- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com DSCV2-70-TX-UK 4K UHD In-Wall Transmitter with USB host and CEC Triggering User Manual Version: V1.0.0 Hall Technologies June 3, 2022 Page 1 of 14...
- Page 2 8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. 10. Refer all servicing to qualified service personnel. Hall Technologies June 3, 2022 Page 2 of 14...
-
Page 3: Table Of Contents
Features .......................... 4 Package Contents ......................5 Specifications ......................... 6 Panel Description ......................8 Front Panel ......................8 Rear Panel ......................9 Wiring ............................11 Automatic Switching ....................... 12 Device Control ......................... 12 Hall Technologies June 3, 2022 Page 3 of 14... -
Page 4: Introduction
Ÿ High-speed USB 2.0 pass through over HDBT up to 70m/230ft Ÿ PoH capable – can be powered by receiver with PSE module Ÿ Firmware upgrade through Micro USB port Hall Technologies June 3, 2022 Page 4 of 14... -
Page 5: Package Contents
Ÿ 1 x Wall Plate Plastic Panel (2‐Gang UK, with Screws) Ÿ 1 x USB B to A Cable Ÿ 1 x Phoenix Male Connector (3.5mm, 4 Pins) Ÿ 4 x Mounting Screws Ÿ 1 x User Manual Hall Technologies June 3, 2022 Page 5 of 14... -
Page 6: Specifications
Control Method Auto Switching, Front panel buttons, API commands General Operating Temperature 0°C to 45°C (32°F to 113°F) Storage Temperature -20°C to 70°C (-4°F to 158°F) Humidity 10% to 90%, non-condensing Hall Technologies June 3, 2022 Page 6 of 14... - Page 7 Note: T568B straight-through Category cable is recommended. Cable Type Range Supported Video Cat 5e/6 60m/197ft 1080P@60 36bpp Cat 6a/7 70m/230ft Cat 5e/6 35m/115ft 4K@30Hz 4:4:4 24bpp 4K@60 4:2:0 24bpp Cat 6a/7 40m/131ft Hall Technologies June 3, 2022 Page 7 of 14...
-
Page 8: Panel Description
Ÿ On: Corresponding HDMI input signal is being transmitted. HDMI LEDs (1-2) Ÿ Off: No HDMI signal is being transmitted or signal is unstable. Hall Technologies June 3, 2022 Page 8 of 14... -
Page 9: Rear Panel
Ÿ Display Off: Hold press for at least 3 seconds to turn off the display device. AUDIO IN Pass-through audio input. Connect to an audio source. USB HOST USB-B input. Connect to a USB host device. (HDMI 1&2) Rear Panel Hall Technologies June 3, 2022 Page 9 of 14... - Page 10 Ÿ Pins TX, RX and G are used to connect to a third-party device for controlling this transmitter. RS232 Ÿ Pins 12V and G are used for providing 12V power (max 5W) to the third-party device or for connecting a local 12V power adapter. Hall Technologies June 3, 2022 Page 10 of 14...
-
Page 11: Wiring
7. Select a desired video source through automatic or manual switching function. Laptop HDMI Control kaypad Audio RS232 USB-C HDBT MacBook Receiver HDMI OUT AUDIO Earphone Speaker Keyboard Mouse USB Camera Hall Technologies June 3, 2022 Page 11 of 14... -
Page 12: Automatic Switching
PC to the UPDATE port of the transmitter (see the following figure). API command for device control is available in the separate document “API Command Set DSCV2-70-TX-UK”. A professional RS232 serial interface software (e.g., Serial Assist) may be needed as well. - Page 13 Transmitter Hall Technologies June 3, 2022 Page 13 of 14...
