlist From the left menu column, select Local Network (see figure 104, Select Network streams (SAP) ( Figure 104.
  • Page 164 VLC populates the playlist with all streams that contain SAP information. If a folder is shown, open it to view the SAP streams inside (see figure 105, Figure 105. VLC - Select a Stream Either double‑click the desired stream to begin playback, or single‑click, then use the VLC player controls at the bottom of the window to view and control the stream.

  • Page 165: Playing A Pull Stream Using Quicktime Media Player

    Playing a Pull Stream Using QuickTime Media Player Use the following procedure to playback and view SMP 300 Series streams on the QuickTime player program. If the stream URL is known, go to step 4. Otherwise, to obtain the stream URL, access the web‑based user interface of the SMP 300 Series (see Web-Based User Interface starting on page 52).
  • Page 166 The Open URL dialog opens (see figure 108). In the Enter an Internet URL to open field, enter the stream URL that was noted in step 3 ( Enter an Internet URL to open: rtsp://192.168.13.1/extron1 Figure 108. Enter Stream URL Information Click OK ( ).

  • Page 167: Estimating Storage Requirements For A Recording

    In some cases they can be higher. To estimate storage per recording hour: Find the SMP 300 Series video bit rate and audio bit rate, which are in kbps (kilobits per second).

  • Page 168: Front Panel Menu Diagrams

    Front Panel Menu Diagrams (For Composite mode only) PICTURE RECORD/STREAM INPUT BACKGROUND ADVANCED VIEW COMM MENU MENU MENU MENU MENU MENU MENU STATUS PRESETS SETTINGS CONTROL CONFIGURATION CONFIGURATION RECALL CONFIGURATION Press and hold NEXT NEXT NEXT NEXT NEXT NEXT NEXT INPUT 5 + NEXT for 3 seconds.

  • Page 169: Front Panel Menu Diagrams (Record/Stream Configuration)

    Front Panel Menu Diagrams (Record/Stream Configuration) RECORD/STREAM Menu CONFIGURATION NEXT ENCODER ENCODER <ARCHIVE> <CONFIDENCE> Rotate either to Rotate either to select encoder select encoder NEXT ENCODER MODE ENCODER MODE STREAMING <DUAL> <COMPOSITE> <ON> Rotate either to Rotate either to select mode. Rotate right for Dual mode. toggle streaming NEXT NEXT...

  • Page 170: Glossary

    Advanced Audio Coding (AAC) — A standardized compression and encoding scheme for lossy (low quality) digital audio. Higher bit rates provide higher quality. Part of the MPEG‑ 2 and MPEG‑4 specifications. The SMP 300 Series supports AAC‑LC (MPEG‑2 part 7, MPEG‑4 part 3, sub‑part 4 and part 14, MP4 audio).
  • Page 171 (2) Compressor/decompressor: Codecs can be implemented in software, hardware, or a combination of both. Composite encoding mode — The SMP 300 Series mode that signals from channels A and B are combined into one archive stream (forming a single recording). This is the only mode available in the SMP 351 and SMP 351 3G‑SDI.
  • Page 172 Domain Name System (DNS) — A database system that translates domain names (such as www.extron.com) into IP addresses. Dual channel encoding mode — The SMP 300 Series mode that signals from channel A and signals from channel B are encoded to separate archive streams (and, therefore, separate recordings), each with its own settings.
  • Page 173 Gateway — A router or proxy server between networks, or a network node equipped to interface with another network that uses different protocols (an entrance and exit into a communications network). Group of Pictures (GOP) — A group of successive pictures within a coded video stream. A GOP begins with an Intraframe (I-frame) (see page 166) containing the full spatial resolution and data of a video frame.
  • Page 174 Intraframe (I-frame) — In video compression schemes, intraframes (I‑frames) are primary frames that contain the full spatial resolution and data of a video frame. IP address — A numerical label using the Internet Protocol assigned to devices in a network. The IP address for the source and destination are included in an IP datagram. A unique, 32‑bit binary number (12‑digit dotted decimal notation —...
  • Page 175 Overscan — An applied “zoom” on SMPTE inputs (NTSC, PAL, 480p, 576p, 720p,1080i,1080p) to hide closed caption/ancillary data, edge effects, or other video artifacts. Parity (or Parity checking) — An error detection technique that tests the integrity of the digital data being sent. Parity can be set to None, Even, or Odd. Predictive frame (P-frame) —...
  • Page 176 Session Description Protocol (SDP) — This protocol is used to describe streaming media initialization parameters. It covers session announcement, session invitation, media type and format, and other forms of multimedia session initiation (as defined in RFC 2327). SDP does not deliver media itself. It simply details the stream parameters and how the stream is started.
  • Page 177 Transport Streams (TS) — A form of media wrapped in MPEG‑2 transport stream headers. The MPEG‑2 transport headers contain information about the media. The SMP is compatible with transport streams that contain H.264 encoded video and AAC encoded audio. Transport streams containing MPEG‑2 video and AC3 audio are not supported.

  • Page 178: Extron Warranty

    Extron Warranty Extron warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/ or materials, Extron will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to: USA, Canada, South America,...
