Melal Part cal return path to the chassis. Any current measured must not exceed 0.5mA. Reverse the instrument power cord plug in the out- ohmmeter let and repeat the test. See Fig. 1-1. Fig. 1-2 Insulation Resistance Test Samsung Electronics...
Page 3
(5) antenna wiring. Always inspect in all areas tinuously and new instructions are issued whenev- for pinched, out-of-place, or frayed wiring, Do not er appropriate. change spacing between a component and the printed-circuit board. Check the AC power cord for damage. Samsung Electronics...
Page 4
Components i-enti- fied by shading, by( ) or by ( ) in the circuit dia- gram are important for safety or for the characteris- tics of the unit. Always replace them with the exact replacement components. Samsung Electronics...
Page 5
(6) Do not remove a replacement ESD device from its protective package until immediately before your are ready to install it.(Most replacement ESD devices are packaged with leads electrically short- ed together by conductive foam, aluminum foil or comparable conductive materials). Samsung Electronics...
Page 6
◆ Be sure to put on a wrist strap grounded to the sheet. ◆ Be sure to lay a conductive sheet made of copper etc. Which is grounded to the table. Samsung Electronics...
Page 7
3) Make solder land 2 points short on Pick-up. (See Fig. 1-4) 4) Disassembly the Pick-up. Note : If the assembly and disassembly are not done in correct sequence, the Pick-up may be damaged. SOLDER LAND 2 POINTS SHORT PICK-UP ASS'Y Fig. 1-4 Samsung Electronics...
Page 8
All manuals and user guides at all-guides.com 2. Alignment and Adjustment 2-1 Location of Test Point SKEW Fig. 2-1 Location of Test Point Samsung Electronics...
Page 9
Adjustment Spec. Test Point Adjustment Location TDV-533 “ENV” Screw A / B Chapter 14 Flat Waveform (Main PCB - Component Side) Ass’y Deck - Bottom Side (See Fig. 2-1) (See Fig. 2-2) Fig. 2-2 Ass’y Deck (Top Side) Samsung Electronics...
Page 10
If you cannot obtain a Flat waveform, then the unit is defective. Note : The Deck must be in a horizontal position. Use both “A” and “B” screws to adjust. Typical Waveform before Adjustment Waveform after Correct Adjustment Fig. 2-3 Envelope Waveform Samsung Electronics...
Page 11
All manuals and user guides at all-guides.com Alignment and Adjustment MEMO Samsung Electronics...
Page 12
3-2 Deck Assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Notice You can search for the updated part code through ITSELF web site. URL; http://itself.sec.samsung.co.kr Samsung Electronics...
Page 13
All manuals and user guides at all-guides.com Exploded Views and Parts List 3-1 Cabinet Assembly DECK-DVD MECHA (S.N.A.) 601 (ASSY-PCB-MAIN) CN1B 602 (ASS'Y-PCB-JACK) S.N.A. (ASS'Y CABINET-BOTTOM) S.N.A. : Service Not Available DVD-P230 DVD-P331 UT01 Samsung Electronics...
Page 14
ASSY PCB-JACK;DVD-P331/XAA,EXINO JACK PC AC39-10200N CBF POWER CORD;EP2,SPT-2,AWG#18,1.8MT,WA AK92-00148A ASSY PCB-KEY;DVD-P392,KEY PCB ASS’Y Only for DVD-P331 CN1B 3809-001180 CABLE-FLAT;30V,-30to+80C,80mm,35P,1.25mm UT01 Refer to table below REMOCON-ASS’Y;DVD-P331/XAA,XAA,-,-,-,-,- Models UT01 DVD-P230 AK97-00300C AK97-00301C AK64-00101A AK92-00151A AK92-00130A AH59-00092S DVD-P331 AK97-00328A AK64-00088D AK64-00101C AK92-00149A AK92-00150A AH59-00092T...
Page 15
All manuals and user guides at all-guides.com Exploded Views and Parts List 3-2 Deck Assembly H107 H105 H106 H102 H103 S.N.A. H108 H104 H241 H211 H206 H206 H203 H207 H202 H205 H204 H210 H209 Samsung Electronics...
Page 21
All manuals and user guides at all-guides.com Electrical Parts List Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark AK92-00130A ASSY PCB-JACK;DVD-E231/XAA,EXINO JACK PC DVD-P230 AR405 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M AK92-00150A ASSY PCB-JACK;DVD-P331/XAA,EXINO JACK PC DVD-P331 AR406 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2M AC201 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,...
