Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5 INTRODUCTION 5...
Page 6: Vehicle Identification Number
This number also appears on the Automobile Information NOTE: It is illegal to remove the VIN plate. Disclosure Label affixed to a window on your vehicle.
Page 7: Vehicle Modifications / Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 9: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....11 Ignition Key Removal ....11 Key-In-Ignition Reminder .
Page 10 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Vehicle Theft Alarm ..... .24 Liftgate .......26 Power Liftgate —...
Page 11: Things To Know Before Starting Your Vehicle 9
A WORD ABOUT YOUR KEYS You can insert the double sided keys into the locks with either side up. The dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 be used to order duplicate keys from your dealer.
Page 12: Key-In-Ignition Reminder
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The power window switches, radio, power sunroof, and power outlets will remain active for up to 45 seconds after the ignition switch has been turned off. Opening either front door will cancel this feature. WARNING! Leaving children in a vehicle unattended is danger- ous for a number of reasons.
Page 13 The Sentry Key Immobilizer System does not need to be armed or activated. Operation of the system is automatic regardless of whether or not the vehicle is locked or unlocked. During normal operation, the Theft Alarm/ Immobilizer Light will come on for three (3) seconds immediately after the ignition switch is turned on for a bulb check.
Page 14: Replacement Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys NOTE: Only keys that have been programmed to the vehicle electronics can be used to start the vehicle. Once a Sentry Key has been programmed to a vehicle, it can not be programmed to any other vehicle.
Page 15: General Information
The new Sentry Key has been programmed. The Keyless Entry Transmitter will also be programmed during this procedure. Repeat this procedure to program up to a total of 8 keys. If you do not have a programmed sentry key, contact your dealer for details.
Page 16: Door Locks
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS Manual Door Locks Lock the doors by pushing up on the lock knob on each door trim panel. If the lock knob is up when you shut the door, the door will lock.
Page 17: Power Door Locks
Power Door Locks A power door lock switch is on each front door trim panel. Use this switch to lock or unlock the doors. If you press the power door lock switch while the key is in the ignition, and any front door is open, the power locks will not operate.
Page 18: Child Protection Door Lock
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto Unlock The doors will unlock automatically on vehicles with power door locks if: 1. The Auto Unlock feature is enabled, 2. the transmission was in gear and the vehicle speed returned to 0 mph (0 km/h), 3.
Page 19: Remote Keyless Entry
To activate the system, open the rear door and move the child lock control, located near the door’s rear latch, to the ON position. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 When the child lock system is engaged the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position.
Page 20: To Unlock The Doors And Liftgate
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If the key is in the ignition switch, then all buttons on that transmitter will be disabled. The buttons on the remaining transmitters will work. If the vehicle is shifted out of PARK, all the transmitter buttons are disabled for all keys.
Page 21: To Lock The Doors And Liftgate
To lock the doors and liftgate: Press and release the LOCK button on the transmitter to lock all doors and liftgate. The horn will chirp once to acknowledge the signal. If desired, the “Sound Horn On Lock” feature can be turned on and off by referring to the Customer Programmable Features of the “Electronic Ve- hicle Information Center (EVIC)”...
Page 22 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Open/Close Power Liftgate — If Equipped Press the LIFTGATE button twice within five seconds to open/close the power liftgate. The liftgate will beep for 2 seconds and then open/close. If the button is pushed while the liftgate is being power closed, the liftgate will reverse to the full open position.
Page 23: General Information
General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 24: Vehicle Theft Alarm
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Remove and replace the battery. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To reassemble the transmitter case, snap the two halves together.
Page 25 To disarm the system: Press the UNLOCK button on the keyless entry transmitter. Also, using a valid sentry key and moving the ignition switch to the ON/START posi- tion will disarm the system. If you disarm the system and access the liftgate area, the system must be rearmed, as described previously, when closing the liftgate.
Page 26: Liftgate
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The alarm system will be activated when the battery is connected if the system was previously armed. The exterior lights will flash, the horn will sound, and the ignition will not start the vehicle. If this occurs, disarm the system.
Page 27: Power Liftgate - If Equipped
NOTE: • If a power malfunction to the power liftgate latch should occur, an emergency liftgate latch release can be used to open the liftgate. The emergency liftgate latch release can be accessed through a snap-in cover located on the liftgate trim panel. •...
Page 28 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The power liftgate may also be opened by pressing the switch located on the overhead console. A beeping signal will sound two seconds before the liftgate starts to open or close. WARNING! During power operation, personal injury or cargo damage may occur.
Page 29 • The power liftgate must be in the full open position for any of the close buttons to operate. If the liftgate is not fully open, press the open button to fully open the liftgate and then press close. • If the liftgate release switch is activated while the power liftgate is closing, the liftgate will reverse to the full open position.
Page 30: Windows
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather. WINDOWS Power Windows The window controls on the driver’s door control all the...
Page 31: Occupant Restraints
When the lock switch is pressed the window controls on the passenger doors will not illuminate and the passen- ger windows will be disabled. Auto Down Feature All the power window switches have an auto down feature. Press the window switch to the second detent, release, and the window will go down automatically.
Page 32: Lap/Shoulder Belts
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Please pay close attention to the information in this section. It tells you how to use your restraint system properly to keep you and your passengers as safe as possible. WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buck- led up.
Page 33 WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts.
Page 34 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is near the seatback of the front seats and next to your arm in the rear seats. Grasp the latch plate and pull out the belt.
Page 35 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click”. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 36 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
Page 37 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 38: Lap/Shoulder Belt Untwisting Procedure
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you’ll prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in position.
Page 39 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180° to create a fold that begins immediately above the latch plate. 3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the latch plate.
Page 40: Seat Belt Pretensioners
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision.
Page 41: Seat Belts And Pregnant Women
The Enhanced Warning System (BeltAlert™) can be en- abled or disabled by your authorized dealer or by following these steps: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position.
Page 42: Seat Belt Extender
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Keep the belt low so that it does not come across the abdomen. That way the strong bones of the hips will take the force if there is a collision. Seat Belt Extender If a seat belt is too short, even when fully extended and when the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, your dealer can...
Page 43: Driver And Front Passenger Supplemental
Driver and Front Passenger Supplemental Restraint System - Airbag This vehicle has airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s front airbag is mounted in the center of the steering wheel. The passenger’s front airbag is mounted in the instrument panel, above the glove compartment.
Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This vehicle is also equipped with a driver inflatable knee blocker located on the instrument panel below the steer- ing column. This vehicle may also be equipped with left and right side curtain airbags to protect the driver and passengers sitting next to a window.
Page 45 WARNING! • Do not put anything on or around the airbag covers or attempt to manually open them. You may damage the airbags and you could be injured because the airbags are not there to protect you. These protective covers for the airbag cushions are designed to open only when the airbags are inflating.
Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Children 12 years old and under should always ride buckled up in a rear seat. Infants in rear facing child restraints should NEVER ride in the front seat of a vehicle with a passenger front airbag. An airbag deployment can cause severe injury or death to infants in that position.
Page 47 WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How The Airbag Systems Work • The airbag control module determines if an impact is severe enough to require the airbags to inflate. Based on the level of collision severity, the control module determines the proper rate of inflation.
Page 49 • When the airbag control module detects a collision requiring the Front Airbags , it signals the inflator units. A large quantity of nontoxic gas is generated to inflate the front airbags. Different front airbag inflation rates are possible, these rates are determined by the airbag control module based on collision severity.
Page 50: Side Airbags Supplemental Restraint System (Srs) - If Equipped
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Driver Inflatable Knee Blocker inflates rearward towards the driver’s knees to help protect the knees and position you for the best interaction with the front airbag. The Driver Inflatable Knee Blocker fully in- flates in about 50 milliseconds, this is only about half of the time it takes you to blink your eyes.
Page 51 • The airbag material may sometimes cause abrasions and/or skin reddening to the driver and front passen- ger as the airbags deploy and unfold. The abrasions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor. They are not caused by contact with chemicals.
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you.
Page 53: Child Restraint
Child Restraint Everyone in your vehicle needs to be buckled up at all times — babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The lower anchor bars of the LATCH System are located where the seat back meets the seat cushion. The tether anchors are located on the rear surface of the seat. Child restraint systems designed to be compatible with the vehicles LATCH System are now available.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 NOTE: If your child restraint seat is not LATCH com- patible, install the restraint using the vehicle seat belts. Tether Anchors There are tether strap anchorages behind all second row seating positions and the driver’s side third row seating position.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE When the tether anchorage is used in the third row seating position, the strap should be positioned straight over the top of the seatback. Infants and Children There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt.
