Page 1: Service Manual
Twin-tub washing machine SERVICE MANUAL Model HWM65-187S Features Full plastic cabinet Choose water current and washing time Choose spinning time Sperate washing and spinning Full plastic washing tub and spinning tub Edition: 2008.04.17 Manual code:SM HWM65-187S... -
Page 2: Table Of Contents
1.Contents Features 3. Specifications Safety precautions Warning and cautions 6. Net dimension Installation and accessory parts 8. Parts and functions 9. Maintenance service and trouble shooting 10. Wiring diagram CONTENTS... -
Page 3: Features
FEATURES Features Full plastic cabinet Choose water current and washing time Choose spinning time Sperate washing and spinning Full plastic washing tub and spinning tub... -
Page 4: Specifications
Specification... -
Page 5: Safety Precautions
Please insert the power cord into special receptacle with rated voltage.Be sure to use single-phase two pins receptacle. The earthing terminal must be earthed reliably.If possible,please adopt electric leakage protector. If the power cord is bad, to avoid risk it is required to replace. Keep the pin of the power plug clean. -
Page 6: Warning And Cautions
Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine. -
Page 7: Net Dimension
NET DIMENSION Unit mm Figure 1 INSTALLATION AND ACCESSORY PARTS The drainage shall be smooth with the drain hose. 1.put the drain hose up to suitable position. . 0.7m<H <1.2m 2.Do not step on or press the drain hose. Notes: the highest point of drain pipe should be higher than the water level of washing tub for avoiding to siphon phenomenon during drain. -
Page 8: Installation And Accessory Parts
Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub. Put soft items on the ground. Lean the machine down gently with the front surface facing the ground. Take off the drain hose from the cabinet. Take the hose out of the fixing groove. - Page 9 Points of Attention in After-sales Service Be sure to switch off the power during dismantling or repair. Be sure to use insulated wiring terminals and insulation box in connection of the wires, and crimp and fix to proper position with suitable tools. In welding connections with electric iron, be sure to twist the wires before welding, and insulate with insulation tapes.
- Page 10 Dismantling and installation of the base frame Dismantle the back cover. Loosen the wires. Loosen the fastening screw of the spin tub shaft. Separate the shaft from the brake wheel. Loosen the brake hook. Take off the brake cable frame from the installation groove of the twin-tub.
-
Page 11: Parts And Funtions
Wash selector Wash timer Water-filling entrance Control panel Overflow filter Water level adjusting lever Lint filter (installed by user) Valve cover Pulsator Wash tub Drain hose Wash tub cover Base frame PARTS AND FUNTIONS Outer cover of the spin tub Inner cover of the spin tub Spin timer Major frame... -
Page 12: Maintenance Service And Trouble Shooting
Insert the power plug , but the machine does not work Wash part Check if the capacitor is good? Replace the capacitor MAINTENANCE SERVICE AND TROUBLE SHOOTING Check if the wash timer is opened ? Check if the power source is available? Check if the contact between the plug and receptacle is good? Check if the power supply... - Page 13 Spin part Check if the capacitor is good? Replace the capacitor. MAINTENANCE SERVICE AND TROUBLE SHOOTING Check if the spin timer is opened ? Check if the power source is available? Check if the contact between the plug and receptacle is good? Check if the power supply cord is good? Check if the inlay of...
- Page 14 There is metal rubbing noise in braking If the brake arm has brake block ? The washing noise is too large Is the motor noise large? Is the motor fastened tightly? Is the belt too loose Is the radiating pulley loose? Is the pulsator rubbing the bottom of the twin-tub? 8.4 The pulsator only rotates towards one direction...
- Page 15 (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before it to repair. Phenomena The machine does not act. The draining does not work There's abnormal sound during washing There's abnormal sound and violent vibration during...
-
Page 16: Wiring Diagram
Spin timer Brown Fuse Wash timer Blue There is overload protector installed in the motor. In case that the motor is overload or meets breakdown in working, the protector will act and stop the motor. When the breakdown is removed, the motor will resume normal working. Actual Circuit Diagram wash timer Control... - Page 17 Sincere Forever Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
