- Page 1 Introduction Safety notes Mounting SIVACON Standards and references Distribution systems Installation and maintenance Harmonics instructions for Power Factor Correction (PFC) capacitors Overpressure disconnector Installation Manual Overcurrent / short circuit protection Maintenance Appendix 05/2022 L1V30884033A...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Table of contents Introduction ............................5 About this manual ....................... 5 Technical Support ........................ 6 Safety notes ............................7 General safety notes for installation and operation ............... 7 Storage and operation conditions..................8 Ambient temperature......................9 Mounting ............................. 11 Mounting the capacitors ....................11 Cooling space for capacitors.................... - Page 4 Table of contents Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 5: Introduction
Note Disregarding the guidelines in this manual can result in operational failure, bursting and fire. In case of doubt, contact your local Siemens sales organization or distributor for assistance. Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A... -
Page 6: Technical Support
Introduction 1.2 Technical Support Technical Support You can find further support on the Internet at: Technical Support (https://www.siemens.com/support-request) Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A... -
Page 7: Safety Notes
Safety notes General safety notes for installation and operation • Ensure you are using the right capacitor type for your application. Please refer to the Siemens product installation manual and product manual for proper selection of capacitors. Please contact Siemens for any assistance required in selection. -
Page 8: Storage And Operation Conditions
Safety notes 2.2 Storage and operation conditions Storage and operation conditions Do not use or store capacitors in a corrosive atmosphere, especially where chloride gas, sulfide gas, acid, alkali, salt or similar substances are present. In a dusty environment, regular maintenance and cleaning, especially of the terminals, is required to avoid a conductive path between phases and/or phases and ground. -
Page 9: Ambient Temperature
Safety notes 2.3 Ambient temperature Ambient temperature The ambient temperature category for most standard types is–40 / D. This means a max. temperature of 55 °C, an average temperature over 24 hours of 45 °C, and the average temperature in one year should not exceed 35 °C. The maximum casing temperature of 60 °C must not be exceeded. - Page 10 Safety notes 2.3 Ambient temperature Note Only qualified personnel are permitted to install, commission or service this device. Wear the prescribed protective clothing. Observe the general equipment regulations and safety regulations for working with high-voltage installations (e.g. DIN VDE, NFPA 70E as well as national or international regulations).
-
Page 11: Mounting
Mounting Mounting the capacitors Figure 3-1 Capacitor overview Mounting positions Capacitors installed in a cabinet should be placed on the bottom to ensure the lowest stress temperature possible. WARNING The use of damaged devices may result in death, serious injury, or property damage. Do not install the capacitor in case of dents deeper than 0.5 mm. - Page 12 Mounting 3.1 Mounting the capacitors The PhaseCap Premium, PhaseCap Compact and PhaseCap Energy+ (Height of capacitor ≤ 224 mm) capacitor series may be mounted in the vertical or horizontal position. Note The pictures depicted above are for illustration purposes only. Actual sample will be as per MLFB type.
-
Page 13: Cooling Space For Capacitors
Mounting 3.2 Cooling space for capacitors Cooling space for capacitors Make sure that sufficient cooling space is provided: • A minimum distance of 20 mm between the capacitors is necessary to maintain sufficient cooling. • Keep at least 20 mm space above the capacitor and do not attach any mounting components at the crimp or on top. -
Page 14: Fixing Threaded Bottom Stud
Mounting 3.3 Fixing threaded bottom stud Fixing threaded bottom stud The threaded mounting stud is at the bottom of the capacitor: Fixing The threaded bottom stud must be fastened with certain specified torques: • PhaseCap, PhaseCap Compact, PhaseCap Energy +, PhaseCap HD, DeltaCap: M12 bottom stud: torque 10 Nm. -
Page 15: Grounding
Mounting 3.4 Grounding Grounding The M12/M8 bottom stud is used for grounding. Connect it to the ground by cable, or connect the capacitor to any other conductive item which is connected to the ground. Note Connect the capacitor case to ground. Suitable connectors have to penetrate existing layers of lacquer to ensure good, constant conductivity and sufficient current carrying capabilities. -
Page 16: Connecting
Mounting 3.5 Connecting Connecting When connecting, avoid bending cable lugs or cables, or the use of other forms of mechanical force on the terminals. Otherwise, leakage could disable the safety device (overpressure disconnector). Provide sufficient mechanical strain relief for the cable. Ensure firm fixing of terminals, fixing torque to be applied as per individual specification. - Page 17 Mounting 3.5 Connecting Note Capacitor may be damaged. Do not exceed the maximum allowable current. Use an appropriate screw driver. Capacitors are supplied with partially engaged terminal screws. • PhaseCap Premium, DeltaCap, PhaseCap Compact, PhaseCap Energy+ except terminal type F and PhiCap: 5.5 x 1/Ph2/Pz2 type •...
