ION Block Rocker Max Service Manual page 5

Bill of Materials (BOM)
Part # Part Name
CR010985 IPA76C2 LED
10520174 shim
10520219 copper foil
10530036 Iron prop
10530091 Iron prop
12030044 rocker switching
13110024 Switching power supply
16040955 plug wire
16040956 plug wire
16041016 plug wire
16041017 plug wire
16050255 shielded wire
16060105 Ground wire
16120133 plug wire
16141101 plug wire
19020014 glass fuse
20320025 Handle
20360099 EVA sheet
20410119 Buttorn
20410121 Buttorn
20440059 Buttorn
20460013 fixed button
24100053 magnet ring
30060163 form
30060227 form
30090002 bunch
30110004 gasket
40010038 power socket
60100016 wire
60100024 wire
60190175 FM wire
70010046 screw
70010048 screw
70010088 screw
70010111 screw
70010337 screw
70010576 screw
70010605 screw
70070031 hex nut
CR010981 IPA76C2 MAIN
60210077 module
CR010983 IPA76C2 AMP
54020109 top cover
54020110 top cover
54020111 top cover
10410171 grill
10520106 trundle
10520185 wire
16040929 plug wire
16040961 plug wire
Specification
IPA76C2 LED ASSY
lower carbon steel T=1.5mm,V1.0
Red copper,180*40*0.03mm,V1.0
DN-MB6036
DN-MB6084,ROHS,V1.0
AN-S343,RS601D,6A/250V
AN-T90024,WJ68W-165410,100-240VAC,16.5V/4.1A
AN-W4515,2P,22#,UL1617,130mm
AN-W4516,2P,22#,UL1007,420mm
AN-W4577,16#,UL1015,100mm
AN-W4578,2P,20#,UL1007,180mm
AN-W5252,UL1533/26#,UL1007/#22,100mm
AN-W702,18#,UL1015,150mm
AN-WE133,22#,UL1007,200mm
22#,UL1007,L=80mm
522,1A/250V,Φ5*20mm
DN-PE2025,ABS,UL94V-0ROHS,V1.0
DN-PE6054,ABS,UL94V-0,ROHS,V1.0
DN-PEB075,(3),ABS,ROHS,V1.0
DN-PEB076,(2),ABS,ROHS,V1.1
UBD-1,NYLON66(94V-0)
KY-CLT-2
V180174T
10*1000*1mm
12*1000*2.0mm
2.5*80mm
IPA76C,T=1mm,Φ3.5*Φ12mm,ROHS.V1.0
AN-J0138,DB-14-F,3P
IPA23,AMwire,AM-D8x100mm-85TS-M7
2.4G,2DBi,ROHS
￠9.5*220mm,V1.1
M3*6mm
AN-C10048,M3*6mm
Φ3*8mm
Φ3*10mm
Φ2.6*8mm
Φ3*6mm
Φ2.6*7mm
Φ9*M5*8mm
IPA76C2 MAIN ASSY
IPA76C2,CSR,JS-BTM8605,Block Rocker Max,V1.0
IPA76C2 AMP ASSY
DN-PC2111,ABSJP,V1.0
DN-PC2111,ABS,EU,V1.0
DN-PC2111,ABS,US,V1.0
DN-ME5126,SPCC,T=0.8mm,V1.0
JD180D
265*15mm,T=0.3mm,V1.1
AN-W4489,2P,18#,UL1015,L=450mm
AN-W4521,1P,18#,UL1015,750mm
Qty
1
1
1
3
2
1
1
1
2
1
1
1
1
1
1
1
2
2
6
1
1
1
2
2
0.6
5
2
1
1
1
1
5
5
9
10
8
2
2
1
1
1
1
1
1
1
1
2
1
1
1
