Mitsubishi L200 2016-

• Fitting instructions electric wiring kit tow bar with 12-N socket up to DIN/ISO Norm

1724.

• We would expressly point out that assembly not carried out properly by a competent

installer will resultin cancellation of any right to damage compensation, in particular

those arising by virtue of the product liability act.

• Contents of these kits and their fitting manuals are subject to alteration without

notice, please ensure that these instructions are read and fully understood before

commencing installation.

• Do not overload circuits; the maximum loads per connection are detailed in this

manual.

• Attention! Before Installation, please read this manual carefully and inform

your customer to consult the vehicle owners manual to check for any vehicle

modifications required before towing.

• In the event of functional problems, troubleshooting must be

limited to about 0.5 hours, contact the installers support:

customercare@ecs-electronics.com / 00800 22 55 23 27.

Partnr.: MT-131-BHU

Revision: 0

Monday - Friday

08.00am - 11.00am

12.00am - 05.00pm

GMT

customercare@ecs-electronics.com

www.ecs-electronicsuk.co.uk

MT-131-BHU / 120515TT

Summary of Contents for ECS MT-131-BHU

Page 1 • In the event of functional problems, troubleshooting must be limited to about 0.5 hours, contact the installers support: customercare@ecs-electronics.com / 00800 22 55 23 27. Monday - Friday 08.00am - 11.00am 12.00am - 05.00pm customercare@ecs-electronics.com...
Page 2 Start Guide Code follow original wire airbag UN-243-YZ Optional reverse lamp pre-wire extension included Pag. 20 OPTION P.D.C. PARK DISTANCE CONTROL PARK DISTANCE CONTROL Fuse 20 Amp. Pag. 18 - 19 © ECS Electronics B.V. Pag. 2 MT-131-BHU / 120515TT...
Page 8 Club Cab Double Cab Wire-tie 200 mm Club Cab Wire-tie 200 mm © ECS Electronics B.V. Pag. 8 MT-131-BHU / 120515TT...
Page 9 Double Cab Option 1 FOLLOW ORIGINAL CLIP Wire-tie 200 mm Wire-tie 200 mm Wire-tie 450 mm Wire-tie 360 mm Option 2 FOLLOW ORIGINAL CLIP Wire-tie 200 mm Wire-tie 360 mm © ECS Electronics B.V. Pag. 9 MT-131-BHU / 120515TT...
Page 10 Club Cab Option 1 FOLLOW ORIGINAL CLIP Wire-tie 200 mm Wire-tie 200 mm Wire-tie 450 mm Wire-tie 360 mm Option 2 FOLLOW ORIGINAL CLIP Wire-tie 200 mm Wire-tie 360 mm © ECS Electronics B.V. Pag. 10 MT-131-BHU / 120515TT...
Page 16 Orange 20 Amp. Code TEST ALL THE CIRCUITS WITH A TEST DEVICE WITH THE CORRECT POWER LOAD FOR EACH FUNCTION. A TEST DEVICE WITH LED’S CANNOT BE USED FOR THIS PURPOSE. © ECS Electronics B.V. Pag. 16 MT-131-BHU / 120515TT...
Page 17 Code follow original wire 08.00am - 11.00am airbag 12.00am - 05.00pm customercare@ecs-electronics.com www.ecs-electronicsuk.co.uk INFO SOCKET CONNECTION STOP DIN/ISO 1724 3/31 5/58-R 6/54 7/58-L 3x21W Colour Yellow Blue White Green Brown Black © ECS Electronics B.V. Pag. 17 MT-131-BHU / 120515TT...
Page 18 PDC module requires to switch off the system (+12v or Earth trigger). Then connect the Trigger wire of the PDC system to pin 9 of the ECS connector, and connect the required feed (+12v or Earth) to pin 7 and 5.
Page 19 AFTER MARKET / NON-OE PARKSENSOR-SYSTEM Reverse 12 Volt signal PDC MUTE PDC UNIT 12 Volt OPTION 1, NO PDC MUTE OPTIONS OPTIONS OPTION 2, PDC MUTE 9 7 5 PDC MUTE PDC UNIT 12 Volt © ECS Electronics B.V. Pag. 19 MT-131-BHU / 120515TT...
Page 20 UN-243-YZ Reverse lamp pre-wire extension MAX = 21W UN-243-YZ 8 10 8 10 MAX = 21W Reverse © ECS Electronics B.V. Pag. 20 MT-131-BHU / 120515TT...
