ECS HY-095-DHU User Manual

Hyundai santa fe 12/2012- & 10/2015-; hyundai grand santa fe 2013-

Download this manual

With prepared trailer connector

Hyundai Santa Fe 12/2012- & 10/2015-

Hyundai Grand Santa Fe 2013-

• Fitting instructions electric wiring kit tow bar with 13-P socket up to DIN/ISO Norm

11446.

• We would expressly point out that assembly not carried out properly by a competent

installer will resultin cancellation of any right to damage compensation, in particular

those arising by virtue of the product liability act.

• Contents of these kits and their fitting manuals are subject to alteration without

notice, please ensure that these instructions are read and fully understood before

commencing installation.

• Do not overload circuits; the maximum loads per connection are detailed in this

manual.

• Attention! Before Installation, please read this manual carefully and inform

your customer to consult the vehicle owners manual to check for any vehicle

modifications required before towing.

• In the event of functional problems, troubleshooting must be

limited to about 0.5 hours, contact the installers support:

customercare@ecs-electronics.com / 00800 22 55 23 27.

Partnr.: HY-095-DHU

Revision: 0

Monday - Friday

08.00am - 11.00am

12.00am - 05.00pm

GMT

customercare@ecs-electronics.com

www.ecs-electronicsuk.co.uk

HY-095-DHU/ 030216CP

Page 1 • In the event of functional problems, troubleshooting must be limited to about 0.5 hours, contact the installers support: customercare@ecs-electronics.com / 00800 22 55 23 27. Monday - Friday 08.00am - 11.00am 12.00am - 05.00pm customercare@ecs-electronics.com...
Page 2: Part List
Gebruikershandleiding Gebruikershandleiding User guide User guide Guía del usuario Guía del usuario Manuale di istruzioni Manuale di istruzioni Bruksanvisning Citroën C4 Hatchback © ECS Electronics B.V. www.ecs-electronics.com Revision: 0 CT-026-DL / 210305RH © ECS Electronics B.V. Pag. 2 HY-095-DHU/ 030216CP...
Page 5 OPTION GRAND Santa FE Santa Fe Option 1 30 mm ø 35mm 20 mm Option 2 20 mm ø 35mm 17,5 mm © ECS Electronics B.V. Pag. 5 HY-095-DHU/ 030216CP...
Page 6: Socket Connection
Grand Santa Fe ø 35mm 60 mm INFO Option 1 Option 2 SOCKET CONNECTION Option 3 Pag. 11 Option 1 © ECS Electronics B.V. Pag. 6 HY-095-DHU/ 030216CP...
Page 11 15 amp. 15 amp. STOP DIN/ISO 11446 3/31 5/58-R 6/54 7/58-L 2x21W 3x21W 2x21W 180W/15Amp 180W/15Amp Yellow Blue White Green Brown Black Black/ Brown/ White White Colour White 1,00 mm 2,50 mm © ECS Electronics B.V. Pag. 11 HY-095-DHU/ 030216CP...
Page 12 PARK DISTANCE CONTROL PARK DISTANCE CONTROL Info PARK DISTANCE CONTROL Option! PARK DISTANCE CONTROL For OEM installed PDC systems Option 1 Option 2 Ground / 31 1 3 5 1 3 5 TEST Neutral © ECS Electronics B.V. Pag. 12 HY-095-DHU/ 030216CP...
