ION Audio
iCUE
[iCUE]
Service Manual
v1.0
2012.07.24
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH ION AUDIO.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by ION Audio. If you are not the authorized, intended
recipient, you are hereby notified that any review, dissemination, distribution or duplication of this
document is strictly prohibited. If you are not authorized, please contact ION Audio and destroy
all copies of this document. You may contact ION Audio at support@ionaudio.com.
Copyright ION Audio
Confidential
ION Audio Service Manual
Advertisement
Related Manuals for ION ICUE
Summary of Contents for ION ICUE
- Page 1 The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by ION Audio. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited.
- Page 2 As the owner of the copyright to the Manual, ION Audio does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of ION Audio.
- Page 3 REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ION AUDIO SERVICE CENTER WILL VOID THE ION AUDIO WARRANTY. PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO...
- Page 4 The product is exposed to water or excessive moisture, c. The AC power supply plug or cord is damaged, d. The product shows an inappropriate change in performance or does not operate normally, or e. The enclosure of the product has been damaged. Confidential ION Audio Service Manual...
- Page 5 This product shares the design of Numark's Total Control [KC0]. Confidential ION Audio Service Manual...
-
Page 6: Specification
SERVICE MANUAL MODEL:TOTAL CONTROL SPECIFICATION FUNCTION Scratch Whrrld……………………………..Works for setting cue point and scratching only. LOOP………………………………………automatically loops a given time (like Pioneer safety loops). Treble/Middle Bass…………………………EQ control. Push function of knob allows instant frequency kill. Crossfader…………………………………..mixes between channels. Parameter Knob……………………………..assignable to adjust effects. Has push function for added control. SYNC………………………………………..Forces BPM alignment to opposing deck. -
Page 7: Disassembly Procedures
DISASSEMBLY PROCEDURES (A) REMOVE 8 PCS OF SCREW TO DISCONNECT FRONT PANEL AND REAR PANEL. Fig.1 (A). REMOVE 6 PCS OF SCREW TO DISCONNECT BOTTOM CHASSIS. Fig.2... - Page 8 DISASSEMBLY PROCEDURES (A) REMOVE 5 PCS OF VR KNOB. (B) REMOVE 1 PC OF NAME PLATE. REMOVE 6 PCS OF SCREW FROM PITCH FADER AND CROSS FADER. (D) DISCONNECT 3 PCS OF CONNECTOR TO REMOVE PITCH FADER PCB AND CROSS FADER PCB Fig.3 DISASSEMBLY PROCEDURES (A) REMOVE 3 PCS OF SCREW FROM POWER PCB.
- Page 9 DISASSEMBLY PROCEDURES (A) REMOVE 18 PCS OF SCREW FROM MAIN PCB. (B) DISCONNECT 3 PCS OF CONNECTOR TO REMOVE MAIN PCB. Fig.5...
- Page 13 KC0MAR01 BOM DESCRIPTION LEVEL BAPS-W006 KNOB BAW-0973-Y-01-N WASHER CA040218002 USB CABLE CB300WMAR11 CD SLEEVE CB300WMAR12 CD SLEEVE CN0420000803 4P CONNECTOR (80mm) CN0520001003 5P CONNECTOR (100mm) CN1420001701 14P CONNECTOR (170mm) CN1425401002 14P CONNECTOR (100mm) ERE73 E RING 3MM LA62GMN37 DATE LABEL LAC22MAR204 SEARAL NO.
- Page 14 JK0SCU201RFNO USB CONNECTOR JKDJ-0702B-020 DC CONNECTOR JW5206T JUMP WIRE JMP1~4,7,8 PC06C009 POWER PCB RS00018J05 RESISTOR 0 (SMD) RS10218J05 RESISTOR 1K (SMD) RS10318J05 RESISTOR 10K (SMD) R35,85 RS51118J05 RESISTOR 510 (SMD) TE622000501 5P CONNECTOR (J5) TE952541401 14P CONNECTOR (J1) UHDLW5BTN501SQ2 CHOKE COIL TWPC06C01101 MAIN PCB ASS'Y TWPC06C011A01...
