6.6. Getting the Measurement Results

The Vision Sensor measurements are received using "fhrunrecvval". In this sample
program, it is assumed that the Vision Sensor measurements are sent in the order
"TJG X Y Z W P R".
In order to receive the measurement results from the Vision Sensor, we
execute "fhrunrecvval" and check the received overall judgment value.
! Get the Measurement Result
fhrunrecvval fh_socket, retries_recv, timeout_recv, outputdata, err_no;
IF err_no <> success
1
GOTO
ENDIF
! Total Judge Check
IF outputdata{1} <> 1
GOTO
ENDIF
The measurement results X - R are stored in the variables.
!Measurement results
res_cmd_pos_x := outputdata{2};
res_cmd_pos_y := outputdata{3};
2
res_cmd_pos_z := outputdata{4};
res_cmd_pos_w := outputdata{5};
res_cmd_pos_p := outputdata{6};
res_cmd_pos_r := outputdata{7};
THEN
exit_program;
THEN
exit_program;
numerical sequence receiving function
If the overall judgment is not OK, exit the program
The measurement results X-R
