- Page 1 QUICK REFERENCE IFD5XX IFD550/IFD540 FMS/GPS/NAV/COM IFD545/IFD510 FMS/GPS IFD100 App for iPad avidyne.com | 800.AVIDYNE...
- Page 2 FMS knob (the outer ring scrolls through each box, whereas the inner ring scrolls through the fields of each box), or 2. Utilize hybrid touch by tapping the screen on a waypoint or in the blank space between waypoints. avidyne.com | 800.AVIDYNE...
- Page 3 Volume/Power/ Frequency Squelch Knob Frequency Swap Nearest (flip-flop) Line Select Keys Procedure (LSK) * COM/NAV Manual Direct To Tuning Knob (Push for NAV & Transponder) Page Function Keys CDI Nav Source (two-way rocker) SVS**, FMS, MAP, AUX FMS Knob (context- Active Waypoint sensitive: scroll, zoom/ push to select)
- Page 4 Here’s how: When a flight plan waypoint is a valid airway entry point, a dropdown list of available airways appears. Scroll to the desired exit point, and all intermediate intersections along that airway are automatically populated into the flight plan. avidyne.com | 800.AVIDYNE...
- Page 5 Inserting a Waypoint Use the right Push the right To add a waypoint knobs or tap the knob, press to your flightplan, ENTR, or tap identifier to display tap the empty space the QWERTY the ENTR key where your cursor is keyboard in order on the QWERTY below ‘Origin.’...
- Page 6 You can your saved route to the route tab edit the Route selections. on the FMS page. name or leave as default name (Origin Identifier- Dest Identifier.) avidyne.com | 800.AVIDYNE...
- Page 7 Activating a Stored Route To activate a route To activate, press the from the stored routes “Activate Route” LSK or list, tap the desired touch-screen button. route to select. Then Press again to “Activate Flightplan.”...
- Page 8 Pressing ENTR pre-populated with the box. The QWERTY or the right knob can waypoint highlighted in keyboard appears for also be used to confirm. your current flightplan. you to enter the desired waypoint identifier. avidyne.com | 800.AVIDYNE...
- Page 9 Selecting a Departure Tap the ‘Departure’ Select a departure Enter the Transition by field. A dropdown name and push ENTR. selecting the assigned list of available departure runway. departure procedures will be displayed.
- Page 10 Each subsequent press of the “PROC” key will step through all following destination airfield approaches/arrivals in the flight plan, and wrap back around to the origin. When the drop down box appears over the intended data field, tap the desired procedure to add to the flight plan. avidyne.com | 800.AVIDYNE...
- Page 11 Selecting a Visual Approach To select a Visual To select the desired Then select the Visual Approach for your Visual Approach, twist Entry, (Straight In, destination airport , the FMS knob to scroll Left Base, Right Base, press the “PROC” Function down past any published Left Downwind, Right key.* This will display a...
- Page 12 <waypoint added to the a drop down (turn direction, name>” and flight plan, list of options. leg length, push the FMS populated with inbound course). knob to select. either standard or published hold data. avidyne.com | 800.AVIDYNE...
- Page 13 Exiting/Deleting a Hold To Exit the hold, Other options A blue CAS Should you need select the “Exit message will include deleting to continue to Hold” Line Select alert you that you the Hold Hold, select Key (LSK1), and Waypoint with are ‘Exiting hold “Continue Hold”...
- Page 14 North Up (360°) -> Track Up (240° arc view) -> Track Up (360°) *If a Heading source is connected to the IFD, then you can set preference for Heading Up rather than Track Up in AUX->SETUP page under Map Orientation. avidyne.com | 800.AVIDYNE...
- Page 15 Decluttering the Map TAB: To select the preferred level of map density displayed, from the Map Page, Map tab, press the “Land” LSK to declutter the terrain base map and/or “Nav” LSK to declutter off-route NavAids (Intersections, Airports, VORs etc). There are four levels of declutter for each. The specified level of detail will remain consistent across all map pages.
- Page 16 EDR and your aircraft is 1,000 the perceived distance NCR remain enabled. ft AGL or greater, and above and behind the will disappear as you ownship symbol. descend below 1,000ft. avidyne.com | 800.AVIDYNE...
