S P E C I F I C A T I O N S
SCS135 System
Frequency Response
35Hz – 20kHz (–6dB)
Satellites
Recommended Power:
10 – 50 watts
Impedance:
8 ohms nominal
Sensitivity:
86dB @ 1 watt/1 meter
Tweeter:
One 13mm (1/2") titanium-lami-
nate dome, video-shielded
Midrange:
One 76mm (3") driver,
video-shielded
Dimensions (H x W x D):
111mm x 81mm x 95mm
4-3/8" x 3-3/16" x 3-3/4"
Weight:
0.5kg/1.1 lb
Refinements may be made on occasion to existing products without notice, but will always meet
or exceed original specifications unless otherwise stated.
Simply Cinema is a registered trademark of JBL, Incorporated.
* Dolby and Pro Logic are trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
O W N E R ' S G U I D E
PRODUCT LINE:
SCS135 (220-240V)
MODEL
NUMBER:
DESIGN GOAL: Bring the thrill of live performance and movie sound to the
home environment by calling on JBL's professional engineering leadership.
SATELLITE TYPE: Titanium-laminate-dome tweeter, sealed enclosure
SUBWOOFER TYPE:Bass-reflex enclosure
PORT DESIGN: FreeFlow™ flared
PROFESSIONAL REFERENCE: Cinema Loudspeaker Series
Center
Recommended Power:
10 – 50 watts
Impedance:
8 ohms nominal
Sensitivity:
86dB @ 1 watt/1 meter
Tweeter:
One 13mm (1/2") titanium-lami-
nate dome, video-shielded
Midrange:
Dual 76mm (3") drivers,
video-shielded
Dimensions (H x W x D):
83mm x 194mm x 95mm
3-1/4" x 7-5/8" x 3-3/4"
Weight:
0.86kg/1.89 lb
P R O S O U N D
C O M E S H O M E
®
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2000 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No.ai5075
Subwoofer
Amplifier:
100 watts RMS
Bass:
203mm (8") woofer, bass-reflex
enclosure
Dimensions (H x W x D):
381mm x 330mm x 356mm
15" x 13" x 14"
Weight:
13.6kg/30 lb
™

Advertisement

Table of Contents
loading

Related Manuals for JBL Simply Cinema SCS135

Summary of Contents for JBL Simply Cinema SCS135

  • Page 1 Refinements may be made on occasion to existing products without notice, but will always meet or exceed original specifications unless otherwise stated. Simply Cinema is a registered trademark of JBL, Incorporated. * Dolby and Pro Logic are trademarks of Dolby Laboratories.
  • Page 2 SCS135 (220-240V) MODEL NUMBER: DESIGN GOAL: Bring the thrill of live performance and movie sound to the home environment by calling on JBL’s professional engineering leadership. SATELLITE TYPE: Titanium-laminate-dome tweeter, sealed enclosure SUBWOOFER TYPE:Bass-reflex enclosure PORT DESIGN: FreeFlow™ flared PROFESSIONAL REFERENCE: Cinema Loudspeaker Series...

  • Page 3: R E A D T H I S

    Objects have fallen, or liquid has been built-in installation such as a bookcase or spilled into, the product; or rack unless proper ventilation is provided Steen Michaelsen or the manufacturer’s instructions have JBL Europe A/S been adhered to. Harman Consumer International France, 4/00...
  • Page 4 T H A N K Y O U F O R C H O O S I N G J B L For more than 50 years, JBL that you expected – and that and helps us to better under-...

  • Page 5: Speaker Placement

    S P E A K E R P L A C E M E N T Center-Channel Front Speakers Speaker Subwoofer 0 – 0.61m (0 – 2 ft.) Surround Speakers 1.52 – 1.83m (5 – 6 ft.) The front speakers should be ing the leg in to angle the reproduced by the subwoofer placed the same distance from...

  • Page 6: Mounting Options

    M O U N T I N G O P T I O N S Satellites and Surrounds On shelves. On the wall. Wall brackets On optional stands (FS300). are included. Wall-Mounting Attach plate to wall. The Slide speaker onto support. Place speaker and support brackets should be placed, on wall plate.

  • Page 7: Speaker Connections

    Most manu-facturers of image. speakers and electronics, With the advent of multi- including JBL, use red to channel surround-sound sys- denote the (+) terminal and tems, connecting all of the black for the (–) terminal.

  • Page 8: Dolby* Pro Logic* (Non-Digital) - Speaker Level

    Dolby* Pro Logic* (Non-Digital) – Speaker Level Use this installation method for Left Front Right Front Dolby Pro Logic appli-cations Center (not Dolby Digital, DTS – ® – – other digital processing), where the receiver/processor does not have a subwoofer out- put, or a volume-controlled pre- amp (line-) level output: Subwoofer...

  • Page 9: Dolby Pro Logic (Non-Digital) - Line Level

    Dolby Pro Logic (Non-Digital) – Line Level Use this installation method Use RCA-type patch cords sors. Note: If your receiver or for Dolby Pro Logic appli- to connect the line-level sub- amplifier only has one sub- cations (not Dolby Digital, DTS woofer outputs on your receiv- woofer output jack, then you or other digital processing),...

  • Page 10: Operation

    O P E R A T I O N Move the Master Power ing program material to the When the “Auto/On” switch ™ switch (marked “Power” ¡) to subwoofer, the subwoofer will is switched to the “On” posi- • the “ ”...

  • Page 11: Troubleshooting

    T R O U B L E S H O O T I N G If there is no sound from any of • If your receiver/processor is If there is no sound from the the speakers: set in Dolby Pro Logic mode, surround speakers: •...
  • Page 12 Staple sales invoice here.
