- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com DSCV1-70-TX 1-gang 4K Wall-plate Transmitter User Manual Version: V1.0.0 Hall Technologies June 3, 2022 Page 1 of 12...
- Page 2 8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. 10. Refer all servicing to qualified service personnel. Hall Technologies June 3, 2022 Page 2 of 12...
-
Page 3: Table Of Contents
Table of Contents Introduction ..........................4 Overview ..........................4 Features ..........................4 Package Contents ......................5 Specifications ........................6 Panel Description ....................... 8 Wiring ............................9 RS232 Pass-Through ......................11 Hall Technologies June 3, 2022 Page 3 of 12... -
Page 4: Introduction
Ÿ Supports one-way PoH, the transmitter can be powered by the receiver with PSE module. Ÿ Supports USB pass-through and RS232 pass- through via HDBT port. Ÿ Supports firmware upgrade through RS232 port and can be set through the DIP switch. Hall Technologies June 3, 2022 Page 4 of 12... -
Page 5: Package Contents
Ÿ 1 x Phoenix Connector (3.5mm, 2 Pins) Ÿ 1 x Phoenix Connector (3.5mm, 3 Pins) Ÿ 1 x 1–Gang US Socket Cover, White (with Screws) Ÿ 1 x User Manual Hall Technologies June 3, 2022 Page 5 of 12... -
Page 6: Specifications
AUDIO OUT: Stereo Maximum Data Rate 10.2Gbps Maximum Pixel Clock 340MHz General Operating Temperature 0°C to 45°C (32°F to 113°F) Storage Temperature -20°C to 70°C (-4°F to 158°F) Humidity 10% to 90%, non-condensing Hall Technologies June 3, 2022 Page 6 of 12... - Page 7 Note: T568B straight-through Category cable is recommended. Cable Type Range Supported Video Cat 5e/6 60m/197ft 1080P@60 36bpp Cat 6a/7 70m/230ft Cat 5e/6 35m/115ft 4K@30Hz 4:4:4 24bpp 4K@60 4:2:0 24bpp Cat 6a/7 40m/131ft Hall Technologies June 3, 2022 Page 7 of 12...
-
Page 8: Panel Description
Ÿ On: HDMI input signal is active. HDMI LED Ÿ Off: No HDMI signal input. Ÿ On: HDBT link is normal. LINK LED: Ÿ Blinking/Off: No HDBT link or link error. Hall Technologies June 3, 2022 Page 8 of 12... -
Page 9: Wiring
4. Connect additional functions options. • USB pass-through: Connect USB host PC to HOST port of the transmitter and connect USB devices such as keyboard and mouse to USB DEVICE ports of the receiver. The Hall Technologies June 3, 2022 Page 9 of 12... - Page 10 PSE module, no additional power adapter is needed to be connected to the transmitter. 6. Power on all attached devices. Transmitter HDMI IN Cat x Receiver HDMI OUT Keyboard&Mouse Interactive Whiteboard Hall Technologies June 3, 2022 Page 10 of 12...
-
Page 11: Rs232 Pass-Through
Note: In Pass-through mode, API commands also can be sent to the transmitter from transmitter side or receiver side to change baud rate, get its firmware version or upgrade its MCU, etc. (please refer to the separate document “API Command Set DSCV1-70-TX” to get detail commands information). - Page 12 © Copyright 2022. Hall Technologies All rights reserved. 1234 Lakeshore Drive Suite 150, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies June 3, 2022 Page 12 of 12...
