- Page 1 15"17"20"LCD TV USER'S MANUAL MODEL: Please read this manual carefully before L15L6A-G0, 15SV6-A0, L17LV6-T1, using your television and keep this manual in a good place for future reference. HBLC20AB11...
-
Page 2: Table Of Contents
To users: Thank you for using our LCD-TV. After unpacking, please check that you have the following items: Operating instructions, Remote control, AC- DC adapter, AC wire, and Batteries. Before connecting the LCD-TV and turning the power on, please read this book carefully. Please keep this book for later use. When it was loss of function by electrostatic shock, please switch the on/off button for restoring the function. -
Page 3: 1Safety Notice Items
Never put the unit in direct sunlight or near heat sources; l Allow enough space for proper ventilation; l Please keep water away from the LCD-TV . If water comes in contact with the LCD-TV, disconnect the power cord from the power source, then wipe the set with a dry soft cloth;... -
Page 4: 3Front Panel Controls
VOL (VOL-) (VOL+) Volume up / to select the main menu/ to adjust the CH (CH-) TV channel down / to select the item in the menu (CH+) TV channel up / to select the item in the menu 4.TV/AV Select the input signals: PC/COMPONENT/AV/SV/TV 5. -
Page 5: 4Connection Options
YPbPr Input DC Power Cord Socket This TV operates on DC power. The voltage is indicated on the Specifications page . Never attempt to operate the TV on AC power. AV Audio Input Connect audio/video output from an external device to these jacks... -
Page 6: 5Remote Control Key Functions
Remote Control Key Functions When using the remote control, aim it towards the remote sensor on the TV Illustration of the keys on the remote control: Power supply switch To display/exit the main menu 2. MENU TV channel up/down or select the item of the menu 3. -
Page 7: 6Connection Instructions
Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna) NOTE: All cables shown are not included with the TV Bronze Wire RF coaxial wire (75 ohm) Turn clockwise to tighten. To improve picture quality in a poor signal area, purchase and install a signal amplifier. - Page 8 Connection Instructions PC Setup You can use your LCD-TV as a monitor for your personal computer using a VGA cable (not supplied). Connection and use steps: 1.Read the user guide supplied with your computer and ensure that it has a VGA connector;...
- Page 9 1.Read the user guide supplied with your AV devices and ensure that it has Composite or S-Video connectors; 2.Make sure that the power of the LCD-TV and the AV device are off; Connection Option 1 Set VCR output switch to 3 or 4 and then tune TV to the same channel number.
- Page 10 Connection Instructions Cable TV Setup - After subscribing to a cable TV service from a local provider you can watch cable TV programming. The TV cannot display TV programming unless a TV tuner device or cable TV converter box is connected to the TV.
-
Page 11: 7Basic Operating Instructions
When the power button is pressed and the LCD-TV is turned on, the indicator light on the front of the LCD-TV changes MENU from red to green. When the LCD-TV is turned on, the input MENU mode is displayed on the screen. When the LCD-TV is turned... - Page 12 You can use the number keys on the remote control to directly select TV channels. The LCD-TV can store up to CATV 125, AIR 69 channels , and you can press the keys on the remote control or on the panel to make a selection.
-
Page 13: 8Menu Operations
Menu Operations * In this manual, the OSD (On Screen Display) may be different from your TV s because it is just an example to help you with the TV operation. 1. Press MENU button to display the main menu, and VOL+/VOL-to select the main menu . - Page 14 Menu Operations Picture Menu Options continued 2. Press CH+/CH- button to enter the sound menu and to go up and down to select the desired option . 3.Press VOL+/VOL- button to increase and decrease the level toadjust the selected option to your preference . 4.
- Page 15 4. Repeat step 2 and step 3 until desired picture quality has been achieved . Function : VOLUME : Adjust the volume of your TV BALANCE : Adjust the balance of the audio output from left to right . When indication value of balance increases toward +50 , sound of the left speaker becomes weaker .
- Page 16 Function : INPUT SOURCE : To select the input source from PC/COMPONENT/AV/SV/TV LANGUAGE : To select the language of the OSD . If you select one language , the OSD will display in the language you have selected .
- Page 17 Changing the direction or position of the antenna may improve reception. SNOW: If your receiver is located at the weak, fringe area of a TV signal, your picture may be marred by small dots. It may be necessary to install a special antenna to improve the picture.
- Page 18 Menu Operations General Menu Options Continued Caption: The term for the words that scroll across the bottom of the TV screen; usually the audio portion of the program provided for the hearing impaired. TEXT: The term for the words that appear in a large black frame and almost cover the entire screen;...
- Page 19 Vchip Setting : CHILD LOCK: MPAA: When MPAA rating is selected, you could select OFF/G/PG/PG-13 R/NC-17/X . PG RATING:Select the TV Rating option. You could select from OFF/TV-Y/TR-Y7/ TV-G/TV-PG/TV-14/TV-MA. PG CONTENTS: CAN. ENGLISH: Select this option. You could select from OFF/E/C/C8+/G/PG/ 14+/18+ .
- Page 20 4. Repeat step 2 and step 3 until desired quality has been achieved .. Functions: 1. CHANNEL : Press VOL+/VOL- to change the TV channel . 2. SKIP : If you want skip a channel , press VOL+/VOL- to select ON , and this channel will be skip next time when you press CH+/CH- .
- Page 21 Menu Operations Adjust Menu Options Continued 2. Press CH+/CH- button to enter the adjust menu and to go up and down to select the desired option . 3.Press VOL+/VOL- button to increase and decrease the level to adjust the selected option to your preference . 4.
-
Page 22: 9Specifications
Specifications Specifications of the television that you have just purchased may vary from the information in this table due to technical innovations. Picture, sound system Antenna input impedance Audio output External input port AC converter Temperature NOTE:The dimension in this manual is a approximation. Accessories 1 AC-DC converter 2 AC cable... - Page 23 V0.1 009050****...
