Page 1: Table Of Contents
5.3 Positioning 5.4 Electrical connection 5.5 Instructions for the installer ORIGINAL INSTRUCTIONS We advise you to read this manual carefully, as it contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • Keep children under the age of 8 away from the appliance when it 1.1 General safety instructions is in use. • Cleaning and maintenance must Risk of personal injury not be carried out by • During use the appliance and its unsupervised children. - Page 3 Instructions • Do not insert pointed metal objects • Before any operation on the (cutlery or utensils) into the slots in appliance (installation, the appliance. maintenance, positioning or movement) always wear PPM. • Do not pour water directly on very hot trays.
- Page 4 Instructions • Do not sit on the appliance. • Do not use the open door to place pans or trays on the internal • Do not use steam jets to clean the glazing pane. appliance. • Cooking vessels or griddle plates •...
- Page 5 Instructions • Do not wash the removable • The hoses should not come into components such as the hob contact with moving parts and grids, flame-spreader crowns and should not be crushed in any way. burner caps in a dishwasher. •...
-
Page 6: Manufacturer Liability
Instructions For this appliance 1.4 Appliance purpose • This appliance is intended for • Ensure that the appliance is switched off before replacing the cooking food in the home bulb. environment. Every other use is • Do not rest any weight or sit on the considered inappropriate. -
Page 7: Disposal
Instructions 1.6 Disposal • Deliver the appliance to the appropriate recycling centre for This appliance must be electrical and electronic disposed of separately from equipment waste, or return it to the other waste (Directives retailer when purchasing an 2002/95/EC, 2002/96/EC, equivalent product, on a one for 2003/108/EC). -
Page 8: How To Read The User Manual
Instructions 1.7 How to read the user manual This user manual uses the following reading conventions: Instructions General information on this user manual, on safety and final disposal. Description Description of the appliance and its accessories. Information on the use of the appliance and its accessories. -
Page 9: Description
Description 2 Description 2.1 General Description 1 Upstand 4 Auxiliary oven light 2 Cooking hob 5 Auxiliary oven seal 3 Control panel 6 Auxiliary oven door 7 Multifunction oven light Rack/tray support frames 8 Multifunction oven seal 9 Multifunction oven door 10 Multifunction oven fan... -
Page 10: Cooking Hob
Description 2.2 Cooking hob AUX = Auxiliary burner UR-3c = Ultra-rapid burner SR = Semi-rapid burner 2.3 Control panel 1 Multifunction oven function knob 3 Auxiliary oven temperature knob The oven’s various functions are suitable for This knob allows to select the cooking different cooking modes. -
Page 11: Other Parts
Description 5 Programmer clock Cooling fan For displaying the current time, setting programmed cooking operations and the minute minder timer. 6 Hob burner knobs Useful for lighting and adjusting the hob burners. Press and turn the knobs anti-clockwise to the value to light the relative burners. -
Page 12: Available Accessories
Description 2.5 Available accessories Ring reducer Tray rack Useful when using small cookware. WOK ring To be placed over the top of the tray; for cooking foods which may drip. Deep tray Useful when using a wok. Some models are not provided with all accessories. -
Page 13: Use
3 Use High temperature inside the oven during use Instructions Danger of burns Improper use • Keep the oven door closed during Risk of damage to surfaces cooking. • Protect your hands wearing heat • Do not cover the bottom of the oven resistant gloves when moving food cavity with aluminium or tin foil sheets. -
Page 14: To Save Energy
Precautions First use 1. Remove any protective film from the A gas leak can cause an explosion. outside or inside of the appliance, If you smell gas or there are faults in the gas including accessories. system: 2. Remove any labels (apart from the •... -
Page 15: Using The Accessories
3.2 Using the accessories Racks and trays Racks and trays have to be inserted into the Ring reducers side guides until they come to a complete The ring reducers must be placed on the stop. hob grids. Make sure they are placed •... -
Page 16: Using The Hob
3.3 Using the hob Correct positioning of the flame- spreader crowns and burner caps All the appliance’s control and monitoring devices are located together on the front Before lighting the hob burners, make sure panel. The burner controlled by each knob that the flame-spreader crowns are is shown next to the knob. -
Page 17: Using The Ovens
3.4 Using the ovens Multifunction oven functions Switching on the multifunction oven Light bulb Turns on the light inside the oven cavity. Fan with round heating element Ensure that the programmer clock The combination of the fan and the shows the cooking duration round heating element symbol , otherwise it will not... - Page 18 Auxiliary oven functions Grill The heat coming from the grill Light bulb element gives perfect grilling results Turns on the light inside the oven above all for thin and medium cavity. thickness meat and, in combination with the rotisserie (where fitted), Static gives the food an even browning at the end of cooking.
