- Page 1 MANUEL D’UTILISATION PHILIPS CAFETIERE HD7806/51 Besoin d’un conseil ? Une question sur ce produit ? RDV sur la communauté SAV Darty : https://sav.darty.com Déjà 1/2 million de solutions grâce à l’avis des utilisateurs.
- Page 2 Service Manual Senseo® Original HD7806/50 HD7806/52 HD7806/51 HD7806/59...
-
Page 3: Table Of Contents
IEC 62353. • Only use genuine Philips spare parts to replace critical components. • The warranty of your Philips product is void if you do not use genuine Philips spare parts to repair critical components of your appliance. -
Page 4: General Information
General information Technical information Consumer Replaceable Parts • Voltage : 230 V • HD5009/01 Podholder 1-cup Black • Frequency : 50 Hz • HD5010/01 Podholder 2-cup Black • Power consumption : 1450 W • HD5011/01 Water container Sepia grey • Standby power consumption : <... -
Page 5: Technical Information
Technical information Materials Production date (or serial number)) • Housing : PP • Housing : ABS (only for HD6556) • Water container : PP • Brew chamber : PA • Spout : POM • Hoses : Silicon • Drip tray & Driptray cover : PP •... -
Page 6: Electical Diagram
Technical information Electical diagram Functional diagram Water level Temp. Sensor Sensor 3-way valve Boiler Fuse Brew Water Pump M head Container CONTROL Boiler Fuse Pump Push buttons... -
Page 7: Disassembly- And Reassembly Advice
Disassembly- and Reassembly advice During assembly Disassembly information • Make sure that the wiring is properly dressed as To remove the brew chamber lid cover handle as in the original situation. When replacing crimp follows: connections or tie wraps, perform a pull test. Prevent entrapment of wiring between housing- •... - Page 8 Disassembly- and Reassembly advice Removing Brew chamber head handle as follows: • Disassemble back cover! • Place the appliance such a way that you are looking at the boiler. • First remove the boiler from the snap lock position of the brew chamber. •...
-
Page 9: Functions/Features Explanation
Functions/features explanation SENSEO coffee boost technology Intensity select Get the most out of your coffee pad thanks to the The new PCBA has an extra feature onboard innovative SENSEO® Coffee Boost technology that “Intensity select”, which need to be enabled for delivers a fuller, richer flavor through: the following type numbers (HD6554, HD6555 &... -
Page 10: Volume Adjustment Procedure
Functions/features explanation Volume adjustment procedure Adjusting the normal 1-cup volume (WEU or French/Spain) If you have replaced the PCBA for whatever reason, you always need to check/adjust the volume 6. Empty the cup, podholder and push again for setting from this new PCBA. The PCBA coming from one cup setting, measure the volume output service has standard the WEU volume setting pre- with a graduated beaker. - Page 11 Functions/features explanation Adjusting the scale factor for the strong/short Restoring the Boiler_empty flag to production (60 ml) cup volume. default: Sometimes it is needed, that the boiler of the 13. Remove the water tank from the machine. (for SENSEO have to be emptied. adjusting the right parameter, the internal SW will check if the water level sensor is activated This for instance in wintertime were the possibility...
-
Page 12: Troubleshooting
Troubleshooting Problem Possible root cause Solution Blinking slow, no heating Boiler, PCBA Exchange boiler, PCBA Cannot open lid Blocked podholder Clean/descale or exchange podholder Cold coffee Boiler full of scale Descale appliance according instruction for use Boiler, NTC defect Exchange boiler, NTC Too less coffee Podholder blocked Descale podholder or exchange... -
Page 13: Service Parts
Service parts (2x) Service code Description Remark Online CRP 4222 259 69501 Brew chamber assy (Coffee boost) Mystic blue 4222 259 62781 Pad holder assy 1-cup Black HD5009/01 4222 259 62791 Pad holder assy 2-cup Black HD5010/01 4222 247 77141 Spout cover Black CP0603/01... - Page 14 Service parts Service code Description Remark Brew chamber lid Lever 4222 247 72881 Pushrod 4222 240 06911 Slider spring 4222 247 35837 Slider 4222 247 07461 Brew chamber seal 4222 259 67752 Distributor assy Coffee boost...
- Page 15 Service parts Service code Description Remark Online CRP 4222 247 39963 Sensor housing 4222 259 48666 Water container Sepia Grey HD5011/01 4222 247 40983 Valve outlet Black 4222 259 60151 Back cover assy Black HD7806/50 /51 /52 /59...
- Page 16 Service parts Service code Description Remark 4222 259 59541 3-way valve 4222 259 65482 Boiler assy OPR 230 V 4222 247 75271 TCO cap for OPR boiler 4222 24743694 Boiler pin cap 4222 247 72551 Suspension bracket 4222 247 06511 Pressure hose 4222 247 05136 O-ring (NTC)
- Page 17 Service parts Service code Description Remark 4222 259 68452 PCB assy OPR / Intensity select 230 V 4222 259 68401 Button frame printed Black 4222 259 63422 On/off button printed 3000 016 66541 Base plate Black 4222 259 37248 Pump 230 V / 50 Hz 4222 247 05191 Pump damper...
-
Page 18: Version History
Version history 19/03 Version 1.1 : HD7806/50 / HD7806/51 / HD7806/52 initial release. 19/06 Version 1.2 : Added new version: HD7806/59. Updated Parts List. - Page 19 www.philips.com...