- Page 15 TWPC06C011C01 SENSOR PCB ASS'Y AL2-56-5592 TRANSIST0R 2SC5592 Q3,4 DIRPI-352 SENSOR SEN3,4 RS10318J05 RESISTOR 10K (SMD) R96,117 RS22318J05 RESISTOR 22K (SMD) R113,115 RS33118J05 RESISTOR 330 (SMD) R112,114 RS56118J05 RESISTOR 560 (SMD) R106,107 TE622000401 4P CONNECTOR (J2) TWPC06C011D01 PITCH PCB ASS'Y TE622000401 4P CONNECTOR (J3) VRS10304508...
- Page 16 MBRS140LT3 MBRS140LT3...
- Page 21 REVISION RECORD +3V3 ECO NO: APPROVED: DATE: Above to be as close to U7 as posible - follow UM131 layout exactly CB201209T-102Y 0.1uF 4.7uF,25V 40MHz +3V3 E1UAB18-40.000M 22 ohm 2.2uH VREF +3V3 0 ohm 20pF 0.01uF 20pF 4.7uF,25V 0.1uF +3V3 100k AVCC VREF...
- Page 22 REVISION RECORD ECO NO: APPROVED: DATE: R104 SEN1 R109 2SC5592 330 ohm RPI-352 R108 R105 SEN2 R116 2SC5592 R111 +3V3 330 ohm RPI-352 R110 To Scratch Wheel Encoders SCRATCH_ENC2_VCC3_LOCAL SCRATCH_ENC2_A_LOCAL ENCODER0 SCRATCH_ENC2_B_LOCAL ENCODER1 SCRATCH_ENC2_GND_LOCAL +3V3 R106 SCRATCH_ENC1_VCC3_LOCAL SCRATCH_ENC1_A_LOCAL ENCODER2 SEN3 R117 SCRATCH_ENC1_B_LOCAL ENCODER3...
- Page 23 It is an option to use VREF for POTS/faders REVISION RECORD POT_HIGH +3V3 ECO NO: APPROVED: DATE: CB201209T-102Y VREF POT_HIGH 22uF 0.1uF 0.1uF 10 ohm Rotary1 Rotary2 0.1uF 22uF 0.1uF PITCH FADER CH1 FADER5 FADER4 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF PF1_GND Place close to POT 0.1uF...
- Page 24 REVISION RECORD +3V3 ECO NO: APPROVED: DATE: 74HC4051 OUT/IN POT_360_L +3V3 Place capacitors close to micro 74HC4051 1000pF POT_SELECT0 POT_SELECT1 POT_SELECT2 OUT/IN POT1 POT_FADER_BANK1 POT2 POT3 POT4 POT5 POT6 POT7 Place capacitors close to micro POT8 +3V3 1000pF POT_SELECT0 POT_SELECT1 74HC4051 POT_SELECT2 OUT/IN...
-
Page 25: Switch Matrix
+3V3 REVISION RECORD ECO NO: APPROVED: DATE: SW_COL7 SW_COL6 SWITCH MATRIX: SW_COL5 SW_COL4 - 2x5 Transport SW_COL3 SW_COL2 (play, pause, cue, loop, loop cue) SW_COL1 SW_COL0 - 2x4 Soft Button - 2x2 Pitch Bend - 2x1 Cue Source MMBD4148 MMBD4148 MMBD4148 MMBD4148 MMBD4148... - Page 26 REVISION RECORD ECO NO: APPROVED: DATE: POT_HIGH 0.1uF 0.1uF 22uF P8-A P9-A POT2 Treble2 0.1uF 0.1uF POT1 Treble1 0.1uF 0.1uF 22uF 0.1uF 0.1uF P15-A P16-A Mid2 POT4 POT8 MSTR VOL POT7 0.1uF 0.1uF 0.1uF 0.1uF POT3 CUE VOL Mid1 Copyright (c) 2006 Akai Digital Ltd. 0.1uF 0.1uF 22uF...
- Page 27 +3V3 +3V3 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 1 OE LED_EN 11 LE LED_BANK0 LED16 LED5 LED15 LED4 LED25 LED1 LED3 LED11 3 D0 DATA0 4 D1 DATA1 7 D2 DATA2 8 D3 DATA3...
- Page 28 +3V3 +3V3 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 240 ohm 1 OE LED_EN 11 LE LED_BANK2 LED2 LED8 LED12 LED26 LED6 LED7 LED17 LED18 3 D0 DATA0 4 D1 DATA1 7 D2 DATA2 8 D3 DATA3...