-
Page 18: Discharging Of Capacitors
PFC equipment (phase opposition). Siemens discharge resistors are designed to discharge capacitors down to 75 V or less within 180 seconds (some types within 90 seconds; please refer to the specific data sheet). - Page 19 Mounting 3.6 Discharging of capacitors Table 3-1 Discharge resistor and discharge module External discharge resistor Push on discharge resistors Table 3-2 Different discharge resistors Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 20: Inrush Current Limitation
Mounting 3.7 Inrush current limitation Inrush current limitation Switching LV PFC capacitors can cause high inrush currents of more than 200 times the rated current, especially when they are connected in parallel to others that are already energized. This may cause additional stress to contactors as well as to capacitors and reduce their life cycle. Inrush currents have a negative effect on power quality, e.g. -
Page 21: Standards And References
5000 switching operations PhaseCap Compact up to 10000 switching operations PhaseCap Energy+ up to 15000 switching operations Before considering a higher number of switching operations, please contact Siemens. Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A... - Page 22 Standards and references 4.1 IEC 60831 Standard and Reference Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 23: Harmonics
Harmonics Harmonics are voltages and currents with frequencies that are different from a 50 Hz or 60 Hz power supply frequency. Harmonics result from the operation of electrical loads with non-linear voltage-current characteristics. They are mainly caused by loads operated with modern electronic devices, such as converters, electrical drives, welding machines and uninterruptible power supplies (UPS). - Page 24 Harmonics Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 25: Overpressure Disconnector
Overpressure disconnector Electrical components do not have unlimited life expectancies; this also applies to self-healing capacitors. As polypropylene-type capacitors seldom produce a pronounced short circuit, HRC fuses or circuit breakers alone do not offer sufficient protection. All capacitors of the PhaseCap Premium, PhaseCap Compact, PhaseCap Energy+, PhaseCap HD, DeltaCap and PhiCap series are consequently fitted with a disconnector that responds to overpressure. - Page 26 Overpressure disconnector Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 27: Overcurrent / Short Circuit Protection
Overcurrent / short circuit protection Overcurrent / short circuit protection HRC fuses or moulded case circuit breakers for short circuit protection have to be used. Short circuit protection equipment and connection cable should be dimensioned to handle the 1.5 times rated current of the capacitor permanently. •... - Page 28 Overcurrent / short circuit protection 7.1 Overcurrent / short circuit protection Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 29: Maintenance
Maintenance Disposal of waste electronic equipment Disposal of waste electronic equipment Waste electronic equipment must not be disposed of as unsorted municipal waste, e.g. household waste. When disposing of waste electronic equipment, the current local national/ international regulations must be observed. CAUTION Maintenance Disregarding the following measures may result in severe operation failures, bursting and fire. - Page 30 Maintenance 8.1 Disposal of waste electronic equipment Installation and maintenance instructions for Power Factor Correction (PFC) capacitors Installation Manual, 05/2022, L1V30884033A...
-
Page 31: Appendix
Appendix Connection cable cross section, HRC fuse rating Recommendations to VDE 0100 for fusing and cable cross sections for three phase power capacitors are listed below. VDE 0100 recommendations Cross-section values mentioned below are guideline values valid for operation under normal conditions and at an ambient temperature of 40 °C. - Page 32 Appendix Vibration resistance The capacitor resistance to vibration corresponds to IEC 68, part 2-6. The following values apply to the capacitor alone. Test conditions Max. test conditions Test duration Frequency range 10 ... 55 Hz max. 0,7 g Displacement amplitude 0,75 mm The connections and the terminals may influence the vibration properties.
- Page 33 For these reasons, it is always ultimately incumbent on the customer to check and decide whether a Siemens product with the properties described in the product specification is suitable for use in a particular customer application.
