JBL Studio S-CENTERII Owner's Manual

S P E C I F I C A T I O N S
Maximum Recommended
Amplifier Power:**
Nominal Impedance:
Sensitivity (2.83V/1m):
Frequency Response (–3dB):
Crossover Frequencies:
High-Frequency Transducer:
Midrange Transducer:
Low-Frequency Transducer:
Dimensions (H x W x D):
* Dolby and Pro Logic are trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
** The maximum recommended amplifier power rating will ensure proper system headroom
to allow for occasional peaks. We do not recommend sustained operation at these
maximum power levels.
All features and specifications are subject to change without notice.
O W N E R ' S G U I D E
S T U D I O
P R O D U C T L I N E :
S-CENTER
M O D E L
N U M B E R :
D E S I G N G O A L : Bring the thrill of live performance and movie sound to
the home environment by calling on JBL's professional engineering leadership.
T W E E T E R T Y P E : Pure-titanium dome with EOS™ waveguide
W O O F E R T Y P E : Cast-aluminum basket with HeatScape™ motor structure
C R O S S O V E R N E T W O R K : Straight-Line Signal Path™ (SSP)
P O R T D E S I G N : FreeFlow™ flared
P R O F E S S I O N A L R E F E R E N C E : Studio Monitor
Description: 3-Way dual 5-1/4" center
150W
8 Ohms
91dB
75Hz – 20kHz
800Hz, 3200Hz
1" Pure-titanium dome, with rubber surround,
shielded; Elliptical Oblate Spheroidal™ (EOS)
waveguide
4" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, shielded; Linear Field
Proximity™ (LFP) bezel
5-1/4" PolyPlas™ (polymer-coated cellulose fiber)
cone, rubber surround, SFG™ , magnetic shorting
rings, high-temp oversized Kapton
HeatScape™ motor structure, cast-aluminum
baskets, shielded
Baffles: Low Diffraction, IsoPower™
Port: FreeFlow™ flared
Network: Straight-Line Signal Path™ (SSP)
Terminals: All-metal, gold-plated, 5-way binding posts
7-7/8" x 20-1/2" x 9"
200mm x 521mm x 229mm
Weight: 15 lb/6.8kg
S E R I E S
™
JBL Consumer Products
II
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated. JBL is a registered trademark
of JBL, Incorporated.
Part No. ai0456
voice coil,
®
P R O S O U N D
C O M E S H O M E ™
