WARNING : CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/
electronic and/or plastic (Where applicable) components may also contain traces of chemicals
found by the California Health and Welfare Agency (and possibly other entities) to cause cancer
and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR
MOUTH FOR ANY REASON WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not
inhale solder fumes or expose eyes to solder/flux vapor!
If you come in contact with solder or components located inside the enclosure of this product,
wash your hands before handling food.
EG
011730
ELECTRIC GUITAR
AES420
SERVICE MANUAL
CONTENTS
OVERALL ASSEMBLY ............................................................. 2
CIRCUIT DIAGRAM .................................................................. 4
SPECIFICATIONS ..................................................................... 4
WIRING ..................................................................................... 4
Copyright (c) Yamaha Corporation. All rights reserved. PDF-K28
HAMAMATSU, JAPAN
'04.04
Advertisement
Related Manuals for Yamaha AES420
Summary of Contents for Yamaha AES420
- Page 1 If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling food. CONTENTS OVERALL ASSEMBLY ............. 2 CIRCUIT DIAGRAM ..............4 SPECIFICATIONS ..............4 WIRING ..................4 011730 HAMAMATSU, JAPAN Copyright (c) Yamaha Corporation. All rights reserved. PDF-K28 ’04.04...
- Page 2 AES420 OVERALL ASSEMBLY Tailpiece Assembly: Wrap Around Chrome (QC825700) E02 E03 E01 E03 E04 E05 E04 E05 The nut in service parts is formed with some string grooves. However, you need to make fine adjustments of the grooves to fit on the string to be used when replacing the nut.
- Page 3 AES420 PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY AES420 総 組 立 Body 胴 本 体 QC825500 Tuning Machine Assembly KSSG-100-D02-R (Chrome) 1,2,3 Strings 糸 巻 Ａ ｓ ｓ ｙ Tuning Machine Assembly KSSG-100-D02-L (Chrome)
- Page 4 AES420 SPECIFICATIONS CIRCUIT DIAGRAM STANDARD SPECIFICATIONS Scale Length ......628.0mm FRONT PICKUP Body-Neck Construction ..Set Neck Length ........995.8mm Width ......... 343.6mm Net Weight ........ 3.4kg PICKUP COLOR SWITCH Body (3 position Toggle) BL ..........Black MASTER MASTER VOLUME RM ..........
