Fisher & Paykel DishDrawer DD602 Installation Instructions Manual
Hide thumbs
Also See for DishDrawer DD602:
- Installation instructions manual (25 pages) ,
- Installation instructions manual (24 pages) ,
- Service manual (47 pages)
Related Manuals for Fisher & Paykel DishDrawer DD602
Summary of Contents for Fisher & Paykel DishDrawer DD602
- Page 1 All manuals and user guides at all-guides.com DD602 (Prefinished) DD602I (Integrated) Models DD602 DD602I Part No. 599065/D...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Section General Information Preparation Product Specifications & Cavity Dimensions Options for Installing Multiple Products Electrical, Plumbing & Drainage Information Product Parts Additional Product Parts for Integrated DishDrawer Section Foot Slide Retainer Information Assembling the Foot Slide Retainer Securing the Foot Slide Retainer Section... -
Page 3: General Information
All manuals and user guides at all-guides.com SECTION 1 GENERAL INFORMATION STEP 1.1 PREPARATION NOTE TO THE INSTALLER WARNING NOTE TO THE CONSUMER Before installing the DishDrawer, remove the IMPORTANT house fuse or open the circuit breaker. WARNING Ensure all water connections are turned OFF. -
Page 4: Options For Installing Multiple Products
All manuals and user guides at all-guides.com STEP 1.3 OPTIONS FOR INSTALLING MULTIPLE PRODUCTS IMPORTANT Where the DishDrawer is installed under a counter top, it is recommended that bare wood surrounding the DishDrawer is sealed with an oil based paint or polyurethane to prevent possible steam damage. - Page 5 All manuals and user guides at all-guides.com PLUMBING - DRAINAGE OPTIONS WARNING Option 1 Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative if you are in doubt as to whether the appliance is properly grounded.
-
Page 6: Product Parts
All manuals and user guides at all-guides.com TOOLS NEEDED TO STEP 1.5 PRODUCT PARTS INSTALL DISHDRAWER • • • • • • • • • • • • • • (Integrated Models) • (Integrated Models) • (Integrated Models) Retainer (1) Lower Toe Kick (1) 14. -
Page 7: Foot Slide Retainer Information
All manuals and user guides at all-guides.com SECTION 2 FOOT SLIDE RETAINER INFORMATION STEP 2.1 ASSEMBLING THE FOOT SLIDE RETAINER IMPORTANT It is important that the Foot Slide Retainer is correctly 2.1.1 installed. It guides the feet back and holds the rear of the DishDrawer down to prevent it rocking forward when the drawers... -
Page 8: Securing The Foot Slide Retainer
All manuals and user guides at all-guides.com 2.1.5 IMPORTANT For Integrated product with door thickness other than ” (18mm), the 2.1.6 Foot Slide position must be adjusted forward or just back to allow for this difference. û ü Correct Incorrect STEP 2.2 SECURING THE FOOT SLIDE RETAINER IMPORTANT Check for any protrusions... -
Page 9: Fitting The Dishdrawer
All manuals and user guides at all-guides.com SECTION 3 FITTING THE DISHDRAWER STEP 3.1 CONNECTING THE SERVICES 3.1.1 WARNING Ensure the edges of the Services Hole are smooth or covered. (See Step 1.2 - Product Specifications & 3.1.2 Cavity Dimensions.) If the Services Hole is through a metal partition, the hole WATER SUPPLY. -
Page 10: X94; (610Mm X 876Mm) Cavity
All manuals and user guides at all-guides.com 3.1.8 WARNING The Product must not be plugged in at this stage. DO NOT WARNING If permanently 3.1.9 connecting, ensure power is isolated. STEP 3.2 FLEXIBLE EXTRUSION ATTACHMENT FOR 24” BY 34 ” (610mm x 876mm) CAVITY 3.2.1 Wiring, Plumbing and Services should be... -
Page 11: Adjusting The Feet
All manuals and user guides at all-guides.com STEP 3.3 ADJUSTING THE FEET IMPORTANT 3.3.1 The DishDrawer must be levelled so that each corner is at least within ” (3mm) of level. WARNING The DishDrawer should not support any part of 3.3.2 the kitchen cabinets. -
Page 12: Securing The Dishdrawer
