WIDE LCD PANEL TV

TELEVISEUR LCD A ECRAN LARGE

BREEDBEELD LCD-TV

BREITBILD-LCD-TV

LT-32DC9BH

LT-26DC9BH

INSTRUCTIONS

INSTRUCTIES

ANWEISUNGEN

Trade Mark of the DVB Digital Video Broadcasting

Project (1991 to 1996) Number : 5238: LT-32DC9BH

5239: LT-26DC9BH

Table of Contents

Summary of Contents for JVC LT-32DC9BH

Page 1 TELEVISEUR LCD A ECRAN LARGE TELEVISEUR LCD A ECRAN LARGE INSTRUCTIONS INSTRUCTIONS BREEDBEELD LCD-TV BREEDBEELD LCD-TV INSTRUCTIES INSTRUCTIES BREITBILD-LCD-TV BREITBILD-LCD-TV ANWEISUNGEN ANWEISUNGEN Trade Mark of the DVB Digital Video Broadcasting Project (1991 to 1996) Number : 5238: LT-32DC9BH 5239: LT-26DC9BH...
Page 2 61145 Friedberg legislation. Germania [Business users] ES – Español If you wish to dispose of this product, please visit our web page www.jvc-europe.com to obtain information about the take-back of the product. Battery Apreciado cliente, [Other Countries outside the European Union]...
Page 3 This symbol indicates important instructions accompanying the TV. copyright ( © 2008 Victor company of Japan, Limited) Not to be copied, used or translated in part or whole without JVC’s prior consent in writing except approval of ownership of copyright and copyright law.
Page 4 generAL SAfeTy precAuTionS power ● Plug the power cord into the correct power outlet. An unstable connection may cause fire. ● Do not use damaged power cords or plugs, or use a loose wall outlet. This may cause electrical shock or fire. ● Do never touch the power cord with wet hands. This may cause electrical shock. ● Do not use multiple devices with one outlet. Overheating the outlet may cause fire. ● Do not bend or pull out the power cord using force, nor place heavy objects over it. This may cause electrical shock or fire. ● Make sure you pull out the power cord holding the plug itself. An internal disconnection may cause fire. ● When removing the product, turn off the power and pull out the plug from the power outlet. Also make sure other devices including the antenna or the connectors are removed from the outlets before relocating the product. Otherwise you may suffer electrical shock or fire due to a damaged power cord. ● The mains plug shall remain readily operable. ● Plug as disconnection device shall remain to be readily approached by user.
Page 5 generAL SAfeTy precAuTionS usage ● Unplug the product from the wall outlet and do not touch the antenna during a thunderstorm. This will prevent damage to the unit due to lightning and power-surges. ● Keep dust or water away from the pins or touching points of the power plug. This will prevent electrical shock or fire. ● Keep children from climbing over the product. The device may cause serious injury or death if it falls on them. ● Do not place anything over the product that children may try to reach. The device may cause serious injury or death if it falls on them. ● When removing the battery from the product, keep it out of children’s reach. If a child swallows a battery, consult a doctor immediately. ● Use only specified batteries and do not use an old battery along with a new one. Align the batteries according to the correct polarity (+ or -).
Page 6: Table Of Contents
TABLe of conTenTS preperATion -------------------------------------------------------------------------------------------------------------- 6 Front and Side Panel ---------------------------------------------------------------------------------------------------------------------- 6 Rear and Side Panel ----------------------------------------------------------------------------------------------------------------------- 8 Remote Control Buttons ------------------------------------------------------------------------------------------------------------------- 9 Connecting the Antenna ------------------------------------------------------------------------------------------------------------------0 Conditional Access Module (for the digital channels only) ---------------------------------------------------------------------- connecTing eXTernAL DeViceS -------------------------------------------------------------------------------12 Connecting the DVD or Set-Top Box -------------------------------------------------------------------------------------------------- Connecting the VCR ---------------------------------------------------------------------------------------------------------------------- Connecting the Camcorder or Game Console -------------------------------------------------------------------------------------...
Page 7: Preperation