Page 57 • The infant carrier is only used rearward-facing in the vehicle. It is recommended for children who weigh up to about 9 kg (20 lbs). Convertible child seats can be used either rearward-facing or forward-facing in the vehicle. Convertible child seats often have a higher weight limit in the rearward-facing direction than infant carriers do, so they can be used rearward-facing by children who weigh more than 9 kg (20 lbs) but are...
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint.
Page 59 • Buckle the child into the seat according to the child restraint manufacturer’s directions. • When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle. Don’t leave it loose in the vehicle. In a sudden stop or collision, it could strike the occupants or seatbacks and cause serious personal injury.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE have tether straps, and you are urged to take advantage of all of the available attachments provided with your child restraint in any vehicle. Not all child restraint systems will be installed as we have described here.
Page 61: Engine Break-In Recommendations
Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet could be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 62: Safety Tips
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow the safety tips below.
Page 63: Periodic Safety Checks You Should Make Outside The Vehicle
Airbag Light The light should come on and remain on for 6 to 8 seconds as a bulb check when the ignition switch is first turned ON. If the LED is not lit during starting, have it checked. If the light stays on or comes on while driving, have the system checked by an authorized dealer.
Page 65: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......69 Inside Day/Night Mirror ....69 Automatic Dimming Mirror —...
Page 66 66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seats ....... . .85 10–Way Driver’s Power Seat —...
Page 67 Fog Lights — If Equipped ....106 Turn Signals ......106 Highbeam/Lowbeam Select Switch .
Page 68 68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Erasing Homelink Buttons ....119 Reprogramming a Single Homelink Button . . . 120 Security ......120 Power Sunroof —...
Page 69: Mirrors
MIRRORS Inside Day/Night Mirror Adjust the mirror to center on the view through the rear window. A two point pivot system allows for horizontal and vertical adjustment of the mirror. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 69 Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).
Page 70: Automatic Dimming Mirror - If Equipped
70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped If the switch is in the “Auto” position the mirror will automatically adjust for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror.
Page 71: Outside Mirror - Driver's Side
Outside Mirror — Driver’s Side Adjust the outside mirror to center on the adjacent lane of traffic, with a slight overlap of the view obtained on the inside mirror. Outside Mirror — Passenger’s Side Adjust the convex outside mirror so you can just see the side of your vehicle in the portion of the mirror closest to the vehicle.
Page 72: Power Remote-Control Mirrors
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Remote-Control Mirrors Use the mirror select switch, located on the driver’s door trim panel above the power window switches, to adjust the view obtained in the outside mirrors. Press the rocker switch to the L or R for Left or Right mirror selection.
Page 73: Illuminated Vanity Mirrors
Illuminated Vanity Mirrors An illuminated vanity mirror is on the sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights turn on automatically. Closing the mirror cover turns off the lights. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73 Sun Visor Extension This feature has a pull out extension on the sun visor for...
Page 74 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The UConnect™; phone book enables you to store up to 32 names and four numbers per name. This system is driven through your Bluetooth™ Hands-Free Profile cellular phone. UConnect™ features Bluetooth™ technol- ogy - the global standard that enables different electronic devices to connect to each other without wires or a docking station, so UConnect™...
Page 75: Operation
prompts as well as the other party’s voice in a conversa- tion will be played over your vehicle’s stereo system. The volume of the UConnect™ system can be controlled through your normal stereo controls. The radio display will be used for visual prompts from the UConnect™...
Page 76 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The UConnect™ system will then prompt you to begin the cellular phone pairing process on your cellular phone. Please see your cellular phone user’s manual for instructions on how to complete this step. •...
Page 77 Add Names to Your UConnect™ Phonebook • Press the “Phone” button to begin. • After the Ready prompt, say Phonebook New En- try . • When prompted, say the name of the new entry. • Next, enter the number designation (e.g. “Home”, “Work”, “Mobile”, or “Pager”).
Page 78 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phonebook edit can be used to add another phone number to a name entry that already exists in the phonebook. For example, the entry John Doe may have a mobile and a home number, but you can add John Doe’s work number later through phonebook edit.
Page 79: Phone Call Features
• The UConnect™ system will play the names of all the phonebook entries. • To call one of the names in the list, press the ’Voice Recognition’ button during the playing of the desired name and say Call . • The UConnect™ system will then prompt you as to number designation you wish to call.
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Making a Second Call while Current Call in Progress To make a second call while you are currently in a call, press the ’Voice Recognition’ button and say Dial or Call followed by the phone number or phonebook entry you wish to call.
Page 81: Advanced Phone Connectivity
Phone Redial • Press the ’Phone’ button to begin. • After the Ready prompt, say Redial . • The UConnect™ system will call the last number that was dialed on your cellular phone. This may not be the last number dialed by your UConnect™ system. Advanced Phone Connectivity Transferring an Active Call between the UConnect™...
Page 82: Uconnect™ System Features
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you would like to connect or disconnect the Blue- tooth™ connection between a paired cellular phone and the UConnect™ system, follow the instruction described in your cellular phone user’s manual. List Paired Cellular Phone Names •...
Page 83 pin. This method can also be used in instances where you are pressing a number on your keypad to navigate through a menu structure or to enter a number for a pager. Barge In - Overriding Prompts The ’Voice Recognition’ button can be used when you wish to skip part of a prompt and issue your voice recognition command immediately.
Page 84 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect™ system. By dialing a number with your paired Bluetooth™ cellular phone, the audio will be played through your vehicle’s stereo sys- tem.
Page 85: Seats
SEATS 10–Way Driver’s Power Seat — If Equipped The driver’s power seat switches are located on the driver’s front door trim panel. The bottom switch con- trols up/down, forward/rearward, and tilt adjustment. The top switch controls the seatback recline adjustment and the middle switch controls the lumbar adjustment.
Page 86: Adjustable Head Restraints
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
Page 87 Press the switch once to select a heat setting (high or low) and press the switch a second time in the same direction to turn the heated seat off. The indicator light will show when LOW or HIGH heat is ON. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 The controls for the second row heated seats are located on the center console between the seats.
Page 88: Memory Seat - If Equipped
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • If the lights in the second row heated seat switch begin to flash when the switch is pressed, it indicates that the heated seat is not functioning properly and that ser- vice is required.
Page 89 NOTE: The vehicle must be in Park to recall memory positions. If a recall is attempted when the vehicle is not in Park, a message will be displayed in the Electronic Vehicle Information Center (EVIC). To recall memory positions press memory button number 1 if you are recalling the memory position for driver one or press memory button number 2 if you are recalling the memory position for driver two.
Page 90: Understanding The Features Of Your Vehicle 65
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Press and release the SET (S) button located on the driver’s door. A light in the button will flash telling you that you are in the set memory mode. You have five seconds to complete the next step.
Page 91: Second Row Manual Seat Recliner
5. Within 5 seconds, press and release the UNLOCK button on the remote keyless entry transmitters. A chime will sound signaling you that the transmitter link has been successfully disabled. A message will also be dis- played in the Electronic Vehicle Information Center (EVIC), indicating the transmitter has been disabled.
Page 92: Second Row Manual Seat Adjuster
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or fatally injured. Use the recliner only when the vehicle is parked.
Page 93: Second Row Fold & Tumble Seats
WARNING! Adjust the seat only while the vehicle is parked. Adjusting a seat while the vehicle is moving is dangerous. The seat belt might not be properly adjusted and you could be injured. Second Row Fold & Tumble Seats The second row seats can be folded and tumbled forward for easy access to the third seat or rear cargo area.
Page 94: Third Row Easy Exit
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Pull up on the release handle labeled “2” and lift firmly to tumble the seat fully forward. If the seat contacts the rear of the front seat, move the front seat forward. To relatch the seat, tilt the seat rearward and push down firmly to engage the rear attachments.
Page 95 To fold and tumble the seat forward, follow these steps: 1. Pull up on the seatback release handle “1” located on the back of the seat to fold the seatback down. 2. Pull the release strap “2” located at the bottom of the seat to lift and tumble the seat forward.
Page 96: Third Row Seating Flexibility
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Third Row Seating Flexibility The third row seats may be used with either or both seatbacks folded forward for additional storage space. To fold the seat, remove any objects from in front of or on the seat.
Page 97: Load Floor
WARNING! • Not all head restraints in this vehicle are the same. Head restraints from one seating position should not be removed and installed in any other seating posi- tion. In a collision, serious injury or death may result if the proper head restraint is not installed on each seat.
Page 98: Plastic Grocery Bag Retainer
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Pull on the load floor strap and lift the panel from the driver’s second row seatback over the center console and onto the passenger second row seat. NOTE: Be sure to reattach the strap to secure the load floor panel when not in use.
Page 99: Adjustable Pedals - If Equipped
ADJUSTABLE PEDALS — IF EQUIPPED This feature allows both the brake and accelerator pedals to move toward or away from the driver to provide improved position with the steering wheel. The adjust- able pedal system is designed to allow a greater range of driver comfort for steering wheel tilt and seat position.
