Hoshizaki F-800MAH Instruction Manual

Modular flaker
Hide thumbs Also See for F-800MAH:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Reliability is a
beautiful thing
TM
INSTRUCTION MANUAL
MODULAR FLAKER
F-800MAH(-C)
F-800MWH(-C)
ISSUED:
FEB. 28, 2001
REVISED: DEC. 11, 2003

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki F-800MAH

Summary of Contents for Hoshizaki F-800MAH

  • Page 1 Reliability is a beautiful thing MODULAR FLAKER INSTRUCTION MANUAL F-800MAH(-C) F-800MWH(-C) ISSUED: REVISED: DEC. 11, 2003 FEB. 28, 2001...
  • Page 2 HOSHIZAKI provides this manual primarily to assist qualified service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call or write to the HOSHIZAKI Technical Support Department for assistance.

  • Page 3: Table Of Contents

    • Keep this manual with the icemaker for later reference. I. SPECIFICATIONS ... 4 1. NAMEPLATE RATING ... 4 [a] F-800MAH, F-800MAH-C (Air-cooled) ... 4 [b] F-800MWH, F-800MWH-C (Water-cooled) ... 5 2. DIMENSIONS/CONNECTIONS ... 6 [a] F-800MAH, F-800MAH-C (Air-cooled) ... 6 [b] F-800MWH, F-800MWH-C ...

  • Page 4: Specifications

    This Nameplate is located on the upper right hand side of rear panel. We reserve the right to make changes in specifications and design without prior notice. NOTE: Only the “MODEL NUMBER” is replaced for F-800MAH-C. HOSHIZAKI ICE MAKER HOSHIZAKI ICE MAKER...

  • Page 5: [B] F-800Mwh, F-800Mwh-C (Water-Cooled)

    We reserve the right to make changes in specifications and design without prior notice. NOTE: Only the “MODEL NUMBER” is replaced for F-800MWH-C. HOSHIZAKI ICE MAKER HOSHIZAKI ICE MAKER HOSHIZAKI ICE MAKER HOSHIZAKI ICE MAKER...

  • Page 6: Dimensions/Connections

    2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS [a] F-800MAH, F-800MAH-C [a] F-800MAH, F-800MAH-C [a] F-800MAH, F-800MAH-C [a] F-800MAH, F-800MAH-C [a] F-800MAH, F-800MAH-C Unit = inches [mm.]...

  • Page 7: [B] F-800Mwh, F-800Mwh-C

    [b] F-800MWH, F-800MWH-C [b] F-800MWH, F-800MWH-C [b] F-800MWH, F-800MWH-C [b] F-800MWH, F-800MWH-C [b] F-800MWH, F-800MWH-C Unit = inches [mm.]...

  • Page 8: [C] With Storage Bin

    [c] WITH STORAGE BIN [c] WITH STORAGE BIN [c] WITH STORAGE BIN [c] WITH STORAGE BIN [c] WITH STORAGE BIN Unit = inches [mm.]...

  • Page 9: Installation And Operating Instructions

    6) See the Nameplate on the Rear Panel, and check that your voltage supplied corresponds with the voltage specified on the Nameplate. 7) This icemaker needs a storage bin. The recommended storage bin is HOSHIZAKI ICE STORAGE BIN, Model B-300 series.

  • Page 10: Location

    3. LOCATION 3. LOCATION 3. LOCATION 3. LOCATION 3. LOCATION This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F to +100°F; Normal operating water temperature should be within +45°F to +90°F. Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect production capacity.

  • Page 11: Electrical Connection

    If adjustment is desired, please contact an authorized Hoshizaki service company. 8) Replace the Top Panel and the Front Panel in their correct positions, and secure the Front Panel by a screw.

  • Page 12: Water Supply And Drain Connections

    6. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 4 6. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 4 6. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 4 6. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 4 6.
  • Page 13 F-800MAH, F-800MAH-C F-800MWH, F-800MWH-C Fig. 4 Fig. 4 Fig. 4 Fig. 4 Fig. 4...

  • Page 14: Final Check List

    7. FINAL CHECK LIST 7. FINAL CHECK LIST 7. FINAL CHECK LIST 7. FINAL CHECK LIST 7. FINAL CHECK LIST 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F and the water temperature within +45°F to +90°F all year around? 3) Is there at least 6"...

  • Page 15: Start Up

    8. START UP 8. START UP 8. START UP 8. START UP 8. START UP 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the Compressor.

  • Page 16: Preparing The Icemaker For Long Storage

    9. PREPARING THE ICEMAKER FOR LONG STORAGE - See Fig. 5 9. PREPARING THE ICEMAKER FOR LONG STORAGE - See Fig. 5 9. PREPARING THE ICEMAKER FOR LONG STORAGE - See Fig. 5 9. PREPARING THE ICEMAKER FOR LONG STORAGE - See Fig. 5 9.

  • Page 17: Cleaning And Maintenance Instructions

    1. CLEANING INSTRUCTIONS 1. CLEANING INSTRUCTIONS 1. CLEANING INSTRUCTIONS 1. HOSHIZAKI recommends cleaning this unit at least once a year. More frequent cleaning, however, may be required in some existing water conditions. 2. To prevent injury to individuals and damage to the icemaker, do not use ammonia type cleaners.
  • Page 18 <STEP 2> Use the cleaning solution to remove lime deposits in the water system. 1) Turn off the power supply. 2) Close the Water Supply Line Shut-off Valve. 3) Remove all ice from the Storage Bin. 4) Remove the Front Panel and the Top Panel. 5) Move the Flush Switch to the “FLUSH”...
  • Page 19 20) Turn off the power supply when the Gear Motor starts. 21) Drain out all water from the water line. See 4) through 7). <STEP 3> Use 3/4 gal. of the sanitizing solution to sanitize the icemaker. 1) Close the Water Supply Line Shut-off Valve. 2) Remove the Control Water Valve by releasing the Fitting Nut.
  • Page 20 <STEP 4> Use the sanitizing solution to sanitize removed parts. 1) Remove the Thumbscrew securing the Bin Control Switch on the Chute Assembly. 2) Remove the Band connecting the Spout with the Chute Assembly, and take out the Chute Assembly from the icemaker. 3) Remove the Gasket at the bottom of the Ice Chute and another at the Spout.
  • Page 21 14) Turn off the power supply after 30 minutes. 15) Pour warm water into the Storage Bin to melt all ice, and then clean the Bin Liner with the solution. 16) Flush out any solution from the Storage Bin. 17) Turn on the power supply and start the automatic icemaking process. 1.

  • Page 22: Maintenance Instructions

    More frequent inspection and maintenance are recommended. Consult with your local distributor about inspection and maintenance service. To obtain the name and phone number of your local distributor, call Hoshizaki Technical Support at 1-800-233-1940 in the USA. IMPORTANT IMPORTANT...
  • Page 23 1) Stainless Steel Exterior To prevent corrosion, wipe the exterior occasionally with a clean and soft cloth. Use a damp cloth containing a neutral cleaner to wipe off oil or dirt build up. 2) Storage Bin and Scoop • Wash your hands before removing ice. Use the plastic scoop provided (Accessory). •...
  • Page 24 HOSHIZAKI HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269...

This manual is also suitable for:

F-800mah-cF-800mwhF-800mwh-c