Side panel Here the shown illustration is LT-32DC9BH model and may be somewhat different from your TV. Changes input source. Displays menu / confirms selection. Changes channel / moves selection. Adjusts volume / moves selection. Power On/Off power lamp ON: Lit (Blue) / STANDBY : Unlit remote control sensor Accessories Please check that the following accessories are included with your TV.
Page 8 When attaching the TV to the wall, use the optional JVc wall mounting unit (only for LT-32Dc9BH) • Consult a qualified technician. • See the included manual on mounting procedures. • JVC assumes no responsibility for damage due to improper mounting.
Page 9: Rear And Side Panel
Side panel SMArTcArD SLoT A slot for a Smartcard. Here the shown illustration is ci (common interface) SLoT LT-32DC9BH model and may be A slot for a CI Module (Conditional Access Module). somewhat different from your TV. Ac inpuT Connects the power cord. HDMi inpuT Connect to the HDMI outputs of DVD or STB.
Page 10: Remote Control Buttons
preperATion remote control Buttons (power on/off) (MuTe) Mode Switch DVD players / number Buttons TV / VCRs and DVD recorders. (information) Displays information on the Changes input source. current channel or input. coloured Buttons Used for interactive applications in the EPG, Edit Channels and Teletext TV/DTV mode.
Page 11: Connecting The Antenna
For proper reception of signals, an external antenna is required. For best reception, an outdoor antenna is recommended. ▪ To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly. Here the shown illustration is LT-32DC9BH model and may be somewhat different from your TV. Aerial cATV...
Page 12 Hold the Smartcard vertically with the electronic chip (small square-shaped, gold in colour) facing backwards to your TV. Insert the Smartcard completely into the left slot on the side of the TV. noTe: You can check the information of the embedded CAS (Conditional Access System) in DTV Setup > System > conditional Access menu. Here the shown illustration is LT-32DC9BH model and may be somewhat different from your TV. Smartcard Left Slot Smartcard ci Module (conditional Access Module)
Page 13: Connecting External Devices
DeViceS connecting the DVD or Set-Top Box Here the shown illustration is LT-32DC9BH model and may be somewhat different from your TV. HDMi ScArT coMponenT With a ScArT cable Connect the SCART cable between the SCART connector (eXT-1 or eXT-2) on TV and the SCART connector of DVD or STB.
Page 14: Connecting The Vcr
With a S-video cable Connect the S-video and audio cable between the S-video and audio input connectors on TV (eXT-4) and the S-Video and audio output connectors of VCR. noTe: The composite video and S-Video share Audio-L/R in EXT-4 on side. Here the shown illustration is LT-32DC9BH model and may be somewhat different from your TV. cable of S-Video S-ViDeo ScArT...
Page 15: Connecting The Digital Audio System
DigiTAL AuDio ouT (opTicAL) Connect the optical cable between the DigiTAL AuDio ouT (opTicAL) on TV and the composite optical audio input connector of digital audio system. Here the shown illustration is LT-32DC9BH model and may be somewhat different from your TV. Digital Audio System Headphone Not available...
Page 16: Installation Wizard
inSTALLATion WiZArD Wizard for Digital channels (in Digital TV Mode only) The installation wizard for digital channels will appear automatically when you perform the followings; ● Turning on your TV for the first time after purchase. (Refer to p.17) ● Performing the default setting in DTV Setup > installation menu when Digital TV mode. (Refer to p.9) noTe: ▪...
Page 17 inSTALLATion WiZArD Wizard for Analog channels (ApS) (in Analog TV Mode only) Firstly, switch to Analog TV input mode using the AV or TV/DTV button. When you perform the default setting in feature menu, the installation wizard for analog channels will appear automatically. (Refer to p.7) noTe: The default PIN code is 0000. If you have forgotten the PIN code, please contact your local TV distributor. Select the main language using the ◄/► button.
Page 18: Basic Operation
BASic operATion Turning on the TV Firstly, connect the power cord correctly. At this stage, the TV switches to standby mode. In standby mode to turn TV on, press the poWer, TV/AV or p / button on the TV or press the poWer, AV, TV/DTV, p / or nuMBer button on the remote control and the TV will switch on.
Page 19: Displaying Information
BASic operATion Displaying information programme information (i- plate) (in Digital TV Mode only) Programme information is displayed for a certain period of time whenever you switch channels. You can view the programme information by pressing the button while watching a programme. The information is displayed as follows on the screen. Channel number and channel name Programme name Icons...
Page 20: Displaying Channel List
