- Page 1 AM280JNPDKH Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product. RU UK KK IN FR AR DB68-05685A-01 DVM SUPER_IB_05685A-00_EN.indd 25 2016-04-05 오후 3:32:58...
-
Page 2: Table Of Contents
Features of your new air conditioner Highly sensual and fine quality design Neat and elegant style allows it to be placed naturally anywhere within your interior. DMS (Data Management System) You can control and manage indoor and outdoor unit operation via internet (optional). Convenient control Integrated control with other DVM series indoor and outdoor unit is available. -
Page 3: Safety Precautions
If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. These warning signs are here to prevent injury to you and others. Please follow them carefully. - Page 4 Safety precautions For INStaLLatIoN WarNING Use the power line with the power specifications of the product or higher and use the power line for this appliance only. In addition, do not use an extension line. X Extending the power line may result in electric shock or fire. X Do not use an electric transformer.
- Page 5 For INStaLLatIoN WarNING Never install the outdoor unit in a location such as on a high external wall where it could fall. X If the outdoor unit falls, it may result in injury, death or property damage. this appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
- Page 6 Safety precautions For PoWEr SUPPLY WarNING When the circuit breaker is damaged, contact your nearest service center. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 7 For USING WarNING to reinstall the air conditioner, please contact your nearest service center. X Failing to do so may result in problems with the product, water leakage, electric shock, or fire. X A delivery service for the product is not provided. If you reinstall the product in another location, additional construction expenses and an installation fee will be charged.
- Page 8 Safety precautions For USING WarNING after unpacking the air conditioner, keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. X If a child places a bag over its head, it may result in suffocation. Do not insert your fingers or foreign substances into the outlet when the air conditioner is operating or the air flow blade is closing.
- Page 9 For USING WarNING If any foreign substance such as water has entered the appliance, cut-off the power supply and contact the nearest service center. X Failing to do so may result in electric shock or fire. Do not attempt to repair, disassemble, or modify the appliance yourself.
- Page 10 Safety precautions For USING CaUtIoN Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. X This may result in electric shock, fire, problems with the product, or injury.
- Page 11 For USING CaUtIoN avoid directly exposing humans, animals or plants from the air flow from the air conditioner for long periods of time. X This may result in harm to humans, animals or plants. this appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person...
- Page 12 Safety precautions For CLEaNING WarNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. X This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut-off the power supply and wait until the fan stops.
-
Page 13: Checking Before Use
Checking before use Using outdoor unit Take away any covers or barriers. f It may cause product failure and poor performance in cooling/heating by blocking air flow. Checking the auxiliary power switch Turn on the auxiliary power switch before turning on the air conditioner. f When the auxiliary power switch is off, the air conditioner will not turn on even if you press the on/off button. -
Page 14: Viewing The Parts
Viewing the parts The picture and function of the indoor unit may different depending on the model. Main parts air flow blade (right/left orientation) air flow blade (up/down orientation) Control panel air outlet air filter Removes the dust of incoming air air intake Intakes the outdoor air to open the panel... -
Page 15: Locking The Control Panel
Viewing the parts Control panel and the display remote controller receiver operation indicator Receives and inputs the command Displays the temperature, fan speed from the remote controller and operation mode turbo button on/off button temperature , button Mode button Fan Speed button Locking the control panel Whether the air conditioner is switched on or off, you cannot control the air conditioner with the control panel if this function is set. -
Page 16: Using The Air Conditioner With The Control Panel
Using the air conditioner with the control panel You can control the air conditioner without the remote controller. 1. Press the on/off button on the indoor unit control panel. f The air conditioner will operate in Cool mode. Stop To turn off the air conditioner, press the on/off button again. 2. -
Page 17: Adjusting The Air Flow Direction
adjusting the air flow direction Air flow can be directed to your desired position. adjusting the vertical air flow direction Hold the Air flow blade (up/down orientation) and adjust the up/down direction. f Air flow blades can be heated during heat mode. Be careful not to burn your hands by touching the air flow blades. -
Page 18: Cleaning And Maintaining The Air Conditioner
Cleaning and maintaining the air conditioner • Make sure to turn off the auxiliary power switch or unplug the power plug when cleaning the air conditioner. CaUtIoN Cleaning the indoor unit f Wipe the surface of the unit with a slightly wet or dry cloth when needed. f Brush away the dust on the narrow gap of air conditioner. - Page 19 Cleaning the air filter Washable air filter captures large particles from the air. The filter can be cleaned with a vacuum or by hand washing. 1. Open the panel and pull out the air filter. f Pull out the air filter in the direction of the arrow as shown in the below figure. 2.
- Page 20 Cleaning and maintaining the air conditioner Maintaining the air conditioner If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and turn off the circuit breaker. There may be internal damage if moisture is left in components.
-
Page 21: Troubleshooting
troubleshooting Refer to following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. ProBLEM SoLUtIoN • Check power status and then operate the air conditioner again. • Check whether the power plug is connected correctly or the auxiliary power the air conditioner does not work at all. - Page 22 troubleshooting • Check if the air conditioner is off. Turn the air conditioner on and set the Timer function. timer function is not working. • When the timer is already set, icon will appear on the indoor unit display. Check to see if the timer is already set. • Check if the buttons are locked.
-
Page 23: Product Specification
Product specification MoDEL aM280JNPDKH CLIMatES CLaSS ratED VoLtaGE & FrEQUENCY 220 - 240 V~ 50 Hz CooLING 4.73 A 4.73 A ratED CUrrENt HEatING(H1) 4.73 A CooLING 955 W 955 W ratED PoWEr INPUt HEatING(H1) 955 W CooLING HEatING(H1) NEt WEIGHt... - Page 24 (Russian) www.samsung.com/n_africa/ TUNISIA 80 1000 12 MOLDOVA 0-800-614-40 www.samsung.com/support support SOUTH AFRICA 0860 SAMSUNG (726 7864) U.A.E 800-SAMSUNG (800 - 726 7864) BOTSWANA 8007260000 OMAN 800-SAMSUNG (800 - 726 7864) www.samsung.com/ae/support (English) NAMIBIA 08 197 267 864 KUWAIT 183-CALL (183-2255) www.samsung.com/ae_ar/...