Page 100: To Open And Close The Hood
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The pedals cannot be adjusted when the vehicle is in R (Reverse) or when the Speed Control is ON. A message will be displayed in the Electronic Vehicle Information Center (EVIC) if the pedals are attempted to be ad- justed when the system is locked out (“Adjustable Pedal Disabled —...
Page 101 Next, push to the left the safety catch located under the front edge of the hood, near the center. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Use the hood prop rod to secure the hood in the open position. To prevent possible damage, do not slam the hood to close it.
Page 102: Lights
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. You could have a collision. Be sure all hood latches are fully latched before driving. LIGHTS Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the...
Page 103: Interior Lights
Interior Lights The interior lights come on when a door is opened. The interior lights will automatically turn off in about 15 minutes if a door is left open or the dimmer control is left in the Dome light position. Turn the ignition switch ON to restore the interior light operation.
Page 104 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To change the brightness of the instrument panel lights, rotate the center portion of the Multi-Function Lever up or down. Dimmer Control With the parking lights or headlights on, rotating the dimmer control for the interior lights on the Multi-Function Lever upward will increase the bright- ness of the instrument panel lights.
Page 105: Automatic Headlights
Parade Mode (Daytime Brightness Feature) Rotate the dimmer control upward to the first detent. This feature brightens the odometer and radio display when the parking lights or headlights are on during daylight conditions. Automatic Headlights This system automatically turns your headlights ON or OFF based on ambient light levels.
Page 106: Fog Lights - If Equipped
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To activate the delay feature, turn off the ignition switch while the headlights are still on. Then turn off the headlights within 45 seconds. The 90 second delay inter- val begins when headlight switch is turned off. If the headlights or park lights are turned back on or the ignition switch is turned on, the delay will be cancelled.
Page 107: Highbeam/Lowbeam Select Switch
Highbeam/Lowbeam Select Switch Pull the Multi-Function Lever towards you to switch the headlights to HIGH beam. Pull the Lever a second time to switch the headlights to LOW beam. Passing Light You can signal another vehicle with your headlights by lightly pulling the Multi-Function Lever toward you.
Page 108: Mist Feature
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If the lever is pulled while in the OFF position, the wipers will operate for two wipe cycles, then turn OFF. Mist Feature Push down on the wiper lever to activate a single wipe to clear off road mist or spray from a passing vehicle.
Page 109 Rotating the center of the switch up to the DEL (Delay) position or the ON position will activate the rear wiper. Push the lever forward to initiate the rear wash function in any of the three positions. The washer pump will continue to operate as long as the lever is pressed.
Page 110: Tilt Steering Column
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT STEERING COLUMN To tilt the column, pull the lever, located behind the turn signal control, toward you and move the steering wheel up or down, as desired. Release the lever to lock the steering wheel firmly in place.
Page 111: Electronic Speed Control
To turn the system back ON, press the switch a second time until the traction control Indicator turns OFF. NOTE: • The traction control Indicator comes on each time the ignition switch is turned ON. This will occur even if you used the switch to turn the system OFF.
Page 112: To Activate
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate: Push the “ON/OFF” button once and the CRUISE indi- cator located near the instrument cluster odometer will illuminate showing the electronic speed control system is on. To turn the system OFF, push the “ON/OFF” button again and the system and indicator will turn off.
Page 113: To Resume Speed
To Resume Speed: To resume a previously set speed, push and release the “ACCEL/RESUME” button. Resume can be used at any speed above 25 mph (40 km/h). To Vary the Speed Setting: When the speed control is set, speed can be increased by pressing and holding the “ACCEL/RESUME”...
Page 114: Overhead Console - If Equipped
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Speed Control can be dangerous where the system can’t maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control. An accident could be the result. Don’t use Speed Control in heavy traffic or on roads that are winding, icy, snow-covered, or slippery.
Page 115: Sunglasses Storage
The lights also turn on when a front door, a rear door or the liftgate is opened. The lights will also turn on when the unlock button on the remote keyless entry transmitter is pressed. Sunglasses Storage At the rear of the console a compartment is provided for the storage of a pair of sunglasses.
Page 116: Programming Homelink
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink NOTE: When programming a garage door opener, it is advised to park outside the garage. Some vehicles may require the ignition switch to be turned to the second (or accessories ) position for programming and/or opera- tion of HomeLink.
Page 117 WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. A moving door or gate can cause serious injury or death to people and pets or damage to objects.
Page 118: Canadian Programming/Gate Programming
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If the indicator light blinks rapidly for two seconds and then turns to a constant light continue with Program- ming steps 6-8 to complete the programming of a rolling code equipped device (most commonly a garage door opener).
Page 119: Using Homelink
If you live in Canada or you are having difficulties programming a gate operator by using the Program- ming procedures (regardless of where you live), replace Programming HomeLink step 3 with the following: NOTE: If programming a garage door opener or gate operator, it is advised to unplug the device during the cycling process to prevent possible overheating.
Page 120: Reprogramming A Single Homelink Button
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reprogramming a Single HomeLink Button To program a device to HomeLink using a HomeLink button previously trained, follow these steps: 1. Press and hold the desired HomeLink button. Do NOT release the button. 2.
Page 121: Power Sunroof - If Equipped
POWER SUNROOF — IF EQUIPPED The power sunroof switches are located between the sun visors on the overhead console. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Press and hold the switch rearward to fully open the sunroof. The sunroof can be stopped at any position between closed and full open.
Page 122: Express Open Feature
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Express Open Feature The sunroof is equipped with an intermediate stop or comfort stop position. This feature is designed to elimi- nate wind buffeting at vehicle speeds between 20-40 mph (32-64 km/h). To operate this feature, momentarily press the switch rearward to activate the Express Open Feature and the glass will automatically stop at the comfort stop position.
Page 123: Wind Buffeting
WARNING! • Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. •...
Page 124: Electrical Power Outlets
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRICAL POWER OUTLETS There are two 12 volt power outlets located on the instrument panel below the radio. The driver’s side outlet is controlled by the ignition switch and the passenger side outlet is connected directly to the battery. The driver’s side outlet will also operate a conventional cigar lighter unit (if equipped with an optional Smoker’s Package).
Page 125: Electrical Outlet Use With Engine Off
The outlets include tethered caps labeled with a key or battery symbol indicating the power source. The passen- ger side instrument panel and center console outlets are powered directly from the battery, items plugged into these outlets may discharge the battery and/or prevent engine starting.
Page 126: Cupholders
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Front Seat Cupholders The cupholders are located in the forward edge of the center console. Push down on the forward edge of the console to release the cupholders. Press the cover up when the cupholders are no longer needed.
Page 127: Rear Cargo Storage Bin
Rear Cargo Storage Bin The storage bin is located in the floor of the rear cargo area. To open lift up on the handle. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 Retractable Cargo Area Cover — If Equipped To cover the cargo area: 1.
Page 128: Cargo Tie-Down Hooks
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! In an accident a cargo cover loose in the vehicle could cause injury. It could fly around in a sudden stop and strike someone in the vehicle. Do not store the cargo cover on the cargo floor or in the passenger compartment.
Page 129 WARNING! • Cargo tie-down hooks are not safe anchors for a child seat tether strap. In a sudden stop or colli- sion a hook could pull loose and allow the child seat to come loose. A child could be badly injured. Use only the anchors provided for child seat tethers.
Page 130: Roof Luggage Rack - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED The crossbars and siderails are designed to carry the weight on vehicles equipped with a luggage rack. The load must not exceed 150 lbs (68 kg), and should be uniformly distributed over the luggage rack crossbars.
Page 131 The tie down holes on the cross bar ends should always be used to tie down the load. Check the straps frequently to be sure that the load remains securely attached. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 CAUTION! • To avoid damage to the roof rack and vehicle, do not exceed the maximum roof rack load capacity of 150 lbs (68 kg).
Page 132: Load Leveling System
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in personal injury or property damage. Follow the Roof Rack Cautions when carrying cargo on your roof rack.
Page 133: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instruments And Controls ....136 Instrument Cluster ..... . 137 Instrument Cluster Descriptions .
Page 134 134 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Operation ..... . 160 Tape Player Operation ....164 CD Player Operation .
Page 135 Navigation System — If Equipped ... 182 Climate Controls ..... . . 183 UNDERSTANDING YOUR INSTRUMENT PANEL 135 Dual-Zone Automatic Temperature Control .
Page 136: Instruments And Controls
136 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENTS AND CONTROLS...
Page 137: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 137 INSTRUMENT CLUSTER...