BASic operATion Simple information (except for Digital TV Mode) You can view the information such as the channel number (or input source), and sound mode (or source resolution) by pressing the button while watching an analog TV channel or external input source. 11 ----- 1 ----- P 11 ----- EXT-1 EXT-1 EXT-1 EXT-3 EXT-3 EXT-3 Mono 720 x 480p 720 x 480p 720 x 480p ▲ External Input...
Page 21 BASic operATion Digital programme features (in Digital TV Mode only) Subtitle If the programme provides subtitle information you can select the language for the subtitle. Press the SuBTiTLe button to display the subtitle language list. Subtitle Select a subtitle language using the ▲/▼ button and press the oK English button. noTe: You can select the default subtitle language in DTV Setup > configuration >...
Page 22: Selecting The Main Input Source
BASic operATion Selecting the Main input Source Once you have connected your various audio and video systems, you can view different sources by selecting input sources. Press the AV button. Select a main input among the sources and press the oK button. noTe: You can easily switch to digital TV from different sources by pressing the TV/DTV button. Setting the Aspect ratio You can select an aspect ratio mode by pressing the ZooM button repeatedly on the remote control. Auto - regular - panoramic - 14:9 Zoom - 16:9 Zoom - 16:9 Zoom Subtitle - full 14:9 Zoom Regular Panoramic...
Page 23 BASic operATion Displaying Teletext information You can display teletext information at any time on your TV. Most TV broadcasting stations provide text information services via teletext. The index page of the teletext service gives you information on how to use the service. noTe: To properly display teletext information, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed. You can also select various options to fit your needs using the remote control buttons.
Page 24: Programme Guide (In Digital Tv Mode Only)
progrAMMe guiDe (in DigiTAL TV MoDe onLy) The Programme Guide displays the programme information about each digital channel, based on the date and time. You can also schedule your watching using the information given. Press the guiDe button to display the programme guide. noTe: Press the guiDe button again to exit the guide screen. Current programme information : channel number and name, programme name, ...
Page 25 progrAMMe guiDe (in DigiTAL TV MoDe onLy) Moving the Time Bar You can quickly search the time zone using the time bar. Press the green button to display time control bar. Select each button and press the oK button to move the time bar. If you press a button repeatedly, the same operation is repeated. Exits the time control bar.
Page 26: Finding A Programme
progrAMMe guiDe (in DigiTAL TV MoDe onLy) Schedule Press the yeLLoW button to display the schedule list. The schedule screen displays the reserved programme list and lets you add, edit or delete the reservations. Schedule To add a new reservation schedule, select a blank space and press the oK button.
Page 27: Menu Settings
Menu SeTTingS You can customize your TV which best fits your requirements using the various TV menus. How to navigate the Menu Button Action Menu Displays the menu. > p i c t u r e ▲/▼ Moves among menus or items. Mode Standard oK or ► Brightness Selects (Enters) a menu or confirms a selection. Contrast ◄/►...
Page 28: Feature Settings
Menu SeTTingS installation Settings (in Analog TV Mode only) > installation ● country: Shows the country. > i n s t a l l a t i o n Countr y Netherland ● Auto Search: (Refer to p.30) Auto Search ● Manual Search: (Refer to p.31) Manual Search Edit Channels ● edit channels: (Refer to p.31) Move Enter...
Page 29 Menu SeTTingS Time Setting Select feature > Time Setting. > > T i m e S e t t i n g ● Date: Shows the current date. Date 19.03.2007 Local Time 10 : 00 ● Local Time: Shows the current time. Power On Time -- : -- ● power on Time: Select On to set time for turning on the power and Power O ff Time then enter hour/minute. At the preset time, the TV will automatically...
Page 30 Menu SeTTingS DTV Setup (in Digital TV Mode only) > DTV Setup ● configuration: (Refer to p.34) > D T V S e t u p ● edit channels: (Refer to p.33) DT V Setup ● installation: - channel Search: (Refer to p.32) - Software update: (Refer to p.36) - Default Setting: (for Digital TV Mode Only) Sets the current all settings of the Digital TV mode to the default Enter settings.
Page 31: Analog Channel Settings (In Analog Tv Mode Only)
AnALog cHAnneL SeTTingS (in AnALog TV MoDe onLy) Analog channels can be searched and edited only in Analog TV input mode. noTe: You can access this menu only in Analog TV input mode. > i n s t a l l a t i o n Countr y Netherland How to navigate the Menu Auto Search Manual Search Button...
