TABLE OF CONTENTS

I General ................................................................................................ 51
I Memory channel edit ........................................................................... 51
I Program scan channel edit .................................................................. 55
I EASY mode channel edit ..................................................................... 55
I Program scan or EASY mode channel edit ......................................... 57
9 SET MODE ....................................................................... 59 - 62
I General ............................................................................................... 62
10 OTHER FUNCTIONS ........................................................ 63 - 71
I Low battery indicator ........................................................................... 63
I AFC function ........................................................................................ 63
I Monitor function ................................................................................... 64
I Lock function ....................................................................................... 64
I ATT function ........................................................................................ 65
I NB/ANL function .................................................................................. 65
I Sleep timer .......................................................................................... 66
I User TS setting .................................................................................... 66
I Memory search function ...................................................................... 67
I Auto mode and TS function ................................................................. 69
I Resetting the CPU ............................................................................... 70
I Data cloning ........................................................................................ 71
11 ALPHANUMERIC KEY ASSIGNMENT ................................... 72
12 CONTROL COMMANDS .................................................. 73 - 74
I General ................................................................................................ 73
I Data format .......................................................................................... 73
I Command table ................................................................................... 73
13 TROUBLESHOOTING ...................................................... 75 - 76
14 SPECIFICATIONS ................................................................... 77
15 OPTIONS ................................................................................. 78

OPERATING THEORY

Electromagnetic radiation which has frequencies of 20,000
Hz (20 kHz*) and above is called radio frequency (RF) energy
because it is useful in radio transmissions. The IC-R10 re-
ceives RF energy from 0.5 MHz to 1300 MHz* and converts it
into audio frequency (AF) energy which in turn actuates a
loudspeaker to create sound waves. AF energy is in the
range of 20 to 20,000 Hz.
*kHz is an abbreviation of kilohertz or 1000 hertz, MHz is abbreviation
of megahertz or 1,000,000 hertz, where hertz is a unit of frequency.

OPERATING NOTES

The IC-R10 may receives its own oscillated frequency, result-
ing in no reception or only noise reception, on some frequen-
cies.
The IC-R10 may receive interference from extremely strong
signals on different frequencies or when using an external
high-gain antenna.