Page 138: Instrument Cluster Descriptions
138 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Voltage Light This light monitors the electrical system voltage. The light should turn on momentarily as the engine is started. If the light stays on or turns on while driving, it indicates a problem with the charging system. Immediate service should be obtained.
Page 139 WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual. Follow the warnings under the Cooling System Pressure Cap paragraph.
Page 140 140 UNDERSTANDING YOUR INSTRUMENT PANEL is not functioning and that service is required. However, the conventional brake system will continue to operate normally if the BRAKE warning light is not on. If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes.
Page 141 Vehicles equipped with Anti-Lock brakes (ABS), are also equipped with Electronic Brake Force Distribution (EBD). In the event of an EBD failure, the Brake Warning Light will turn on along with the ABS Light. Immediate repair to the ABS system is required. The operation of the Brake Warning Light can be checked by turning the ignition switch from the OFF position to the ON position.
Page 142 142 UNDERSTANDING YOUR INSTRUMENT PANEL disabled for about 4 minutes until the brakes have cooled. The system will automatically reactivate and turn off the Traction Control Light. 9. Tachometer The red segments indicate the maximum permissible engine revolutions-per-minute (r.p.m. x 1000) for each gear range.
Page 143 release the Trip Odometer button. To reset a trip odom- eter, display the desired trip odometer to be reset then push and hold the button until the display resets (ap- proximately 2 seconds). 14. Cruise Indicator This display indicator shows that the Speed Control System is ON.
Page 144 144 UNDERSTANDING YOUR INSTRUMENT PANEL 19. Oil Pressure Warning Light This light shows low engine oil pressure. The light should turn on momentarily when the engine is started. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A continuous chime will sound when this light turns on.
Page 145: Electronic Vehicle Information Center (Evic)
tire to overheat and can lead to tire failure. Underinfla- tion also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability. Each tire, including the spare, should be checked monthly when cold and set to the recommended inflation pressure as specified in the tire and loading information placard and owner’s manual.
Page 146 146 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing the MENU button will change the displayed programming features. Pressing the STEP button will display the available choices. Pressing the MENU button a second time accepts a selected choice. When the appropriate conditions exist, the Electronic Vehicle Information Center (EVIC) displays the following messages.
Page 147 • TOO COLD FOR PWR LIFTGATE (with a single chime) • TOO HOT FOR PWR LIFTGATE (with a single chime) • PERFORM SERVICE (with a single chime) • LEFT/RIGHT FRONT DOOR AJAR (one or more, with a single chime if speed is above 1 mph) •...
Page 148: Customer Programmable Features - If Equipped
148 UNDERSTANDING YOUR INSTRUMENT PANEL • SERVICE TIRE SYSTEM SOON (Refer to “Starting And Operating, Tire Section”) • TIRE PRESSURE UNAVAILABLE (Refer to “Starting And Operating, Tire Section”) • TCS SUSPENDED (Traction Control System, with a graphic and single chime) •...
Page 149 Auto Unlock On Exit? When this feature is selected all the vehicle’s doors will unlock when the driver’s door is opened if the vehicle is stopped and the transmission is in P (Park) or N (Neu- tral) position. Pressing the STEP button when in this display will select “Yes”...
Page 150 150 UNDERSTANDING YOUR INSTRUMENT PANEL Flash Lights On Lock/Unlock? When this feature is selected, the front and rear turn signals will flash when the doors are locked or unlocked using the remote keyless entry transmitter. This feature may be selected with or without the sound horn on lock feature selected.
Page 151: Compass Display - If Equipped
Reset Service Distance (Displays Only if Service Interval was Changed) When this feature is selected the current accumulated service distance can be reset to the newly selected service interval. Pressing the STEP button when in this display will select “Yes” or “No.” Power Accessory Delay? When this feature is selected, the power window switches, radio, hands–free system, DVD video system,...
Page 152 152 UNDERSTANDING YOUR INSTRUMENT PANEL display “COMPASS CALIBRATING” until the compass is calibrated. The compass will calibrate automatically after approximately 40 seconds if no buttons are pressed and the vehicle is in Park. You may also calibrate the compass by completing one 360° turn in an area free from large metal or metallic objects, the “COMPASS CALI- BRATING”...
Page 153: Mini-Trip Functions - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 153 To set the variance: Turn the ignition switch ON and set the display to Compass. Press the RESET button for approximately 5 seconds but no more than 10 seconds. The “COMPASS VARIANCE” message and the last vari- ance zone number will be displayed.
Page 154: Setting The Analog Clock
154 UNDERSTANDING YOUR INSTRUMENT PANEL • Off Mode Shows a blank display. • Step Button Push this button to cycle through all the Mini-trip functions. To Reset The Display Pressing and releasing the Reset button once will clear the resettable function currently being displayed. The resettable function is average fuel economy.
Page 155: Sales Code Rah-Am & Fm Stereo Radio With Cd Player And Cd/Dvd Changer Controls
SALES CODE RAH—AM & FM STEREO RADIO WITH CD PLAYER AND CD/DVD CHANGER CONTROLS UNDERSTANDING YOUR INSTRUMENT PANEL 155 Radio Operation Power/Volume Control Press the ON/VOL control to turn the radio on. Turn the volume control clockwise to increase the volume. NOTE: Power to operate the radio is supplied through the ignition switch.
Page 156 156 UNDERSTANDING YOUR INSTRUMENT PANEL Seek Press and release the SEEK button to search for the next station in either the AM, FM or Satellite mode. Press the top of the button to seek up and the bottom to seek down. The radio will remain tuned to the new station until you make another selection.
Page 157: Cd Player Operation
You may add a second station to each push-button by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 158 158 UNDERSTANDING YOUR INSTRUMENT PANEL Inserting The Compact Disc CAUTION! This CD player will accept only 4–3/4 inch (12cm) discs only. The use of other sized discs may damage the CD player mechanism. You may either insert or eject a disc with the radio OFF. If you insert a disc with the ignition ON and the radio OFF, the display will show the time of day.
Page 159: Cd/Dvd Changer Operation
RND — Random Play Press the RND button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the SEEK button to move to the next randomly selected track.
Page 160: Sales Code Rbp-Am & Fm Stereo Radio With Cassette Tape Player, Cd Player, And Optional Cd/Dvd Changer Controls
160 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RBP—AM & FM STEREO RADIO WITH CASSETTE TAPE PLAYER, CD PLAYER, AND OPTIONAL CD/DVD CHANGER CONTROLS Radio Operation Power/Volume Control Press the ON/VOL control to turn the radio on. Turn the volume control to the right to increase the volume. NOTE: Power to operate the radio is supplied through the ignition switch.
Page 161 Toggle the PTY button to select the following format types: Program Type Radio Display Adult Hits Adlt Hit Classical Classicl Classic Rock Cls Rock College College Country Country Information Inform Jazz Jazz Foreign Language Language News News Nostalgia Nostalga Oldies Oldies Personality Persnlty...
Page 162 162 UNDERSTANDING YOUR INSTRUMENT PANEL The radio display will flash “SEEK” and the selected PTY program type when searching for the next PTY station. If no station is found with the selected PTY program type, the radio will return to the last preset station. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station.
Page 163 Fade The Fade control provides for balance between the front and rear speakers. Press the FADE button in and it will pop out. Adjust the balance and push the button back in. Tone Control The tone controls affect the BASS and TREBLE frequency bands.
Page 164: Tape Player Operation
164 UNDERSTANDING YOUR INSTRUMENT PANEL To set the clock, use a ballpoint pen or similar object to press the hour (H) or minute (M) buttons on the radio, The time setting will increase each time you press the button. Press any other button to exit from the clock setting mode.
Page 165 Seek Press the SEEK button up for the next selection on the tape and down to return to the beginning of the current selection. Press the SEEK button up or down to move the track number to skip forward or backward 1 to 7 selections. Press the SEEK button once to move 1 selection, twice to move 2 selections, etc.
Page 166: Cd Player Operation
166 UNDERSTANDING YOUR INSTRUMENT PANEL Pinch Roller Release If ignition power or the radio ON/OFF switch are turned off, the pinch roller will automatically retract to protect the tape from any damage. When power is restored to the tape player, the pinch roller will automatically reengage and the tape will resume play.
Page 167 Seek Press the top of the SEEK button for the next selection on the CD. Press the bottom of the button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first second of the current selection.
Page 168: Cd/Dvd Changer Operation - If Equipped
168 UNDERSTANDING YOUR INSTRUMENT PANEL To select Satellite Radio (if equipped), press the MODE button until the word SIRIUS™ appears. The following will be displayed in this order: After three seconds, the current channel name and number will be displayed for five seconds.
Page 169 FF/RW — TUNE Press and hold the FF button for fast forward. Press and hold the RW button for fast reverse. The audio output can be heard when fast forward and fast reverse are acti- vated. Disc Down/Program Button 5 Press the DISC (button 5) button to play the previous disc.
