Owner's manual
! "
! "
! "
! "
! "
사용
사용 설명서
사용
설명서
설명서
설명서
사용
사용
설명서
DXZ956MC
CD/MP3/WMA Receiver /
CeNET & Touch Panel Control /
Music Catcher
CD/MP3/WMA
/ CeNET
Music Catcher
CD/MP3/WMA 리시버
리시버
리시버
리시버 / CeNET & 터치패널
리시버
뮤직
뮤직
캐처
캐처
뮤직
뮤직
뮤직 캐처
캐처
캐처
•
! "
! "
! "
! "
! "
#
#
#
#
# /
•
터치패널
터치패널
터치패널
터치패널 컨트롤
컨트롤
컨트롤
컨트롤
컨트롤 /
Advertisement
Table of Contents
Related Manuals for Clarion DXZ956MC
Summary of Contents for Clarion DXZ956MC
- Page 1 ! " ! " ! " 사용 사용 설명서 사용 설명서 설명서 설명서 사용 사용 설명서 DXZ956MC CD/MP3/WMA Receiver / CeNET & Touch Panel Control / Music Catcher • CD/MP3/WMA / CeNET Music Catcher • CD/MP3/WMA 리시버 리시버 리시버 리시버 / CeNET & 터치패널...
-
Page 2: Table Of Contents
Thank you for purchasing this Clarion product. ∗ Please read this owner’s manual in its entirety before operating this unit. ∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). ∗ This manual includes the operating procedures of the CD changer and TV tuner connected via the CeNET cable. -
Page 3: Precautions
2. Driving on extremely bumpy roads may cause severe vibration and cause the sound to skip. 3. This unit uses a precision mechanism. Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts. WARNING DXZ956MC... -
Page 4: Sloping Console
If you try to play such a compact disc, you may not be able to remove it from the CD player or it may damage the CD player. DXZ956MC 2. Before the SLOPING CONSOLE closes, there may be a braking sound from the safety mechanism. -
Page 5: Controls
3. CONTROLS Source unit [ ADJ ] IR-Receiver [ ROTARY ] [SRC] With the SLOPING CONSOLE opened Display [CD SLOT] DCP Detaching Slider [Q] (OPEN/EJECT) Photo Sensor [MODE] [ ] (SOUND) [ISR] DXZ956MC... -
Page 6: Nomenclature
AUX ➜ Radio... Note: External equipment not connected with CeNET is not displayed. DXZ956MC [ROTARY] knob • Press the knob to turn the power ON. • Press the knob to turn the power OFF. • Turn the knob to adjust the volume. -
Page 7: Operations When External Equipment Is Connected To This Unit
∗ For details, see the section “CD changer operations” (cf. page 46). For the DVD changer, refer to the Owner’s Manual provided with the DVD changer. ● When the TV is connected ∗ For details, see the section “TV operations” (cf. page 49). DXZ956MC... -
Page 8: Touch Panel Buttons
• Touch this button for preset channel up/down, folder up/down, and disc up/down operations. Sub buttons • Shows functions available in a certain context. DXZ956MC ● Simple operation display (To switch to the simple operation display, press Right slide and hold the [MODE] button for 2 seconds or button longer.) -
Page 9: Touch Panel Operations
) or down ( ) with your fingertip still touching the display, and keep your fingertip on the display. The current operation continues for the time your fingertip is held on the display. This operation is used, for example, for fast-forwarding/fast-rewinding tracks. P.CH 2:45 DISP DXZ956MC... -
Page 10: Dcp
• If you purchased a replacement DCP, an electrical adjustment is necessary. This adjustment requires technical knowledge. Please consult Clarion service or a Clarion service station. DXZ956MC Attaching the DCP 1. Place the DCP to the SLOPING CONSOLE, adjusting the metal connecters on DCP and the SLOPING CONSOLE. -
Page 11: Remote Control
Receiver for remote control unit Operating range : 30° in all directions Signal transmitter [ SRC ] [ ISR ] [ SCN ] [ BND ] [ a ], [ d ] [ DISP ] [ RDM ] [ RPT ] Insertion guide DXZ956MC... -
Page 12: Functions Of Remote Control Unit Buttons
Auto store. [RPT] No function. [RDM] No function. ∗ Some of the corresponding buttons on the source unit and remote control unit have different functions. DXZ956MC CD/MP3/WMA/ CD changer M.CATCHER DVD changer Returns to the first Moves the next disc track. -
Page 13: Operations
Speaker Configuration High 2ch Mid 2ch Subwoofer 2ch High 2ch Mid 2ch Rear 2ch Surround 2ch Center + Subwoofer Front 2ch Rear 2ch Subwoofer 2ch Tweeter (right) Front speaker (right) Rear speaker (right) Front speaker (right) Rear speaker (right) Sub-woofer DXZ956MC... -
Page 14: Turning Off
1. Press the [ROTARY] knob. The mode that was previously active is displayed. DXZ956MC Turning off 1. Press the [ROTARY] knob. ∗ The clock will stay displayed after the power is turned OFF. - Page 15 Basic Operations DISPLAY EDIT << TITLE D-BLUE AUTO COLOR SCROLL on the left of the display to COLOR SELECT N I G H T D A R K B L U E on the right of the display to DXZ956MC...
