ADVANCED MANUAL

COMMUNICATIONS RECEIVER

INTRODUCTION

iR30

1 POWER SUPPLY

2 microSD CARD

3 RECORDING AND PLAYING BACK

4 MEMORY OPERATION

5 GPS OPERATION

6 MENU SCREEN

7 OTHER FUNCTIONS

8 Bluetooth

OPERATION

9 UPDATING THE FIRMWARE

10 OPTIONS

11 SPECIFICATIONS

Summary of Contents for Icom IC-R30

Page 1 ADVANCED MANUAL COMMUNICATIONS RECEIVER INTRODUCTION iR30 1 POWER SUPPLY 2 microSD CARD 3 RECORDING AND PLAYING BACK 4 MEMORY OPERATION 5 GPS OPERATION 6 MENU SCREEN 7 OTHER FUNCTIONS 8 Bluetooth OPERATION ® 9 UPDATING THE FIRMWARE 10 OPTIONS 11 SPECIFICATIONS...
Page 2 INTRODUCTION Thank you for choosing this Icom product. This product is designed and built with Icom’s state of the art technology and craftsmanship. With proper care, this product should provide you with years of trouble-free operation. ■ About the IC-R30 manuals The following manuals are supplied for your IC-R30.
Page 3 INTRODUCTION Functions of Adobe Acrobat Reader ® ® ® The following functions and features can be used with Adobe Acrobat Reader. • Keyword search Click “Find” (Ctrl+F) or “Advanced Search” (Shift+Ctrl+F) in the Edit menu to open the search screen. This is convenient when searching for a particular word or phrase in this manual.
Page 4 INTRODUCTION Functions of Adobe Acrobat Reader (Continued) ® ® ® • Printing out the desired pages. Click “Print” in the File menu, and then select the paper size and page numbers you want to print. * The printing setup may differ, depending on the printer. Refer to your printer’s instruction manual for details.
Page 5: Entering And Editing Text
INTRODUCTION Entering and editing text The usable characters are alphabets, numbers and symbols. To enter characters • To insert a text, move the cursor to a place to enter, then push the keypad. L You can elect a character by rotating [DIAL], or pushing D-pad (Up) or D-pad (Down). •...
Page 6 INTRODUCTION Entering and editing text (Continued) D Usable characters The usable characters and symbols, and the maximum characters differ, depending on the item. See the following list for details. Maximum Illegal Category Item Character type Ref. characters characters Memory name [AB] [ab] [12] [!”#] 16 –...
Page 7 INTRODUCTION Entering and editing text (Continued) D How to enter Example: Entering “2m Call” as a Memory name of channel 00 in group 00. Push [VFO/MR] to enter the Memory mode. Push [MW]. Select “Manage Memory.” (Rotate [DIAL] to select it, then push [ENTER].) Select group “00.”...
Page 8 INTRODUCTION About the air ventilation holes There are air ventilation holes on the receiver body and battery pack/case that adjust the air pressure inside of the receiver. L Applying a sticker over the ventilation hole blocks the air pressure adjustment, and may decrease the audio output level.
Page 9 Section POWER SUPPLY ■ About the Battery Case ……………………………………… 1-2 D Battery life …………………………………………………… 1-2 D About the battery replacement …………………………… 1-2 D About the safety use of battery case ……………………… 1-3 ■ Charging with a USB cable ………………………………… 1-4...
Page 10 POWER SUPPLY ■ About the Battery Case z Remove the battery case, then install three AA (LR6) size alkaline batteries, as described below. Be sure to observe the correct polarity. Battery case Install three AA (LR6) (Optional BP-293) size alkaline batteries D Battery life The approximate battery life (operating time) is approximately 4 hours under the following assumptions:...
Page 11 TIP: • The BP-293 meets IPX4 requirements for waterproof protection, only when it is attached to the IC-R30. • The batteries may seem to have low capacity when used in low temperatures. Keep the case warm in low temperature environments.