Page 170: Disc Cd/Digital Video Disc (Dvd) Changer
170 UNDERSTANDING YOUR INSTRUMENT PANEL 6 DISC CD/DIGITAL VIDEO DISC (DVD) CHANGER The Rear Seat Audio/Video System allows passengers to listen to a CD or DVD from the 6 disc CD/DVD changer through the headphones, while the front seat passengers listen to either AM/FM, Cassette or CDs from the radio.
Page 171: Eject (Ejt) Button
4. Repeat the process for loading any additional CD/ DVDs. The CD/DVD changer will stop while additional CD/DVDs are loaded. If the volume control is ON, the unit will switch from radio to CD/DVD mode and begin to play. The radio display will show the chapter number and index time in hours and minutes of the DVD, and the track number, minutes and second of the CD.
Page 172: Operating Instructions - Remote Control
172 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Remote Control Power Button (PWR) Pressing the “POWER” button will turn the rear audio/ video system ON/OFF. The headphone symbol will flash for approximately 5 seconds in the radio display and sound can be heard from the headphones. NOTE: •...
Page 173 MODE Button No Function SEEK Button • CD/DVD changer Press the right side of the “SEEK” button for the next chapter or track on the disc. Press the left side to return to the beginning of the current chapter or track. Press the left side of the “SEEK”...
Page 174: Operating Instructions - Video Screen
174 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Video Screen Push up on the release button to lower the video screen. 1. Screen Width Button Changes the width of the screen picture. 2. Enter Button This button will enter the selection from the on-screen menu.
Page 175: Operating Instructions - Headphones
Operating Instructions — Headphones 1. ON/OFF Button 2. Scan Button 3. Volume Control 4. LED UNDERSTANDING YOUR INSTRUMENT PANEL 175 Power Button Pressing the power button will turn the headphones ON/OFF. NOTE: • The headphones will turn off automatically and the red LED will illuminate for approximately 2 minutes when the radio or rear audio/video system is turned off.
Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL Scan Button Pressing the scan button will automatically find the audio signal that is transmitted from the CD/DVD changer when the rear audio/video system and the headphones are on. This button is used only if the headphones are locked on to a source other than the vehicle’s radio.
Page 177: Operating Instructions - Mp3 Player
General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 178: Remote Sound System Controls
178 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the rear surface of the steering wheel at the 3 and 9 o’clock positions. The right hand rocker switch has a push button in the center and controls the volume and mode of the sound system.
Page 179: Cd Player
CD Player Pressing the top of the switch once will go to the next track on the CD. Pressing the bottom of the switch once will go to the beginning of the current track or to the beginning of the previous track if it is within one second after the current track begins to play.
Page 180: Am Reception
180 UNDERSTANDING YOUR INSTRUMENT PANEL AM Reception AM sound is based on wave amplitude, so AM reception can be disrupted by such things as lightning, power lines and neon signs. FM Reception Because FM transmission is based on frequency varia- tions, interference that consists of amplitude variations can be filtered out, leaving the reception relatively clear, which is the major feature of FM radio.
Page 181: Cd/Dvd Disc Maintenance
Maintain your cassette tape player. The head and capstan shaft in the cassette player can pick up dirt or tape deposits each time a cassette is played. The result of deposits on the capstan shaft may cause the tape to wrap around and become lodged in the tape transport.
Page 182: Radio Operation And Cellular Phones
182 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the cellular phone being On in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna. This condition is not harmful to the radio.
Page 183: Dual-Zone Automatic Temperature Control
To replace the navigation map DVD lift the storage bin cover and liner in the rear cargo area, press the eject button and the disc will eject. Gently insert the new disc into the DVD unit with the label facing up. The disc will automatically be pulled into the DVD unit.
Page 184 184 UNDERSTANDING YOUR INSTRUMENT PANEL regulates the heating and air conditioning system includ- ing blower speed, outlet air temperature, and airflow distribution through the various outlets within the in- strument panel. Using the TEMP buttons, adjust the temperature you would like the system to maintain. When the system is set to your comfort level, it is not necessary to change the settings.
Page 185 • The “DELAY” symbol will flash to indicate that the feature as been disabled. This feature may be enabled using the following proce- dure: • Press and hold the Heated Rear Window and Auto HI buttons for 5 seconds. • The “DELAY” symbol will flash to indicate that the feature as been enabled.
Page 186 186 UNDERSTANDING YOUR INSTRUMENT PANEL The front blower control can be set to any fixed blower speed by pressing the rocker switch up or down. This allows the front occupants to control the volume of air circulated in the vehicle and cancel the auto mode.
Page 187 Bi-Level Mode Air comes from both the instrument panel outlets and floor outlets. A slight amount of air is also directed through the defrost and side window demister outlets. NOTE: In many temperature positions, the bi-level mode is designed to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 188 188 UNDERSTANDING YOUR INSTRUMENT PANEL Mix Mode Air comes from the floor, defrost and side window demist outlets. This mode is not used when operating in either AUTO HI or AUTO LO . This mode should be used when airflow to the floor and windshield is desired. Defrost Mode Air comes from the windshield and side window demist outlets.
Page 189 NOTE: While operating in AUTO HI or AUTO LO , the system will not automatically sense the presence fog, mist, or ice on the windshield. The defrost button must be pressed to clear the windshield and side glass. Depress the “A/C” button to turn on and off the air conditioning during manual operation only.
Page 190 190 UNDERSTANDING YOUR INSTRUMENT PANEL A/C Recirculation Programming The recirculation control is programmed to cancel the recirculation mode when the ignition key is turned OFF and will reset to the outside air mode when the ignition key is turned “ON”. The frequent use of outside air will help keep odors from building up within the air conditioner-heater housing.
Page 191 Rear Fan Operation To operate the rear fan, press the REAR button. The first time this button is pressed the REAR AUTO display will illuminate indicating that the rear fan speed is automatically controlled. To manually control the rear fan speed, press the REAR button again and only REAR will illuminate in the display.
Page 192 192 UNDERSTANDING YOUR INSTRUMENT PANEL Use of the air Recirculation mode during winter months is not recommended because it may cause window fogging. Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e. vacation) for two weeks or more, run the air condi- tioning system at idle for about five minutes in the fresh air and high blower setting.
Page 193: Electric Rear Window Defroster
Outside Temperature Display The outside temperature can be shown in the ATC display by pressing the OUTSIDE TEMP button. After pressing this button, the front seat passenger’s tempera- ture setting display will be replaced with the current outside temperature. Press the OUTSIDE TEMP button again or press the passenger’s TEMP button to return the display to the passenger’s temperature setting.
Page 195: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 198 Normal Starting ..... . 198 Engine Block Heater —...
Page 196 196 STARTING AND OPERATING Tire Safety Information ....213 Tire Markings ......213 Tire Identification Number (TIN) .
Page 197 Gasoline/Oxygenate Blends ....236 MMT In Gasoline ..... 237 Sulfur In Gasoline .
Page 198: Starting Procedures
198 STARTING AND OPERATING STARTING PROCEDURES CAUTION! Long periods of engine idling, especially at high engine speeds, can cause excessive exhaust tempera- tures which can damage your vehicle. Do not leave your vehicle unattended with the engine running. WARNING! Do not leave animals or children inside parked vehicles in hot weather;...
Page 199 WARNING! • Do not attempt to push or tow your vehicle to get it started. Vehicles equipped with an automatic transmission cannot be started this way. Un- burned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle.
Page 200: Engine Block Heater - If Equipped
200 STARTING AND OPERATING If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released. If this occurs, continue cranking up to 15 seconds with the accelerator pedal pushed all the way to the floor.
Page 201: Automatic Transmission
AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 202: Automatic Transmission Ignition Interlock System
202 STARTING AND OPERATING Automatic Transmission Ignition Interlock System This system prevents the key from being removed unless the shift lever is in PARK. It also prevents shifting out of PARK unless the key is in the ACCESSORY or ON position.
Page 203 NOTE: Even if the transmission can be reset, it is recommended that you visit a dealer at your earliest possible convenience. Your dealer has diagnostic equip- ment to determine if the problem could recur. If the transmission cannot be reset, dealer service is required.
Page 204: Autostick
204 STARTING AND OPERATING AUTOSTICK Autostick is a driver-interactive transmission that offers manual gear shifting capability to provide you with more control. Autostick allows you to maximize engine brak- ing, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can also provide you with more control during passing, city driving, cold slippery conditions, mountain driving, trailer towing, and many other situations.
Page 205: All Wheel Drive - If Equipped
• You can start out in first, second, or third gear. Shifting into fourth gear can occur only after vehicle speed reaches 15 mph (24 km/h). • The transmission will automatically downshift to first gear when coming to a stop. •...
