Connecting Cables

Connecting Cables
Step 1
Step 2
Step 3

Connecting Power and Booting the System

Step 1
Step 2
Step 3
Step 4
Step 5
Cisco Wide Area Virtualization Engine 274 and 474 Hardware Installation Guide
3-8
To connect cables to your WAVE appliance, follow these steps:
Power down the appliance before connecting cables to or disconnecting any
cables from the appliance.
See the documentation that comes with your optional equipment for additional
cabling instructions. It might be easier for you to route the cables before you
install specific optional equipment.
See the cable identifiers that are printed on the cables that come with the WAVE
appliance and options. Use these identifiers to connect the cables to the correct
connectors.
Figure 1-2 shows the locations of the input and output connectors on your
appliance.
To connect power to your system, follow these steps:
Review the information in the
Plug a power cord into the power cord receptacle on the back of the WAVE
appliance.
Connect the other end of the power cord to a power source at your installation site.
Power up all externally connected devices.
Press the power control button on the front of the WAVE appliance.
The system should begin booting. Once the operating system boots, you are ready
to initialize the basic software configuration. (See the software configuration
guide for details.)
Chapter 3 Installing the Wide Area Virtualization Engine
"Safety Guidelines" section on page 2-4.
OL-17739-01
