- Page 1 12 INCH PORTABLE DVD PLAYER MODEL:SDVD1251 PLEASE READ CAREFULLY BEFORE OPERATING THIS EQUIPMENT KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE...
-
Page 2: Fcc Notice
CAUTION RISK OF ELECTRIC SHOCK O NOT OPEN CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lighting flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Fcc Warning
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. ... - Page 4 (6) Clean only with dry cloth The appliance should be cleaned only as recommended by the manufacturer. (7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable operation of the product and to protect it from overheating.
- Page 5 (15) Power source This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company.
- Page 6 (21) Replacement parts When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original parts. Unauthorized substitutions may result in fire or electric shock or other hazards. (22) Safety check Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in...
-
Page 7: About Discs
ABOUT DISCS The region number for this DVD Player is: 1 See the following page for information regarding region numbers. PLAYABLE DISCS: The following discs can be played back on this DVD player: DISC TYPES: Data on most DVDs is divided into sections called titles and then into subsections called chapters, each of which is given a title or chapter number. -
Page 8: Product Overview
PRODUCT OVERVIEW MENU : Press to enter root menu. SOURCE : Press and hold to switch to "AV IN" mode, press and hold again to resume. VOL +: Press to increase volume. SETUP: Press and hold to enter set up menu. VOL- : Press to decrease volume. - Page 9 PRODUCT OVERVIEW SD/MMC CARD 10. AV IN Jack 6. USB Port 7. SD/MMC Card Slot 11. Power ON/OFF Switch 12. DC IN Jack 8. Earphone Jack 9. AV OUT Jack 1314 13. Charge Indicator 14. Remote Sensor 15. Power Indicator...
-
Page 10: Remote Control
REMOTE CONTROL 1. STANDBY Button 2. VOLUME +/– Buttons MUTE Button STANDBY 4. MENU Button 5. Direction Buttons Button Button ( Play/Pause Button USB/CARD Button MENU TITLE Button AUDIO Button GOTO Button REPEAT Button 15. SLOW Button 16. LCD ON/OFF Button TITLE 17. -
Page 11: Battery Installation--Remote Control
BATTERY INSTALLATION--REMOTE CONTROL Battery installation: 1. Press the tab on the battery door and lift it off. 2. Install two (2) x AAA size batteries into the battery compartment as the figure on right and the polarity markings inside battery compartment. 3. -
Page 12: Power Source
POWER SOURCE Charging by supplied Wall Power Adapter: Charging by supplied Wall Power Adapter: 1. Connect the small plug from the supplied wall power adapter to the DC IN Jack on the right of unit. 2. Connect the wall power adapter to the wall outlet having AC 100-240V~;... - Page 13 CONNECTIONS Connecting to a TV or Video Player (such like DVD; VCR; DVR Players ... ) with AV connection cable SD/MMC CARD Video input jack ( Yellow ) Audio left channel input jack ( White ) Audio right channel input jack ( Red ) Audio/Video cable (not included) Connected to the Video Player...
- Page 14 SWIVEL PANEL The viewing angle of the swivel panel can be adjusted as below as desired: 180°...
- Page 15 OPERATIONS 1. Lift up the panel and turn to desired angle. Slide the Power ON/OFF switch to "ON" position to power on the unit. 2. Press the OPEN button to open the disc door. Place the disc on the center spindle with label side facing up.
- Page 16 OPERATIONS LCD ON/OFF Press to turn on or off the LCD display. STANDBY Press the button to enter standby mode, press again to power on the unit. VOL +/– Press the button on remote control to adjust volume. MUTE Press to turn off the sound, press again to resume. MENU Press to return to disc's menu page (It depends on the discs).
- Page 17 USB/SD/MMC PLAYBACK 1. Insert the USB Device or SD/MMC memory card into the USB port /card slot as the figure below. SD/MMC CARD NB: The unit supported to playback: ~ MP3.(Music file) ~ JPG (Pictures) Make sure correct files were saved in the USB device or memory cards. 2.
-
Page 18: System Setup
SYSTEM SETUP In completely stop mode, press the SETUP Button on remote control, the setting menu will appear on the screen ◄, ►, ▲, ▼ as below. Using the Direction Buttons to select and highlight the function you need to set or reset. Press the OK Button to enter or confirm the selection. - Page 19 SYSTEM SETUP In Video Setup Page: If "Panel Quality" is selected, using the Direction and OK Buttons to set the panel quality such like Sharpness; Brightness; Contrast; Hue or Saturation as desired. 2. If "Quality" is selected, using the Direction and OK Buttons to set the Sharpness;...
-
Page 20: Care And Maintenance
CARE AND MAINTENANCE Caring for Disc Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to contact with the shiny, unprinted side of the disc. ● Do not attach adhesive tape, stickers, etc. to the disc label. ●... -
Page 21: Specification
SPECIFICATION Power supply:AC 100-240V 50/60Hz Input, 12V/1A DC Output Disc compatibility: DVD/VCD/CD/CD-R/CD-RW/DVD±R/DVD±RW Type of disc: 12cm or 8cm SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE ACCESSORIES 1 x User's Manual 1 x Wall Power Adapter 1 x Remote Control 1 x Car Power Adapter...