Page 206: Parking Brake
206 STARTING AND OPERATING CAUTION! All wheels must have the same size and type tires. Unequal tire sizes must not be used. Unequal tire size may cause failure of the power transfer unit and/or the viscous coupling. PARKING BRAKE When the parking brake is applied with the ignition switch on, the brake light in the instrument cluster will turn on.
Page 207 When parking on a hill, it is important to set the parking brake before placing the gear selector in Park, otherwise the load on the transmission locking mechanism may make it difficult to move the selector out of park. As an added precaution, turn the front wheels toward the curb on a downhill grade and away from the curb on a uphill grade.
Page 208: Brake System
208 STARTING AND OPERATING BRAKE SYSTEM In the event power assist is lost for any reason (for example, repeated brake applications with the engine off), the brakes will still function. The effort required to brake the vehicle will be much greater than that required with the power system operating.
Page 209 WARNING! • Anti-lock system (ABS) cannot prevent the natu- ral laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency be- yond that afforded by the condition of the vehicle brakes and tires or the traction afforded. •...
Page 210 210 STARTING AND OPERATING When the vehicle is driven over 7 mph (11 km/h), you may also hear a slight clicking sound as well as some related motor noises. These noises are the system per- forming its self check cycle to ensure that the ABS system is working properly.
Page 211: Power Steering
POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason, the power assist is interrupted, it will still be possible to steer your vehicle.
Page 212: Traction Control - If Equipped
212 STARTING AND OPERATING TRACTION CONTROL — IF EQUIPPED The Traction Control System reduces wheel slip and maintains traction at the driving (front) wheels. The system reduces wheel slip by engaging the brake on the wheel that is losing traction (spinning). The system will operate at speeds below 35 mph (56 km/h).
Page 213: Tire Safety Information
NOTE: • The Traction Control system will make buzzing or clicking sounds when in operation. • Extended heavy use of Traction Control may cause the system to deactivate and turn on the traction control indicator located in the instrument cluster. This is to prevent overheating of the brake system and is a normal condition.
Page 214 214 STARTING AND OPERATING • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter P is absent from this tire size designation.
Page 215 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Milimeters (mm) 65 = Aspect Ratio in Percent (%)
Page 216 216 STARTING AND OPERATING Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions.
Page 217: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire however the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code located on the white sidewall side of the tire. = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 218: Tire Loading And Tire Pressure
218 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: Some vehicles have a “Tire and Loading Infor- mation” placard located on the driver’s side “B” pillar. Tire and Loading Information Placard This placard tells you important information about the, 1) number of people that can be carried in the vehicle 2) the total weight your vehicle can carry 3) the tire size designed for your vehicle...
Page 219 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size and cold tire inflation pressures specified on the Tire and Loading Information placard and the Vehicle Loading section of this manual.
Page 220 220 STARTING AND OPERATING 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1400 lbs. and there will be five 150 lb. passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lb.
Page 221 STARTING AND OPERATING 221...
Page 222: Tires-General Information
222 STARTING AND OPERATING WARNING! Overloading of your tire is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle-never overload them. TIRES—GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 223: Tire Inflation Pressures
2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Underinflation also increases tire rolling resistance and results in higher fuel consumption. 3.
Page 224 224 STARTING AND OPERATING The pressure should be checked and adjusted as well as inspecting for signs of tire wear or visible damage at least once a month. Use a good quality pocket-type gauge to check tire pressure. Do not make a visual judgement when determining proper inflation.
Page 225 Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) during operation. DO NOT reduce this normal pressure build up or your tire pressure will be too low. Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits.
Page 226: Radial-Ply Tires
226 STARTING AND OPERATING Radial-Ply Tires WARNING! Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle poorly. The instability could cause an accident. Al- ways use radial ply tires in sets of four (or 6, in case of trucks with dual rear wheels).
Page 227: Tire Spinning
Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, since the wheel is designed specifically for the compact spare. CAUTION! Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with the compact spare installed.
Page 228: Tread Wear Indicators
228 STARTING AND OPERATING Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. These indicators are molded into the bottom of the tread grooves and will appear as bands when the tread depth becomes 1/16 inch (2 mm).
Page 229: Alignment And Balance
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspen- sion dimensions and performance characteristics, resulting in changes to steering, handling, and brak- ing of your vehicle.
Page 230: All Wheel Drive (Awd) - If Equipped
230 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. ALL WHEEL DRIVE (AWD) — IF EQUIPPED CAUTION! All Wheel Drive (AWD) vehicles must have the same size and type tires on all wheel positions.
Page 231: 1,2,3, Or 4 Tire(S) Low Pressure
1,2,3, OR 4 TIRE(S) LOW PRESSURE Low tire pressure levels of 25 psi [1.72 bars] (172 kPa) or less detected in one or more tires. Inspect all tires for proper inflation pressure, once the proper tire pressure has been set, the TPM system warning will reset automatically when the vehicle has been driven for at least 2 minutes at or above 20 mph (32 km/h).
Page 232 232 STARTING AND OPERATING CAUTION! The TPM system has been optimized for the original equipment tires and wheels. TPM system pressures have been established for the tire size equipped on your vehicle. Undesirable system operation or sen- sor damage may result when using replacement equipment that is not of the same size, type, and/or style.
Page 233: General Information
General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 234: Snow Tires
234 STARTING AND OPERATING NOTE: In order to avoid damage to tires, chains, and your vehicle do not drive for a prolonged period of time on dry pavement. Observe the tire chain manufacturer’s instructions on method of installation, operating speed, and conditions for usage.
Page 235: Fuel Requirements
Section of this manual. More frequent rotation is permis- sible if desired. The reasons for any rapid or unusual wear should be corrected prior to rotation being per- formed. NOTE: The Tire Pressure Monitor system must be retrained following a tire rotation. See your authorized dealer for service.
Page 236: Reformulated Gasoline
236 STARTING AND OPERATING Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, engine performance, and durability for your vehicle. The manufacturer recommends the use of gasolines that meet the WWFC specifications if they are available.
Page 237: Mmt In Gasoline
may not be covered by the vehicle warranty. While MTBE is an oxygenate made from Methanol, it does not have the negative effects of Methanol. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase the octane num- ber.
Page 238: Materials Added To Fuel
238 STARTING AND OPERATING CAUTION! If the Malfunction Indicator light is flash- ing, immediate service is required. Refer to the paragraph on the Onboard Diagnostics System in section 7 of this manual. Materials Added to Fuel All gasoline sold in the United States is required to contain effective detergent additives.
Page 239: Carbon Monoxide Warnings
• The use of fuel additives which are now being sold as octane enhancers are not recommended. Most of these products contain high concentrations of methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives are not the responsibility of the manufacturer and may not be covered under the New Vehicle Warranty.
Page 240: Adding Fuel
240 STARTING AND OPERATING ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle. CAUTION! Damage to the fuel system or emission control system could result from using an improper fuel...
Page 241: Vehicle Loading
WARNING! • Remove the fuel tank filler tube cap (gas cap) slowly to prevent fuel spray from the filler neck which may cause injury. • The volatility of some gasolines may cause a buildup of pressure in the fuel tank that may increase while you drive.
Page 242: Gross Vehicle Weight Rating (Gvwr)
242 STARTING AND OPERATING • Vehicle Identification Number (VIN) • Type of Vehicle • Month Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the Vehicle Identification Number (VIN). Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle.
Page 243: Loading
Figure out the weight on the front and rear of the vehicle separately. It is important that you distribute the load evenly over the front and rear axles. Overloading can cause potential safety hazards and shorten useful service life. Heavier axles or suspension components do not necessarily increase the vehicle’s GVWR.
Page 244: Trailer Towing
244 STARTING AND OPERATING Empty Weight Load (Including driver, pass- sengers and cargo) Total GAWR TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully re- view this information to tow your load as efficiently and safely as possible.
Page 245: Warranty Requirements
Warranty Requirements The Manufacturer’s Passenger Vehicle Warranty will apply to vehicles used to tow trailers for non-commercial use. However the following conditions must be met: • The maximum frontal area of the trailer cannot exceed 20 square feet (1.86 square meters). •...
Page 246 246 STARTING AND OPERATING • The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation. See Schedule “B” in section 8 of this manual for transmission fluid change intervals.
Page 247 A load equalizing hitch is recommended for loaded trailer weights above 1,000 lbs (454 kg) and required for weights above 2,000 lbs (907 kg). CAUTION! If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they should be of adequate capacity.
Page 249: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....250 If Your Engine Overheats ....251 Jacking And Tire Changing .
Page 250: Hazard Warning Flasher
250 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The hazard flasher switch is located in the center of the instrument panel above the center air outlets. To engage the Hazard Warning Flashers, depress the switch on the instrument panel. When the Hazard Warn- ing Switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emer- gency.