- Page 19 Advice for cooking with the Grill • If the dessert collapses when it comes out of the oven, on the next occasion reduce • Meat can be grilled even when it is put the set temperature by about 10 °C, into the cold oven or into the preheated selecting a longer cooking time if oven if you wish to change the effect of...
-
Page 20: Programmer Clock
3.5 Programmer clock Setting the time If the time is not set, the oven will not switch on. On the first use, or after a power failure, the digits will be flashing on the appliance’s display. 1. Press the keys at the same time. - Page 21 3. Wait approx. 5 seconds without pressing Programmed cooking any key in order for the function to Programmed cooking is the activate. The current time and the function which allows a cooking symbols will appear on the operation to be started at a set time and then ended after a display.
- Page 22 Adjusting the buzzer volume Deleting the set data The buzzer volume can be set to 3 different Press the keys at the same levels. When the buzzer is in operation, time to reset the programs set. press the key to change the setting. Then switch off the oven manually if cooking is in progress.
- Page 23 Multifunction oven cooking information table Weight Temperature Time Food Function Shelf (kg) (°C) (minutes) Lasagne 3 - 4 Static 220 - 230 45 - 50 Pasta bake 3 - 4 Static 220 - 230 45 - 50 Roasted veal Round 180 - 190 90 - 100 Pork loin...
- Page 24 Auxiliary oven cooking information table Weight Temperature Time Food Function Shelf (kg) (°C) (minutes) Lasagne 3 - 4 Static/Lower 220 - 230 50 - 60 Pasta bake Static/Lower 220 - 230 Pork chops Static/Lower 180 - 190 70 - 80 Sausages Grill 13 - 15...
-
Page 25: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance Ordinary daily cleaning Always use specific products only that do Instructions not contain abrasives or chlorine-based acids. Improper use Pour the product onto a damp cloth and Risk of damage to surfaces wipe the surface, rinse thoroughly and dry with a soft cloth or a microfibre cloth. -
Page 26: Cleaning The Hob
Cleaning and maintenance 4.1 Cleaning the hob Igniters and thermocouples For correct operation the igniters and Cooking hob grids thermocouples must always be perfectly Remove the grids and clean them in clean. Check them frequently and clean lukewarm water and non-abrasive them with a damp cloth if necessary. -
Page 27: Cleaning The Doors
Cleaning and maintenance 4.2 Cleaning the doors To reassemble the door, put the hinges in the relevant slots on the front of the oven, The door glazing should always be kept making sure that the grooved sections A are thoroughly clean. Use absorbent kitchen resting completely in the slots. -
Page 28: Cleaning The Oven Cavities
Cleaning and maintenance 3. Remove the intermediate glass pane by 6. Reposition the internal glass pane. Take lifting it upwards. care to centre and insert the 4 pins into their housings in the oven door by applying slight pressure. 4. Clean the external glass pane and the panes previously removed. - Page 29 Cleaning and maintenance Removing rack/tray support frames Cleaning the roof of the oven (auxiliary oven) Removing the rack/tray support frames enables the sides to be cleaned more High temperature inside the oven easily. during use To remove the rack/tray support frames, Danger of burns pull the frame towards the inside of the oven to unhook it from its groove A, then slide it...