All manuals and user guides at all-guides.com STEP 3.5 SECURING THE DISHDRAWER 3.5.1 3.5.2 3.5.3 3.5.4 Page DD_11... -
Page 13: Prefinished Toe Kick Installation
All manuals and user guides at all-guides.com PREFINISHED TOE KICK INSTALLATION SECTION 4 STEP 4.1 SETTING THE UPPER TOE KICK HEIGHT 4.1.1 IMPORTANT Ensure that the Transit Packer located beneath the upper Toe Kick has been removed. 4.1.2 4.1.3 STEP 4.2 TRIMMING THE LOWER TOE KICK 4.2.1 °... -
Page 14: Trimming The Toe Kick Pins
All manuals and user guides at all-guides.com 4.2.2 IMPORTANT Before cutting the Lower Toe Kick, ensure the Toe Kick is positioned on a wooden chopping board to avoid damage to surrounding area. 4.2.3 IMPORTANT 4.2.4 Ensure the Toe Kick Pins are positioned on a wooden chopping board to avoid damage to... -
Page 15: Adjusting The Upper Toe Kick
All manuals and user guides at all-guides.com 4.3.3 Orientate the Lower Toe Kick so that the arrow points upwards. Toe Kick Brace 4.3.4 STEP 4.4 ADJUSTING THE UPPER TOE KICK 4.4.1 Upper Toe Kick Lower Toe Kick 4.4.2 Page DD_14... -
Page 16: Integrated Drawer Front & Toe Kick Dimensions
All manuals and user guides at all-guides.com INFORMATION FOR CABINET MAKER FOR SECTION 5 INTEGRATED DISHDRAWER STEP 5.1 INTEGRATED DRAWER FRONT & TOE KICK IMPORTANT DIMENSIONS 5.1.1 Recommended Drawer Front thickness for Use the following diagrams to work out the dimensions for the Integrated Panels for Drawer Integrated products is Fronts and Toe Kicks.. - Page 17 All manuals and user guides at all-guides.com IMPORTANT Check top and bottom measurements of cavity and use the smaller dimension to ensure that the drawer fronts and toe kicks will fit. Drawer Front Air Flow Chamfer Page DD_16...
- Page 18 All manuals and user guides at all-guides.com 5.1.2 IMPORTANT Control Badge Position All marking out should be done on the back surface of the Drawer Front. IMPORTANT When mounting the handle, ensure fastenings do not protrude beyond the back surface of the Drawer Front.
- Page 19 All manuals and user guides at all-guides.com 5.1.4 Drawer Front Mounting Bracket Nut Holes WARNING Use of a depth gauge is recommended when drilling out holes for Drawer Front Mounting Panel. CAUTION Ensure the drill does not damage the face of the Drawer Front.
-
Page 20: Integrated Drawer Front Installation
All manuals and user guides at all-guides.com SECTION 6 INTEGRATED DRAWER FRONT INSTALLATION STEP 6.1 CHANGING THE INTEGRATED BADGE ENCLOSURE IMPORTANT To avoid electric shocks and damage to electronic components, the integrated badge should be disconnected from the DishDrawer when changing the badge enclosure. -
Page 21: Fitting The Badge, Handle & Mounting Panel To The Drawer Front
All manuals and user guides at all-guides.com STEP 6.4 FITTING THE BADGE, HANDLE & MOUNTING WARNING PANEL TO THE DRAWER FRONT Care should be taken in the following steps. 6.4.1 CAUTION 6.4.2 Take care not to damage front surface of panel. 6.4.3 Ensure all cuts are straight and care is taken... -
Page 22: Fitting The Drawer Front Panels To The Dishdrawer
All manuals and user guides at all-guides.com STEP 6.5 FITTING THE DRAWER FRONT PANELS TO THE DISHDRAWER Use a small amount of liquid soap along the lip of the seal to assist the 6.5.1 Drawer Front to slide on easily against the seal. WARNING Ensure the product is not plugged in. -
Page 23: Dishdrawer Toe Kick Information
All manuals and user guides at all-guides.com DISHDRAWER TOE KICK INFORMATION SECTION 7 STEP 7.1 INTEGRATED TOE KICK INSTALLATION Upper Toe Kick 7.1.1 7.1.2 7.1.3 Lower Toe Kick 7.1.4 Toe Kick 7.1.5 7.1.6 7.1.7 7.1.8 Step 4.4 Page DD_22... -
Page 24: Final Checks
All manuals and user guides at all-guides.com SECTION 8 FINAL CHECKS STEP 8.1 INSTALLATION WET TEST STEP 8.2 TROUBLESHOOTING LEAVE ALL LITERATURE WITH THE CUSTOMER. Page DD_23...