- Page 16 CD, CD changer, or MUSIC CATCHER mode. 1. Touch [DISP] while a title is shown. TRACK 02:53 ∗ Display edit mode appears. DXZ956MC 2. Touch [TITLE]. TITLE ∗ Title edit mode appears. 2:45 3. Touch DISP choose the kind of title to show.
-
Page 17: Radio Operations
2. Touch [BAND] to switch the reception band. Each touch of [BAND] switches the reception band as follows: FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1... Tuning There are 3 types of tuning mode available, seek tuning, manual tuning and preset tuning. DXZ956MC... -
Page 18: Preset Memory
∗ In the standard operation display, preset No. can also be tuned by touching ■ To cancel tuning 1. Touch [RTN]. DXZ956MC Preset memory A total of 24 preset positions (6-FM1, 6-FM2, 6- FM3, 6-AM) exists to store individual radio stations in memory. - Page 19 In the radio mode, tune the station to store, and press and hold the [ISR] button for 2 seconds or longer. You will hear a long beep, and the station currently being received is stored to ISR. Radio Operations DXZ956MC...
-
Page 20: Cd/Mp3/Wma Operations
Touching this during recording cancels the recording process. Touching this starts play from the track at the top of the disc or folder being played. DXZ956MC Touching this pauses or resumes play. DISP The display contents can be changed. a/d (only in the simple operation display) Touching these buttons selects the track to play. - Page 21 • Never insert foreign objects into the CD SLOT. • If the CD does not insert easily, there may be another CD in the mechanism or the unit may require service. Set to MP3/WMA Play MP3/WMA Play CD Play MP3/WMA DXZ956MC...
-
Page 22: Selecting A Track
Listening to a disc already loaded in the unit 1. Press the [SRC] button to select the CD/ MP3 mode. DXZ956MC ∗ Play automatically starts when the mode mark and changes to the CD/MP3 mode. Pausing play 1. -
Page 23: Repeat Play
1. Press the [MODE] button. 2. Touch [TRACK RPT]. ■ To cancel repeat play 1. Press the [MODE] button. Folder repeat play This function allows you to play the current folder repeatedly. 1. Press the [MODE] button. 2. Touch [FOLDER RPT]. DXZ956MC... -
Page 24: Random Play
In the M.CATCHER mode, the files recorded in the built-in flash memory are played back. Operations for listening to a recording made using MUSIC CATCHER are the same as “CD/ MP3/WMA Operations”. For operations for recoding using MUSIC CATCHER, refer to the section “MUSIC CATCHER Operations”. DXZ956MC... -
Page 25: Music Catcher Operations
The display shows “CANCELED” and then the playback of the CD continues. Notes: • Recording also can be canceled by pressing the [SRC], [ Q ] or [ISR] button. • When recording is canceled, the track that has been recorded incompletely is deleted. DXZ956MC... - Page 26 “MM (minute): SS (second)” format. For example, “AVIL. 123:45”. Note: • The recordable time shown varies according to the set recording mode. DXZ956MC 253:49...
