E1136/E1125/E1110/E1100
Revoria Press
User's Manual
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■
Parts of this manual is subject to change without prior notice.
■
The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending
■
on the model, the software, or the OS.
Control Panel
„ Features of Control Panel
Pressing the Home button displays the Home
screen.
1.
Power/Power Saving button
The power switches on.
Note
When "Please wait..." is displayed, the machine
■
is warming up. The use of machine is not avail-
able during this time.
If the power does not switch on, confirm that
■
the power plug is connected.
2.
NFC touch area
This is an area for you to hold up your NFC-supported mobile devices over. To communicate interactively, the NFC func-
tion of this machine needs to be enabled.
3.
Data indicator
This indicator blinks while data is being sent from the machine or data is being received from the client computer.
4.
Note on status display lamp
The lamp lights up in green at an instant of operation reception. When an error occurs, the lamp blinks in orange.
5.
Login
The user is authenticated when the user enters the User ID and logs in.
When the user is logged in with the administrator rights, [Administrator] is shown in this area. While the user is authen-
ticated, tapping on the authentication information display area logs out the user, and the state becomes as unauthenti-
cated.
6.
Interrupt
Suspend the tasks under operation during continuous copy or print and conduct other tasks preferentially.
7.
Opening menu
Tap this button to open the menu for change and check of the settings of the machine.
Tap on [<] to close the menu.
The PDF manual is available by clicking "PDF Manuals" on
the help of Internet Services.
https://product1.iotconnectup.com/webui_help/ap/revoria_press_e1136/en/top.html
[Apps]
5
1
6
7
Home Button
[Pause]
2
3
4
GM1541E2-1
January 2022 Edition 1
[Pins] [Address]
8
Advertisement
Related Manuals for FujiFilm E1136
Summary of Contents for FujiFilm E1136
- Page 1 GM1541E2-1 January 2022 Edition 1 E1136/E1125/E1110/E1100 The PDF manual is available by clicking “PDF Manuals” on the help of Internet Services. Revoria Press https://product1.iotconnectup.com/webui_help/ap/revoria_press_e1136/en/top.html User's Manual Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
- Page 2 Home Screen Tap on on the right side of the history for which you want to create a pin and tap on Apps/Pins/Address Screens can be displayed. • [Apps]: You can tap on any of the application icons [Create Pin]. and use its functions.
-
Page 3: Loading The Paper
Loading the Paper Pinch the guide clip(s) and adjust to the cor- rect paper size. Important Do not place paper or other objects in the reserved ■ space of the tray. Doing so can result in a paper jam or malfunction. -
Page 4: Document Feeder
Copy/Scan Set the document. Document Glass Multiple sheet sheets Loadable paper Paper size (mm) Length: Up to 297, Width: Up to 432 Document Feeder Open the document cover, and wipe off any dirt from the document glass. Loadable paper Paper size (mm) Length: 84 to 297, Width: 140 to 432 Paper weight (g/m... - Page 5 On the [Apps] screen, tap on the desired Application icon. Copy Scan Copy Scan (Email) As needed, configure the setting items. Note [Scan to Folder], [Scan], [Scan to USB], and [Scan to ■ Desktop] are also available as methods for scanning. To send an e-mail, the e-mail settings need to be con- ■...
-
Page 6: Safety Notes
Safety Notes „ Electrical Safety WARNING Before using this product, read “Safety Notes” carefully for safety use. This product shall be operated by the power source as indicated This product and recommended supplies have been tested on the product's data plate. Consult your local power company to check if your power source meets the requirements. -
Page 7: Minimum Configuration
„ Machine Installation „ Operational Safety WARNING WARNING Do not locate this product where people might step on The operator’s product maintenance procedures are de- or trip over the power cord. Friction or excessive pres- scribed in the manuals supplied with this product. Do not sure may generate heat and eventually cause electric carry out any other maintenance procedures not de- shock or a fire accident. - Page 8 To move this product to another location, contact your CAUTION local representative. Always follow all warning instructions marked on or sup- Ventilate well during extended operation or mass copy- plied with this product. To avoid the risk of burn injuries ing or printing.
- Page 9 „ Other WARNING This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Regulatory Information for RFID This product contains Radio Frequency Identification system device (RFID) and it is certified in compliance with applica- ble local laws and/or regulations.
- Page 12 More online support options..TO ACCESS MORE ONILNE SUPPORT OPTIONS Please go to our website, https://fujifilm.com/fbglobal/eng/support and then select your country to proceed. „ Print Drivers & Utilities ACCESS THE LATEST PRODUCT SUPPORT TOOLS ONLINE Fully tested printer drivers, utilities and software patches are available for our products.
