WARNING : CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD.
In addition, other electrical/electronic and/or plastic (Where appli-
cable) components may also contain traces of chemicals found
by the California Health and Welfare Agency (and possibly other
entities) to cause cancer and/or birth defects or other reproduc-
tive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR
PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REASON
WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your
skin! When soldering, do not inhale solder fumes or expose eyes
EG
011787
ELECTRIC GUITAR
AES620HB
SERVICE MANUAL
CONTENTS
Overall Assembly .................................................... 2
Circuit Diagram ......................................................... 4
Specifications ............................................................ 4
Wiring ............................................................................ 4
Copyright (c) Yamaha Corporation. All rights reserved. PDF-K297
BLD
HAMAMATSU, JAPAN
OVS
'05.08
Advertisement
Related Manuals for Yamaha AES620HB
Summary of Contents for Yamaha AES620HB
- Page 1 WHAT SO EVER! Avoid prolonged, unprotected contact between solder and your SPECIFICATIONS ............4 skin! When soldering, do not inhale solder fumes or expose eyes WIRING ................4 011787 HAMAMATSU, JAPAN Copyright (c) Yamaha Corporation. All rights reserved. PDF-K297 ’05.08...
- Page 2 AES620HB OVERALL ASSEMBLY Bridge Assembly: Ping Well TP6-05Y (QC656000) E09b E09f E09c E09d E02 E03 E01 E03 E04 E05 E04 E05 E09e E06 E07 E09a The nut in service parts is formed with some string grooves. However, you need to make fine adjustments of the grooves to fit on the string to be used when replacing the nut.
- Page 3 AES620HB PART NO. DESCRIPTION REMARKS REF NO. QTY RANK OVERALL ASSEMBLY AES620HB Body QC770400 Tuning Machine Assembly GROVER 1,2,3 Strings Chrome QC770500 Tuning Machine Assembly GROVER 4,5,6 Strings Chrome Chrome with Tuning Machine Ass'y Washer Chrome with Tuning Machine Ass'y...
- Page 4 AES620HB SPECIFICATIONS CIRCUIT DIAGRAM STANDARD SPECIFICATIONS Scale Length ......628.0mm FRONT FRONT Body-Neck Construction ... Set-in PICKUP VOLUME Length ........995.8mm PICKUP SWITCH Width ........343.6mm (3 position Toggle) Net Weight ......3.2kg MASTER TONE OUTPUT COLOR (Head/Neck/Body Top/Body Back) BLD ........