Page 251: If Your Engine Overheats
IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. • In city traffic — While stopped, put transmission in neutral, but do not increase engine idle speed.
Page 252: Jacking And Tire Changing
252 WHAT TO DO IN EMERGENCIES WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, see Section 7, Maintenance, of this manual.
Page 253: Jack Location
Jack Location The jack and jack-handle are stowed in the rear storage bin located in the rear cargo floor. Pull up on the storage bin cover and liner to access the jack and jack tools. WHAT TO DO IN EMERGENCIES 253 Spare Tire Stowage The spare tire is stowed under the rear of the vehicle by means of a cable winch mechanism.
Page 254: Preparations For Jacking
254 WHAT TO DO IN EMERGENCIES Spare Tire Removal Fit the jack-handle over the drive nut. Rotate the nut to the left until the spare is on the ground with enough slack cable to allow you to pull the tire out from under the vehicle.
Page 255: Jacking Instructions
• Passengers should not remain in the vehicle when the vehicle is being jacked. Jacking Instructions 1. Remove the spare wheel, scissors jack and jack-handle from stowage. 2. Carefully pry off the wheel center cap using the tip of the jack handle. 3.
Page 256 256 WHAT TO DO IN EMERGENCIES location. Do not raise the vehicle until you are sure the jack is securely engaged. Never jack up the vehicle using any suspension components. 6. Raise the vehicle by turning the jack screw to the right, using the swivel wrench.
Page 257 WARNING! A loose tire or jack, thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle. Always stow the jack parts and the spare tire in the places provided. 12. Secure the flat or spare tire as follows: •...
Page 258: Jump-Starting Procedures If Battery Is Low
258 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES IF BATTERY IS WARNING! Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is on. You can be hurt by the fan. WARNING! •...
Page 259: Driving On Slippery Surfaces
1. Wear eye protection and remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact. 2. When boost is provided by a battery in another vehicle, park that vehicle within booster cable reach and without letting the vehicles touch.
Page 260: Traction
260 WHAT TO DO IN EMERGENCIES WARNING! Rapid acceleration on slippery surfaces is danger- ous. Unequal traction can cause sudden pulling of the front wheels. You could lose control of the vehicle and possibly have an accident. Accelerate slowly and carefully whenever there is likely to be poor traction (ice, snow, wet mud, loose sand, etc.).
Page 261: Towing A Disabled Vehicle
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck. And don’t let anyone near a spinning wheel, no matter what the speed.
Page 262 262 WHAT TO DO IN EMERGENCIES All Wheel Drive Your vehicle may be towed under the following condi- tions: The gear selector must be in NEUTRAL, the distance to be traveled must not exceed 100 miles (160 km), the towing speed must not exceed 44 mph (72 km/h), and both front and rear wheels must be on the ground.
Page 263: Without The Ignition Key
If it is necessary to use the accessories while being towed (wipers, defrosters, etc.), the key must be in the ON position, not the ACCESSORY position. Make certain the transmission remains in NEUTRAL. Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the LOCK position.
Page 265: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS 3.5L Engine ......268 Onboard Diagnostic System — OBD II ..269 Emissions Inspection And Maintenance Programs .
Page 266 266 MAINTAINING YOUR VEHICLE Steering Shaft Seal ....283 Steering Linkage ..... . 283 Drive Shaft Universal Joints .
Page 267 Front Park/Turn Signal And Sidemarker Lights ......309 Front Fog Light ..... . 309 Rear Tail, Stop, Turn Signal, Side Marker And Back-Up Lights .
Page 268: 3.5L Engine
268 MAINTAINING YOUR VEHICLE 3.5L ENGINE...
Page 269: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 270: Emissions Inspection And Maintenance Programs
270 MAINTAINING YOUR VEHICLE EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system. Failure to pass could prevent vehicle registration. For states which have an I/M (Inspection and Maintenance) requirement, this check verifies the following: the MIL (Malfunction Indicator Lamp) is functioning and is not on when the engine is running,...
Page 271: Replacement Parts
a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn off the ignition key or start the engine. This means that your vehicle’s OBD system is not ready and you should not proceed to the I/M station.
Page 272: Maintenance Procedures
272 MAINTAINING YOUR VEHICLE NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the proper equipment.
Page 273 The best time to check the engine oil level is about 5 minutes after a fully warmed engine is shut off or before starting the engine after it has sat overnight. Checking the oil while the vehicle is on level ground will improve the accuracy of the oil level readings.
Page 274 274 MAINTAINING YOUR VEHICLE Change Engine Oil Road conditions and your kind of driving affects the interval at which your oil should be changed. Check the following list to see if any apply to you. • Day or night temperatures are below 32°F (0°C). •...
Page 275 American Petroleum Institute (API) Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). The manufacture only recommends API Certified engine oils that meet requirements DaimlerChrysler Material Stan- dard MS-6395. Use Mopar or an equivalent oil meeting the specifi- cation MS-6395.
Page 276: Engine Oil Filter
276 MAINTAINING YOUR VEHICLE Synthetic Engine Oils You may use synthetic engine oils provided that the recommended oil quality requirements are met and the recommended maintenance intervals for oil and filter changes are followed. Materials Added to Engine Oil The manufacture strongly recommends against the addi- tion of any additives (other than leak detection dyes) to the engine oil.
Page 277: Spark Plugs
Also check belt routing to make sure there is no interfer- ence between the belts and other engine components. Spark Plugs Spark plugs must fire properly to assure engine perfor- mance and emission control. New plugs should be in- stalled at the specified mileage. The entire set should be replaced if there is any malfunction due to a faulty spark plug.
Page 278: Catalytic Converter
278 MAINTAINING YOUR VEHICLE Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
Page 279: Maintenance-Free Battery
WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your ex- haust system. Do not park or operate your vehicle in areas where your exhaust system can contact any- thing that can burn.
Page 280 280 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 281: Air Conditioner
Air Conditioner For best possible performance, your air conditioner should be checked and serviced by an Authorized Dealer at the start of each warm season. This service should include cleaning of the condenser fins and a system performance check. Drive belt tension should also be checked at this time.
Page 282: Power Steering - Fluid Check
282 MAINTAINING YOUR VEHICLE Refrigerant Recovery And Recycling The air conditioning system of your vehicle contains R-134a, a refrigerant that does not deplete the ozone layer in the upper atmosphere. The manufacture recommends that air conditioning service be done by facilities using refrigerant recycling and recovery equipment that meets SAE standard J1991.
Page 283: Front & Rear Suspension Ball Joints
WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to insure accurate fluid level reading. Do not overfill. Use only manufacturers recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
Page 284: Body Lubrication
284 MAINTAINING YOUR VEHICLE Continued operation could result in failure of the univer- sal joint due to water and dirt contamination of the grease. This would require complete replacement of the joint assembly. Body Lubrication Locks and all body pivot points, including such items as seat tracks, doors, liftgate and hood hinges, should be lubricated periodically to assure quiet, easy operation and to protect against rust and wear.
Page 285: Windshield And Rear Window Washers
Windshield and Rear Window Washers The fluid reservoir for the windshield washers and the rear window washer is shared. It is located in the engine compartment and should be checked for fluid level at regular intervals. Fill the reservoir with windshield washer solvent (not radiator antifreeze) and operate the system for a few seconds to flush out the residual water.
Page 286: Cooling System
286 MAINTAINING YOUR VEHICLE Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- plete exhaust system and adjacent body areas for broken, damaged, deteriorated, or mispositioned parts.
Page 287 Coolant Checks Coolant protection checks should be made every 12 months (prior to the onset of freezing weather, where applicable). If coolant is dirty or rusty in appearance, the system should be drained, flushed and refilled with fresh coolant. Check the front of the A/C condenser for any accumulation of bugs, leaves, etc.
Page 288 288 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of coolants other than the specified HOAT coolant may result in decreased corrosion protec- tion and engine damage that may not be covered under the new vehicle warranty. If a non-HOAT coolant is introduced into the cooling system in an emergency, it should be replaced with the speci- fied coolant as soon as possible.
Page 289 Coolant Pressure Cap The coolant pressure cap must be fully tightened to prevent loss of coolant, and to insure that coolant will return to the coolant bottle from the overflow tank. The coolant pressure cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces.
Page 290 290 MAINTAINING YOUR VEHICLE Disposal of Used Engine Coolant Used ethylene glycol based engine coolant is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community. To prevent ingestion by animals or children do not store ethylene glycol based engine coolant in open containers or allow it to remain in puddles on the ground.