-
Page 30: Extraordinary Maintenance
Cleaning and maintenance 4.4 Extraordinary maintenance 4. Slide out and remove the lamp. Replacing the oven light bulbs Live parts Danger of electrocution • Disconnect the appliance from the power supply. Both multifunction and auxiliary ovens are fitted with a 40W light Do not touch the halogen lamp bulb. - Page 31 Cleaning and maintenance pull the seal outwards. The oven does not heat up: • Fuse defective; check and, if necessary, replace the switch. • The function knob has not been set: set the function knob. All food prepared in the oven cavity burns within a short time: •...
-
Page 32: Installation
Installation 5 Installation General information Connection to the gas mains can be made 5.1 Gas connection (not valid for the using a continuous wall steel hose in compliance with the guidelines established by the standards in force. The appliance is For installation in the UK, please preset for natural gas G20 (2H) at a refer to the “Local specifications for... - Page 33 Installation Carefully screw the hose connector 3 to the Connection with a steel hose appliance’s gas connector 1 (½” thread Make the connection to the gas mains ISO 228-1), placing the seal 2 between using a continuous wall steel hose whose them.
- Page 34 Installation Connection to LPG Room ventilation Use a pressure regulator and make the The appliance should be installed in rooms connection on the gas cylinder following that have a permanent air supply in the guidelines set out in the standards in accordance with the standards in force.
-
Page 35: Adaptation To Different Types Of Gas
Installation 5.2 Adaptation to different types of In case of operation with other types of gas, the burner nozzles must be changed and the minimum flame adjusted on the gas taps. Replacing nozzles 1. Remove the grids, burner caps and flame-spreader crowns in order to access the burner cups. - Page 36 Installation Adjusting the minimum setting for natural Adjusting the minimum setting for LPG or town gas Tighten the screw located at the side of the Light the burner and turn it to the minimum cock rod clockwise all the way. position.
- Page 37 Installation Burner and nozzle characteristics tables Natural gas G20 - 20 mbar UR-3c Rated heating capacity (kW) 1.05 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600 Liquid gas – G30/31 - 30/37 mbar UR-3c Rated heating capacity (kW) 1.05 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle)
-
Page 38: Positioning
Installation 5.3 Positioning Any wall units positioned above the worktop of the appliance must be at a Heavy appliance minimum distance of at least Y mm. If a Crushing hazard hood is installed above the hob, refer to the hood instruction manual to ensure the correct clearance is left. - Page 39 Installation Appliance overall dimensions 600 mm 600 mm B - Class 2 subclass 1 min. 150 mm (Built-in appliance) 900 - 915 mm 750 mm 450 mm 600 mm Minimum distance from side walls or other flammable material. Minimum cabinet width (=A). C - Class 2 subclass 1 (Built-in appliance) The appliance must be installed by...
- Page 40 Installation Dimensions of the appliance: locations of Positioning and levelling gas and electric connections (mm) Heavy appliance Risk of damage to the appliance • Insert the front feet first and then the rear ones. The appliance must sit level on the floor to ensure stability.
-
Page 41: Electrical Connection
Installation 5.4 Electrical connection Installing the upstand (on some models only) The upstand provided is an Power voltage integral part of the product. It must Danger of electrocution be fastened to the appliance prior to installation. • Have the electrical connection performed by authorised technical The upstand must always be positioned and personnel. - Page 42 Installation General information Fixed connection Check the grid characteristics against the Fit the power line with an omnipolar circuit data indicated on the plate. breaker in compliance with installation regulations. The identification plate bearing the technical data, serial number and brand The circuit breaker should be located near name is visibly positioned on the appliance.
-
Page 43: Instructions For The Installer
Installation 5.5 Instructions for the installer • The plug must be accessible after installation. Do not bend or trap the power cable. • The appliance must be installed according to the installation diagrams. • Do not try to unscrew or force the threaded elbow of the fitting. - Page 44 9 1 4 7 7 8 7 5 2 / C...