-
Page 27: Sound Adjustment
1. Press the [SOUND] button. 2. Touch [ADF]. SOUND SETTING BALANCE VOLUME 3. Touch on the right of the display to select the ADF mode. ADF MODE ADF 1 ∗ Select one of “USER”, “1”, “2”, “3”, or “OFF”. DXZ956MC... - Page 28 SETTING TIME P.EQ X-OVER ALIGN GAIN PRESET DXZ956MC 4. Touch [ON/OFF]. The P.EQ effect is toggled ON/OFF. FREQUENCY 5. Touch [L/R] to select “LEFT” or “RIGHT”. 6. Touch [BAND]. ∗This item can be adjusted within the range 1 to 3.
- Page 29 2WAY) is THROUGH, 25Hz to 10 kHz. (The factory default setting is “80Hz”.) Sound Adjustment Q curve : 1 X OVER MODE 80Hz REAR on the left of the display to switches the on the right of the display to DXZ956MC...
- Page 30 This is displayed when the “SPEAKER SELECT” is set to “3WAY”. This is displayed when the “SPEAKER SELECT” is set to “2WAY”. DXZ956MC 5. Touch adjust the setting. ∗ The adjustment range is 0cm to 501.4cm in 2.3 cm steps.
- Page 31 ∗ This item can be adjusted within the range -5 to +5. 4. Press the [SOUND] button to return to the original mode. Sound Adjustment SETTING TIME X-OVER ALIGN GAIN SEAT PRESET SW VOLUME on the right of the display and DXZ956MC...
- Page 32 R12 (rear side emphasized) and F12 (front side emphasized). 4. Press the [SOUND] button to return to the original mode. DXZ956MC Selecting the VSE menu VSE (Virtual Space Enhancer) allows you to compensate the sound pressure balance inside your car so that the same sound effect can be obtained whichever seat you are sitting in as proved in compensation simulations.
- Page 33 3. Touch [ON/OFF]. The P.EQ effect is toggled ON/OFF. 4. Touch select one of the P.EQ menus. Sound Adjustment SETTING TIME X-OVER ALIGN GAIN SEAT PRESET P.EQ MODE SEDAN-1 PRESET ON/OFF on the right of the display and DXZ956MC PRESET...
- Page 34 250 Hz Front 500 Hz (USER) Rear 500 Hz DXZ956MC 4. Touch select one of the P.EQ menus. 5. Press the [ADJ] button. 6. Touch [F/R] to select [FRONT] or [REAR]. FREQUENCY 7. Touch [BAND] to select the value to set.
- Page 35 • The factory default setting is “0dB”. 1. Press the [SOUND] button. 2. Touch [SP GAIN]. SP GAIN MODE FRONT - L 3. Touch on the left of the display to select an item. Each touch switches the adjustment item as follows: BALANCE FADER DXZ956MC...
-
Page 36: Music Mode
Select the frequency that suits your speaker when you have installed speakers with smaller diameter. Set to “THROUGH” if you use speakers that can reproduce low frequency sound. DXZ956MC ● SUB-W LPF (Subwoofer Low-Pass Filter) ➜ adjustment This filter cuts the signals above the selected frequency value. - Page 37 SRD SP 4. Touching adjust the delay time. • “SRD-SP” can be adjusted within the range 0ms to 15ms. 5. Press the [SOUND] button to return to the original mode. Sound Adjustment on the right of the display to DXZ956MC...
-
Page 38: Common Operations
MUSIC MATCHER files a title up to 10 characters long. These titles can be displayed when broadcasts are received or when playing CDs. The number of titles that can be entered is as follows: DXZ956MC Mode CD mode TV mode Radio mode MUSIC CATCHER mode 64 titles... -
Page 39: Changing Settings
∗ This function is not compatible with all cellular telephones. Contact your local authorized Clarion dealer for information on proper installation and compatibility. Common Operations Changing settings Selecting setting items 1. - Page 40 • Setting the portable audio (AUX) input level (cf. page 44) SYSTEM CHECK • Performing a system check (cf. page 44) CODEMATIC • Setting security (cf. page 45) SLIDE CONT • Setting the slide direction of the slide buttons (cf. page 45) DXZ956MC Sub item...