- Page 17 SVS Page Applies to IFD550 & IFD545 only. SVS Page provides ego-centric, Push the SynVis button ‘out-the-window’ view of SVS. (LSK3) to turn off the Twist the right knob or pinch Magenta Line. Push zoom the display to adjust pilot- again to turn off SVS, selectable horizontal field of view and to show a standard...
- Page 18 The Emergency COM Frequency, 121.5 kHz, can be quickly tuned into the Active COM slot by pressing and holding the flip-flop button for approximately three (3) seconds. avidyne.com | 800.AVIDYNE...
- Page 19 NAV Tuning Applies to IFD550 & IFD540 only. Nav radio tuning can be accomplished through 3 different methods. Use the COM/NAV Touch the standby Touch the Activate the knob. Push the frequency field standby frequency. to display the frequency, knob to display Once the desired numeric keypad.
- Page 20 Mode. You can also download Maintenance Logs from this page and pair your BT keyboard and more. Please use caution so as not to inadvertently change port settings or other configurations, For Tech Support and Training information, see back cover. avidyne.com | 800.AVIDYNE...
- Page 21 Connecting iPad to IFD via WiFi From AUX->SETUP Go to Settings Menu Under +Devices menu, page, double touch or on iPad and select WiFi locate your iPad by highlight and push right that matches your IFD’s name and change knob to expand the Network name.
- Page 22 If you are not seeing a Flightplan on your IFD100 after launch and you know your WiFi connection is good, it’s most likely that these do not match. You can verify database expiration dates by going to Go to AUX->SETUP and ‘Status - Databases’ page (LSK2). avidyne.com | 800.AVIDYNE...
- Page 23 IFD100 - Page & Tab Select different screens on the IFD100 in much the same way as with the panel mounted IFD5XX. Page buttons on the IFD100 operate much the same as the IFD5XX. Touching any of the available Tabs will switch the display accordingly.
- Page 24 North Up (360°) -> Track Up (240° arc view) -> Track Up (360°) *If a Heading source is connected to the IFD5XX, then you can set preference for Heading Up rather than Track Up in AUX->SETUP page under Map Orientation. avidyne.com | 800.AVIDYNE...
- Page 25 IFD100 - Synthetic Vision Select the TAWS Tab on the MAP page of the IFD100 to view 3D Exocentric Synthetic Vision, which includes 3D Terrain, Obstacles, Traffic (when available), Airports. The Terrain Awareness and Alerting feature shows nearby terrain within 1,000 feet as yellow hashed pattern, and terrain within 100 feet or above in red hashed pattern.
- Page 26 Baro Seting - Touch degree default. big-glass PFD display, to bring up numeric with Lateral and Vertical keypad. Enter current Deviation when the FMS Baro to enable Altimeter is flying an Instrument display on IFD100 PFD. or Visual Approach. avidyne.com | 800.AVIDYNE...
- Page 27 IFD100 - Portrait Mode Only when connected to IFD550 or IFD545. Rotate your iPad for Portrait Portrait Split-screen (only display of all the same screens with the IFD550/IFD545) as in landscape mode, but with from SVS page of IFD100. better vertical map distance. Split screen view of ego-centric PFD on upper half.
- Page 28 Launch Foreflight Touch 3 dots in top- App. middle of screen then be prompted to select select Split Screen another App. This is where you launch the (Middle icon). IFD100 App. Both apps will now be running. avidyne.com | 800.AVIDYNE...
- Page 29 NOTES...
- Page 30 PILOT SUPPORT 888.723.7592 Mon-Fri: 8:00AM–5:00PM EDT / 1200-2100 UTC visit: pilotsupport.avidyne.com email: pilotsupport@avidyne.com AFTER HOURS TECHLINE™ 877.900.4264 PILOT TRAINING www.avidyne.com/training P/N 600-00350-001 Rev01 AVI22-032 ©2022 Avidyne Corp. All Rights Reserved. 08/22 avidyne.com | 800.AVIDYNE...