Page 32: Manual Search
AnALog cHAnneL SeTTing (in AnALog TV MoDe onLy) Manual Search Select Manual Search. > > M a n u a l S e a r c h ● colour System: Auto - PAL - SECAM Colour System Auto Audio System ● Audio System: BG – I – DK - L Band Channel ● Band: C (Air Channel) - S (Cable Channel) Programme No ● channel: Choose or enter the channel number.
Page 33: Digital Channel Settings (In Digital Tv Mode Only)
DigiTAL cHAnneL SeTTingS (in DigiTAL TV MoDe onLy) Digital channels can be searched and edited only in Digital TV input mode. noTe: You can access this menu only in Digital TV input mode. How to navigate the Menu Installation Channel Search Button Action Software Update Default Setting Menu Displays the menu. ▲/▼...
Page 34 AnALog cHAnneL SeTTing (in AnALog TV MoDe onLy) edit channels Select DTV Setup > edit channels menu. Edit Channels edit channel Lists Edit Channel Lists Edit Favourite Channels Select edit channel Lists. ● group: Select the group of channel list. ● Lock: Lock or unlock the channel. ● Select All: Select all channels. ● unselect All: Unselect all the selected channels. Channel editor Edit Channel Lists Group...
Page 35: Dtv Configuration (In Digital Tv Mode Only)
DTV configurATion (in DigiTAL TV MoDe onLy) This chapter describes how to set up the configuration for digital channels. Configuration noTe: You can access this menu only in Digital TV input mode. Parental Control Language Setting Schedule How to navigate the Menu Miscellaneous Settings Button Action Menu Displays the menu. ▲/▼...
Page 36: Miscellaneous Settings
DTV configuLATion (in DigiTAL TV MoDe onLy) Schedule Schedule Select DTV Setup > configuration > Schedule. The reserved programmes will be displayed in time order. Select the programme you want to edit and press the oK button. Select a blank space and press the oK button to add a new reservation. noTe: For detailed information about Schedule, refer to programme guide >...
Page 37: Dtv Software Update (In Digital Tv Mode Only)
DTV SofTWAre upDATe (in DigiTAL TV MoDe onLy) In order to maintain proper performance of the TV, it is essential to have the most up-to-date software. Installation noTe: You can access this menu only in Digital TV input mode. Channel Search Software Update Default Setting How to navigate the Menu Button Action Menu...
Page 38 DTV SofTWAre upDATe (in DigiTAL TV MoDe onLy) oTA (over the Air) OTA, an abbreviation of Over–the-Air, means that the software can be downloaded through your aerial. The manufacturer reserves the right to decide when and where to release software by this process. The software update via your aerial will only occur under the following circumstances. The equipment should have appropriate loader software.
Page 39: Appendix
AppenDiX Menu Map Picture Mode p.6 Brightness Contrast Sharpness Colour Hue ------------------------------- (NTSC signal only) Fleshtone Colour Temperature Noise Reduction Backlight Sound Bass p.6 Treble Balance Hyper Sound Installation Country p.7 (In Analog TV Mode Only) Auto Search p.0 Manual Search p. Edit Channels p. Feature Language p.7...
Page 40: Troubleshooting
AppenDiX Troubleshooting Before contacting your local service dealer, please make sure you refer to the following guide. If the TV does not work normally after completing the following trouble shooting, please contact your local TV distributor or service centre. () No message is displayed or the TV has no power. Check the main power cable and make sure it is plugged into a suitable power outlet.
Page 41: Error Message
AppenDiX (9) Channel search does not work. Check that your cable is connected correctly. Make sure that the antenna setting in the menu is correct. - Use the appropriate antenna capable of receiving VHF or UHF channels for your area. (0) Cannot update new software. - You can get an update. If the TV does not show a message requesting update, that means no software is available. () Cannot watch pay channels. Check in the menu that you have a valid and working subscription to the channels you wish to view.
Page 42: Specifications
AppenDiX Specifications Model LT-26Dc9BH LT-32Dc9BH CCIR B/G/I/D/K/L Broadcasting systems PAL, B/G, D/K, I Colour systems SECAM, B/G, D/K, L Digital : 51 MHz ~ 858 MHz Analogue : 45.25 MHz ~ 855.25 MHz Channel and frequencies Cable TV (S1-S20/S21-S41) A2 / Nicam Stereo Sound-multiplex systems FLOF (Fastext), TOP Teletext systems AC 220 V - 240 V, 50/60 Hz Power requirements Audio output 5W + 5W 10W + 10W (Rated power output) Speaker size (H x W x D: mm) (35x115x32.1) oval x2 (40x200x45.3) oval x2 95W (Max.) 140W (Max.) Power consumption [ 17.3W ]...
