Harman Kardon AVR 130 Product View

¸
1 3 5
2 4
1 Main Power Switch
2 Power Indicator
3 Standby/On Switch
4 Headphone Jack
5 Tone Mode Selector Button
6 Speaker Selector
7 Surround Mode Group Selector
8 Surround Mode Selector
9 Tuning Selector
)
‹ / › Buttons
! Tuner Band Selector
AVR 130 FRONT-PANEL CONTROLS
˘ ¯
DIGITAL LOGIC 7
PRO LOGIC
3 STEREO DSP
5 CH. STEREO
SURR. OFF
Surr. Select
7 9
8
6
@ Set Button
# Digital Input Selector
$ Preset Stations Selector
% Delay Adjust Selector
^ Input Source Selector
& Tuner Mode Selector
* Optical 3 Digital Input
( Coaxial 3 Digital Input
Ó Bass Control
Ô Video 3 Video Input Jacks
 Video 3 Audio Input Jacks
˜
! # %
$ ^
) @ )
ˆ
ı
VID 1 DVD
VID 2 CD
VID 3 FMAM
TAPE
6 CH
Coaxial 3
& ( Ô
Ó
*
Ò Balance Control
Ú Treble Control
Û Channel Adjust Selector
Ù Volume Control
ı Input Indicators
ˆ Speaker/Channel Input Indicators
˜ Upper Display Line
¯ Lower Display Line
˘ Surround Mode Indicators
¸ Remote Sensor Window
Ù Û Ú
Ò

