Harman Kardon AVR 635 Front Panel Controls Manual

The following controls and indicators are
available on the AVR 635's front panel:
The following controls and jacks are located
behind the front-panel door. To open the door,
place the edge of a finger on the left or right
edge of the panel and gently swing the door
down toward you.
AVR 635 FRONT-PANEL CONTROLS
1 Standby/On Switch
2 Surround Mode Group Selector
3 Surround Mode Selector
4 Tuning Selector
5 Tuner Band Selector
6 Preset Station Selector
A Main Power Switch
B Headphone Jack
C Tone Mode Button
D Speaker Selector Button
E Channel Adjust Selector
7 Input Source Selector
8 Tuning Mode Selector
9 Front-Panel Control Door
) Volume Control
! Input Indicators
@ Speaker/Channel Input Indicators
F Digital Input Selector
G Delay Adjust Selector
H ‹/› Buttons
I Set Button
J EzSet/EQ Microphone Jack
# Upper Display Line
$ Lower Display Line
% Surround Mode Indicators
^ Remote Sensor Window
K Optical 4 Digital Input
L Input/Output Status Indicators
M Coaxial 4 Digital Jack
N Video 4 Audio/Video Jacks
