InFocus SP777 Lamp Replacement Update

Replacing the projection lamp

You can order new lamp modules from your dealer.
Turn off the projector and unplug the power cable.
1
Wait 60 minutes to allow the projector to cool thoroughly.
WARNINGS:
• To avoid burns, allow the projector to cool for at least 60 minutes before
you replace the lamp.
• Unplug the power cord before replacing the lamp.
• Do not drop the lamp module. The glass may shatter and cause injury.
• Do not touch the glass lamp screen. Fingerprints can obscure projection
sharpness.
• Be extremely careful when removing the lamp housing. In the unlikely
event that the lamp ruptures, small glass fragments may be generated.
The lamp module is designed to contain most of these fragments, but
use caution when removing it. Before replacing a ruptured lamp, clean
the lamp compartment and dispose of cleaning materials. Wash hands
after lamp replacement. This product has a lamp which contains a very
small amount of mercury. Dispose of it as required by local, state or fed-
eral ordinances and regulations. For more information see
www.eiae.org.
2 Remove the cable cover from the back of the projector by prying the
screw covers off, then removing the two screws (1 on each side).
turn off and unplug
the projector
pry the cable cover's
screw covers off
remove the screws
4
wait 60 minutes
