Summary of Contents for Fortinet FortiTester 4000E
- Page 1 FortiTester 4000E QuickStart Guide...
- Page 2 Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’ s internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features or development, and circumstances may change such that any forward-looking statements herein are not accurate.
-
Page 3: Register For Support
Register for Support Register your Fortinet product to receive: • Technical Support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles menaces La reistrazione ti permette di usufruire di: •... -
Page 4: Box Includes
Box Includes FortiTester 4000E QuickStart Guide Quickstart Guide FortiTester 4000E Ethernet cable 2 Power cables 5 Rubber feet Console cable 6 M4 screws for sliding rails handles 2 Sliding rail handles 2 M6 rack mount screws 2 Sliding rails... -
Page 5: Installation
Installation Please read “Cautions and Warnings” prior to installing your device. The appliance can be placed on any flat surface, or mounted in a standard 19 inch rack. To install the appliance on a flat surface Ensure that the surface onto which the appliance is to be installed is clean, level, and stable and that there is at least 1.5in (3.8cm) of clearance on all sides to allow for adequate airflow. -
Page 6: Rail Installation
Do NOT place heavy objects on the unit. Rail Installation To install the FortiTester unit using the rail mounted kit: To remove the chassis (inner) member, pull the slide open, and then press the trigger down as shown on the drawing, and pull the chassis (inner) member out. - Page 7 Release safety lock before mounting Push the safety lock forward to secure 4. To mount the chassis into the cabinet, first ensure that the ball retainer is in the fully open position. Then, insert the chassis (inner) member into the cabinet member. When you push the chassis back into the cabinet, press the trigger down to release the slide from the locked position.
- Page 8 QSFP+ Transceivers To install the transceivers Caution: Transceivers are static sensitive Properly ground yourself with an ESD wrist strap or similar grounding device. devices. Use Carefully take the device out of the an ESD wrist packaging and check to ensure it is the strap or similar correct device.
- Page 9 Press the transceiver firmly into the cage socket with your thumb. Caution: Do not Verify that the transceiver is latched correctly by force the grasping the sides of the transceiver and trying to transceivers into pull it out without lowering the latch. If the the cage slots.
- Page 10 To remove the transceivers Ensure that you are properly grounded. If applicable, disconnect the fiber-optic cable from the transceiver connector and install a clean dust plug in the transceiver’s optical bores. Pull the latch out and down into the horizontal position.
-
Page 11: Basic Connections
Basic Connections Power Connection Plug the provided power cable into the rear of the appliance, and then into a grounded electrical outlet or a separate power source such as an uninterruptible power supply (UPS) or a power distribution unit (PDU). If the appliance has a redundant power supply, connect each power cable to a different power source. - Page 12 Web Browser with Ethernet cable MGMT Port To connect to the web UI Requires: Microsoft Internet Explorer 9 or higher, the latest version of Mozilla Firefox, Apple Safari 6, or Google Chrome. 1. Using the Ethernet cable, connect the appliance management port to your computer. 2.
- Page 13 Terminal Emulation Serial Port Console Port To connect to the CLI Requires: Terminal emulator such as PuTTY, Tera Term, or a terminal server. 1. Connect the appliance console port to the management computer using the provided console cable. 2. Start a terminal emulation program on the management computer, select the COM port, and use the following settings: Baud Rate: 9600 Data bits: 8...
- Page 14 MGMT Grounding Screws Dedicated Gigabit Ethernet Management Provides extra grounding. Port for system management. QSFP28 Port Reset Button 100 Gigabit Ethernet port for connection to your DUT. Reboots the system. Console Optional connection to the management computer. Provides access to the CLI.
- Page 15 Power Switch To turn the power ON/OFF. vice Guide Power Supply Warning Buzz Power Connections Reset Button 100-240V AC, 50-60 Hz, 5-3 A. Redundant Power Supply. To disable the power supply warning buzz.
- Page 16 SSL Accelerator – Power SSL Accelerator – Alarm : SSL accelerator is receiving power Green Off: SSL accelerator card is opera�ng normally Off: SSL accelerator is not powered on Red: SSL accelerator card failure MGMT Port Link/Activity MGMT Port Speed Flashing Amber : Transmitting &...
- Page 17 Power Supply Status Green: Power supply is opera�ng normally. Red: Power supply is not connected to power or mechanical failure. vice Guide...
- Page 18 Cautions and Warnings Environmental specifications Ambient operating temperature: 0C to 40C Rack Mount Instructions – The following or similar rack-mount instructions are included with the installation instructions: Instructions de montage en rack – Les instructions de montage en rack suivantes ou similaires sont incluses avec les instructions d'installation: Elevated Operating Ambient –...
- Page 19 Voluntary Control Council for Interference (VCCI) – Japan この装置は、クラスＡ機器です。この装置を住宅環境で使用すると電波妨害を引き起こすことがあります。この場合には使用者が適切な対策を講ず るよう要求されることがあります。ＶＣＣＩ－Ａ Bureau of Standards Metrology and Inspection (BSMI) – Taiwan 這是甲類的資訊產品。在居住的環境中使用時, 可能會造成射頻干擾。在這種情況下，使用者會被要求採取某些適當的對策。 The presence conditions of the restricted substance (BSMI RoHS table) are available at the link below: https://www.fortinet.com/bsmi China 此为 A 级产品。 在生活环境中，该产品可能会造成无线电干扰。这种情况下，可能需要用户对其采取切实可行的措施 。...
- Page 20 Create a support account, register and manage your products, download updates, firmware images and release notes, and create technical support tickets. https://support.fortinet.com Fortinet Document Library Up-to-date versions of Fortinet publications for the entire family of Fortinet products. http://docs.fortinet.com Training Services Course descriptions, availability, schedules, and location of training programs in your area.
