- Page 1 IBM ioMemory VSL 3.2.6 HIGH IOPS HARDWARE INSTALLATION GUIDE DECEMBER 11, 2013...
-
Page 2: Table Of Contents
Table of Contents Table of Contents IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6 Legal Notices FCC CFR 47 Part 15 Class A device: Safety Information Introduction Overview Software Compatibility Compatible Software (Driver) Compatible Operating Systems IBM Adapters... - Page 3 Sufficient System Memory (RAM) Firmware Requirements In the Box Installing the Device Installation Instructions Installing the Half-Height Bracket Installing Power Cables Installing the Cable WEEE Advisement Disposal and Acknowledgment Determining Manufacture Date IBM Support IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6...
-
Page 4: Ibm High Iops Hardware Installation Guide For Iomemory Vsl
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6... -
Page 5: Safety Information
2. First, remove power cords from outlet. 3. Attach signal cables to connectors. 3. Remove signal cables from connectors. 4. Attach power cords to outlet. 4. Remove all cables from devices. 5. Turn device ON. IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6... -
Page 6: Introduction
Compatible Software (Driver) The ioMemory VSL software is more than just a hardware driver, it is the "secret sauce" that gives IBM High IOPS Adapters their amazing performance. Each release of the ioMemory VSL software is compatible with certain IBM High IOPS Adapters. -
Page 7: Enterprise Value Ibm Flash Adapters
Description Throttle Shutdown Code Required Throttle Shutdown Number Temp. Temp. Temp. Temp. IBM 365GB Gen2 x8* Half- High IOPS height, half- A3J3 46C9078 93°C 100°C 78°C 83°C MLC Mono length Adapter clearance IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6... -
Page 8: Memory Attributes
IBM 320GB High IOPS SD 0097 46M0878 height, half-length 78°C 85°C Class SSD PCIe Adapter clearance IBM 320GB High IOPS MS Gen1 x4 Half-height, half- 1649 46M0898 78°C 85°C Class SSD PCIe Adapter length clearance IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6... -
Page 9: Memory Attributes
2. Assumes uniform distribution of writes across both memory modules. Hardware Requirements Before you install your IBM High IOPS Adapter(s) make sure your computer hardware meets these requirements. NOTE- For the latest IBM System x server configuration information and requirements for IBM High IOPS Mono and Duo Adapters, please see the URL below: http://www.ibm.com/support/entry/portal/docdisplay?lndocid=SERV-IOPS... -
Page 10: Shipping Considerations
Installing Power Cables on page Adequate System Cooling 300 LFM: To maximize the longevity and performance of IBM High IOPS Adapters, we recommend at least 300 Linear Feet per Minute (LFM) of airflow across the devices. 55°C Maximum: The ambient air temperature around the device should not exceed 55°C. -
Page 11: Sufficient System Memory (Ram)
IBM ioMemory VSL Release Notes for the version of ioMemory VSL software that you will install with the device(s). Firmware Requirements The IBM High IOPS Adapter must have a certain level of firmware in order to work with particular versions of the ioMemory VSL software. Consult the Upgrade Notes section of the http://www.ibm.com/systems/support... - Page 12 Half-height bracket, used on low-profile systems External Power Cable(s) On the USB Key (if available) are the following items: Environmental Notices document Important Notices document IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6...
-
Page 13: Installing The Device
Attention! Upgrade Previous Devices First If you have Legacy IBM High IOPS Adapters configured for ioMemory VSL 2.x or earlier that you wish to use with ioMemory VSL software version 3.x, you must upgrade the firmware on the previously installed devices before installing new devices in the system. - Page 14 Installing Power Cables on page 18 for instructions and to see if the power cable is required for your device. 7. Grasp the IBM High IOPS Adapter by the top edge and seat it gently but firmly in the available PCIe slot, for example: Attention! This illustration is an example of one type of IBM High IOPS Adapter, your specific device will install in the same manner.
- Page 15 10. Plug in the computer's power cable and turn on the computer. 11. Your operating system may detect the IBM High IOPS Adapter and ask if you want it to install a hardware driver for the device. In that case, click Cancel.
-
Page 16: Installing The Half-Height Bracket
ESD-safe package. You are now ready to install the driver and utilities software. See the IBM ioMemory VSL User Guide based on your operating system. Installing the Half-Height Bracket For half-height installation (such as in low-profile systems), you need to replace the full-height retaining bracket with the included half-height bracket. - Page 17 5. Attach the half-height bracket using a Phillips #1 tip screwdriver to tighten the two screws. IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6...
-
Page 18: Installing Power Cables
Installing Power Cables Some IBM High IOPS Adapters are compliant with the PCIe 2.0 bus specification of 25W and do not require external power in compliant PCIe slots. Other devices require more than the 25W to function. Second Generation IBM High IOPS Duo Adapters do require additional power through the provided power cable. - Page 19 IBM High IOPS Duo Adapters: IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6...
- Page 20 Attention! There are two power cables supplied with the IBM High IOPS Duo Adapters, a 2x3 pin supporting one Duo and a 2x4 pin supporting three Duos. These power cables mate directly to the corresponding aux power connectors available in most IBM servers.
-
Page 21: Weee Advisement Disposal And Acknowledgment
You can determine the week and year the device was manufactured by locating the serial number label on your device and interpreting the first four numbers of the serial number. Example Label: IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6... - Page 22 The first two numbers on the label indicate the last two numbers of the calendar year, and the next two numbers indicate the week of that year. In this example, the first four numbers are 1113, this stands for the year 2011 (11) and the 13th week of the year 2011 (13). IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6...
-
Page 23: Ibm Support
IBM Support IBM High IOPS Adapter software and documentation are available on the web at the following address: http://www.ibm.com/support/entry/portal/docdisplay?lndocid=MIGR-65723 (follow that link and then select IBM High IOPS software matrix). IBM part number 00AH229 IBM High IOPS Hardware Installation Guide for ioMemory VSL 3.2.6...
