ION Block Rocker Service Manual page 6

17050013 nonpolarity electrolytic
capcitor
20110131 len
20310041 corner
20660038 rail
20660039 rail
20660040 rail
21010473 wooden cabinet
22010931 user manual
22010934 user manual
22050006 drier
22150001 service card
23010020 packaging bag
23010295 packaging bag
23010356 packaging bag
23020262 EPS
23070029 pearl wool sheet
23090570 gift box
23100092 inner carton
24100030 magnetic ring
30060079 foam
30060095 foam
30060423 Foam
30060424 Foam
30150142 telescoping handle
30150143 double sided tape
54110026 len
60090030 mic head
60190154 Battery
70010098 screw
70010151 screw
70010236 screw
70010237 screw
70010300 screw
70010479 screw
70010691 screw
70010848 screw
80130037 8" woofer
80320001 3" tweeter
90021267 serial number sticker
90041425 compliance sticker
90060117 compliance sticker
90080001 destination label
90200056 mark sticker
90200071 mark sticker
90220078 special sticker
90250038 CARB sticker
90270010 date sticker
Bill of Materials (BOM)
4.7uF/50V,±20%,-40/+85℃,Φ6*17mm
DN-PL1100
DN-PE1025,TPU,ROHS,V1.0
DN-PC6036,(3),ABS
DN-PC6037,(2),ABS
DN-PC6038,(1),ABS
DN-X10202,MDF,T=9mm
IPA76C,Quickstart Guide,V1.0
ION,safety and warranty manual,V14.8
50g,silicon,non-woven fabric,DMT,SGS
ION series,V1.1
PE,120*280*0.06mm
PE,160*260*0.025mm,punched
PE,(290+390)*750*0.1mm punched
IPA76C,EPS,510*340*100mm,V1.0
LGA8,500*350*2mm,V1.0
IPA76C,487*352*502mm
250g,270*65*60mm.V1.0(for MIC)
T22*14*8-C ,5uH
50*150*5mm
10*1000*1mm,EVA1030
EVA1030,288.5*6*1mm,T=1mm
EVA1030,(2)315*6*1mm
aluminium alloy,295*88mm,V1.0
3M(9495),V1.0
DN-PL1100,PC
AN-E0926,PM-353,ROHS
AN-E1909,PL7-12,12VDC,7Ah
Φ3*8mm,Phillips round head,screw head D5.5mm,self-
tapping,black zinc,HRC
Φ3*15mm,Phillips round head,screw head D5.5mm,self-
tapping,black zinc,HRC
Φ4*16mm,Phillips round head,screw head D7mm,self-
tapping,black zinc,HRC
M4*16mm,round head,screw head D9mm,black zinc,HRC
AN-C10300,M5*25mm,round head,screw head D9mm,black
zinc,HRC
Φ4*20mm,screw headD9mm
M4*26mm,round head,screw head D8mm
Φ3.5*15mm,hex screw,screw headD7mm
AN-LD31,50W,4ohm,99-08-Y8030F-00
10W,4ohm,99-08-Y3014B-00
IPA76C,64*13mm
IPA76C,38*26mm
IPA76C,copperplate paper,82*50mm
GA0/GA1/GA2,coated paper
coated paper,,BLACK&361C,Φ30mm,V1.0
green round sticker
ALESIS,30*30mm,coated paper,PANTONE 361C
ION,coated paper,78*23mm
coated paper,13*6mm,V1.0
1
1
8
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
3
2
4
3
1
1
1
1
3
4
4
4
4
2
4
29
1
1
4
2
1
3
1
1
1
1
1