- Page 41 ADJ-APPEARANCE [ ENT ] MESSAGE INPUT We I come TEXT on [FONT] to select the type of switches the type of on [TEXT] to determine the DXZ956MC...
- Page 42 ∗ Select one of OFF (dimming OFF, bright), 1 (slightly dimmed) to 5 (dark). DXZ956MC 5. Press the [ADJ] button to return to the original mode. Adjusting the brightness of...
- Page 43 ADJ APPEARANCE I CON I CON on the right of the display to on the left of the display to ADJ SOUND SELECT P. E Q on the right of the display to DXZ956MC...
- Page 44 AUX function This system has an external RCA input so you can listen to sounds and music from external devices connected to this unit. DXZ956MC Setting the input level (AUX SENS) of portable audio (AUX mode) This function allows you to set the input level of optional external devices connected to this unit.
- Page 45 “UP ➜ +” or “DOWN ➜ +”. 5. Press the [ADJ] button to return to the original mode. INPUT Common Operations CODE MATIC on the left of the display to ADJ SETTING on the right of the display to DXZ956MC...
-
Page 46: Operations Of Accessories
Pressing and holding [MODE] button for 2 seconds or longer switches the simple operation display. TELL ME TRACK 03:29 DXZ956MC Playing time display Î00:01: The playing time is displayed. Track No. display Touching the track to play, or fast-forward/fast-rewind tracks. -
Page 47: Scan Play
Repeat play continuously plays the current track. This function continues automatically until it is canceled. 1. Press the [MODE] button. 2. Touch [TRACK RPT]. ■ To cancel repeat play 1. Press the [MODE] button. on the track on the track DXZ956MC... - Page 48 The disc random play selects and plays individual tracks or discs automatically in no particular order. This function continues automatically until it is canceled. 1. Press the [MODE] button. 2. Touch [DISC RDM]. ■ To cancel disc random play 1. Press the [MODE] button. DXZ956MC...
-
Page 49: Tv Operations
∗ The mode of equipment that is not connected is not displayed. Switching the reception band 1. Touch [BAND] to switch the reception band. Each touch of [BAND] switches the reception band. TV1 ➜ TV2 ➜ TV1... on the right slide button in the DXZ956MC... - Page 50 ∗ The station can also be tuned by touching in the standard operation display. ■ To cancel tuning 1. Touch [RTN]. DXZ956MC Preset memory A total of 12 TV stations can be stored (6-TV1 and 6-TV2). This allows you to select your favorite TV stations and store them in memory for later recall.
-
Page 51: Watching A Video
TV D I V E R 4. Touch select [ON] or [OFF]. 5. Press the [ADJ] button to return to the original mode. TV Operations on the left of the display to ADJ TUNER on the right of the display to DXZ956MC... -
Page 52: In Case Of Difficulty
Noise is generated or noise is mixed with sound. DXZ956MC Cause Replace with a fuse of the same amperage. If the fuse blows again, consult your store of purchase. Consult your store of purchase. Turn the unit off and check each wire for a possible short. - Page 53 Measure Let dry for about 1 hour with the power on. Use ISO9660 level 1, 2 or JOLIET or Romeo file system. Use alphanumeric/ASCII characters for MP3/WMA file name. Use “.M3U” for the file extension of a play list. DXZ956MC...
-
Page 54: Error Displays
If an error display other than the ones described above appears, press the reset button. If the problem persists, turn off the power and consult your store of purchase. DXZ956MC Cause This is a failure of CD deck’s mechanism and consult your store of purchase. -
Page 55: Specifications
7" (Width) × 2" (Height) × 6-5/16" (Depth) [178 (W) × 50 (H) × 160 (D) mm] Dimensions / Remote control unit: 1-3/4" (Width) × 4-7/16" (Height) × 1/2" (Depth) [44 (W) × 113 (H) × 13 (D) mm] DXZ956MC... - Page 56 Clarion Co., Ltd. PE-2747K 2005/2 (Abe·Abe) 280-8213-00 All Rights Reserved. Copyright © 2005: Clarion Co., Ltd.