Page 291: Hoses And Vacuum/Vapor Harnesses
• If frequent coolant additions are required, the cooling system should be pressure tested for leaks. • Maintain coolant concentration at 50% ethylene glycol antifreeze (minimum) in water for proper corrosion protection of your engine which contains aluminum components. • Make sure that the radiator and coolant bottle hoses are not kinked or obstructed.
Page 292: Brakes
292 MAINTAINING YOUR VEHICLE Brakes In order to assure brake system performance, all brake system components should be inspected periodically. Suggested service intervals can be found in the Mainte- nance Schedules. WARNING! Riding the brakes can lead to brake failure and possibly an accident.
Page 293: Master Cylinder - Abs Brakes Brake Fluid Level Check
NOTE: Inspection of brake hoses should be performed whenever the brake system is serviced and at every engine oil change. Inspect hydraulic brake hoses for surface cracking, scuffing, or worn spots. If there is any evidence of cracking, scuffing, or worn spots, the hose should be replaced immediately! Eventual deterioration of the hose can take place resulting in a possibility of a burst failure.
Page 294: Fuel System Hoses
294 MAINTAINING YOUR VEHICLE Use only manufacturers recommended brake fluid, refer to Recommended Fluids, Lubricants and Genuine Parts for correct fluid type. WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire.
Page 295: Automatic Transmission
You are urged to use only the manufacture specified hoses with quick connect fittings, or their equivalent in material and specification, in any fuel system servicing. It is mandatory to replace any damaged hoses or quick connect fittings that have been removed during service. Care should be taken in installing quick connect fittings to insure they are properly installed and fully connected.
Page 296 296 MAINTAINING YOUR VEHICLE CAUTION! Using a transmission fluid other than the manufac- turers recommended fluid may cause deterioration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than the manufacturers recommended fluid will result in more frequent fluid and filter changes.
Page 297 5. Remove the dipstick and determine if the fluid is hot or warm. Hot fluid is approximately 180°F (82°C), which is the normal operating temperature after the vehicle has been driven at least 15 miles (24 km). The fluid cannot be comfortably held between the finger tips.
Page 298: All Wheel Drive (Awd) - If Equipped
298 MAINTAINING YOUR VEHICLE • Police, taxi, limousine, commercial type operation, or trailer towing where the vehicle driven regularly for more than 45 minutes of continuous operation. NOTE: Refer to Section 8 of this manual for Mainte- nance Schedules. If the transmission is disassembled for any reason, the fluid and filter should be changed.
Page 299 Overrunning Clutch The fill plug is located on the side of the overrunning clutch housing. The fluid should be maintained at a level even with the bottom of the fill plug hole when the vehicle is parked on a level surface. If it becomes neces- sary to add or replace the fluid, use only the manufac- turers recommended transmission fluid, refer to Recom- mended Fluids, Lubricants and Genuine Parts for correct...
Page 300: Front And Rear Wheel Bearings
300 MAINTAINING YOUR VEHICLE Front And Rear Wheel Bearings Front and rear wheel bearings are permanently sealed. No regular maintenance is required for these compo- nents. Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 301 Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using a mild car wash soap, and rinse the panels completely with clear water. • If insects, tar or other similar deposits have accumu- lated on your vehicle, wash it as soon as possible. •...
Page 302 302 MAINTAINING YOUR VEHICLE • If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective coating have your vehicle repaired as soon as possible. The cost of such repairs is considered the responsibil- ity of the owner.
Page 303 Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and Mopar Total Clean.
Page 304: Cleaning The Center Console Cup Holders
304 MAINTAINING YOUR VEHICLE 1. Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners. If soap is used, wipe clean with a clean damp rag. 2. Dry with a soft tissue. Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners.
Page 305: Integrated Power Module (Ipm)
INTEGRATED POWER MODULE (IPM) An Integrated Power Module is located in the engine compartment near the battery. This center contains fuses and relays. A label that identifies each component is printed on the inside of the cover. MAINTAINING YOUR VEHICLE 305 CAUTION! •...
Page 306: Vehicle Storage
306 MAINTAINING YOUR VEHICLE VEHICLE STORAGE If you are leaving your vehicle dormant for more than 21 days you may want to take steps to protect your battery. You may: • Disconnect the negative cable from the battery. • Anytime you store your vehicle, or keep it out of service (i.e.
Page 307: Bulb Replacement
LIGHT BULBS — Exterior Back-up ....... 921 Rear Stop, Turn Signal ....3157 Rear Sidemarker .
Page 308: High Intensity Discharge Headlights (Hid) - If Equipped
308 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. High Intensity Discharge Headlights (HID) — If Equipped The headlights are a type of high voltage discharge tube.
Page 309: Front Park/Turn Signal And Sidemarker Lights
Front Park/Turn Signal and Sidemarker Lights 1. Remove the two screws securing the headlight mod- ule to the vehicle and pull the headlight module forward away from the vehicle. MAINTAINING YOUR VEHICLE 309 2. Twist the bulb socket to remove from the headlight module and pull the bulb from socket.
Page 310: Rear Tail, Stop, Turn Signal, Side Marker And Back-Up Lights
310 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. Rear Tail, Stop, Turn Signal, Side Marker and Back-up Lights 1.
Page 311: License Light
License Light 1. Place a screwdriver in the slot next to the release tab and push on the release tab to remove the lens. 2. Unscrew the bulb and remove it from the socket. Replace the bulb and push on the lens until it snaps into place.
Page 312: Recommended Fluids, Lubricants And Genuine Parts
312 MAINTAINING YOUR VEHICLE RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Spark Plugs Oil Filter Fuel Selection Fluids, Lubricants and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) Use API Certified, meeting material standard MS-6395, (GF-3). Refer to oil viscosity chart for correct SAE grade.
Page 313: Chassis
Chassis Component Automatic Transmission AWD Power Transfer Unit AWD Overrunning Clutch AWD Rear Carrier Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts Mopar ATF+4 Automatic Transmission Fluid. Mopar Gear Lubricant 75W-90. Mopar ATF+4 Automatic Transmission Fluid. Mopar Gear Lubricant 75W-90. Mopar DOT 3 and SAE J1703 should be used.
Page 315 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..316 Maintenance Schedules ....316 Schedule “B” ......319 Schedule “A”...
Page 316: Emission Control System Maintenance
316 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 317 • Taxi, police, or delivery service (commercial ser- vice). • Off-road or desert operation. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule “B” of the Maintenance Schedules section of this manual.
Page 318 318 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of coolant bottle, brake master cylinder and transmission, add as needed. •...
Page 319: Schedule "B
SCHEDULE “B” Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. Change the automatic transmission fluid and filter every 60,000 miles (96 000 km) if the vehicle is usually operated under one or more of the conditions marked with an •...
Page 320 320 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. * Change the All Wheel Drive (AWD) power transfer unit fluid.
Page 321 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front & Rear) Inspect the PCV valve and replace as neces- sary.* Change the All Wheel Drive (AWD) power...
Page 322 322 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. * Change the All Wheel Drive power transfer unit fluid.
Page 323 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front & Rear) Inspect the PCV valve and replace if neces- sary.* Inspect the serpentine drive belt, replace if...
Page 324 324 SCHEDULE “B” Miles (Kilometers) Change the All Wheel Drive (AWD) overrun- ning clutch and rear carrier fluid. (See note at the end of this chart) Relpace the air conditioning filter. 57, 000 60, 000 63, 000 66, 000 (91 000) (96 000) (101 000) (106 000) (110 000) 69, 000...
Page 325 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter Replace the spark plugs on 3.5 liter engines. Inspect the tie rod ends and boot seals. (Front &...
Page 326 326 SCHEDULE “B” Miles (Kilometers) Change the All Wheel Drive (AWD) overrun- ning clutch and rear carrier fluid. (See note at the end of this chart) Relpace the air conditioning filter. 75, 000 78, 000 81, 000 84, 000 (120 000) (125 000) (130 000) (134 000) (139 000) 87, 000 90, 000 (144 000)
Page 327 Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter * Change the All Wheel Drive (AWD) power transfer unit fluid. (See note at the end of this chart) Change the All Wheel Drive (AWD) overrun- ning clutch and rear carrier fluid.
Page 328 328 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if neces- sary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front & Rear) Inspect the PCV valve and replace as necessary.* Inspect the serpentine drive belt, replace if neces-...
Page 329 * This maintenance is recommended by the manufacture to the owner but is not required to maintain the emis- sions warranty. ‡ This maintenance is not required if previously replaced. Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all re- ceipts.
Page 330: Schedule "A
330 SCHEDULE “A” SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front &...
Page 331 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front & Rear) Check the PCV valve and replace, if neces- sary.* Inspect the serpentine drive belt, replace if...
Page 332 332 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if neces- sary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front & Rear) Check and replace the PCV valve , if necessary.* Inspect the serpentine drive belt, replace if neces-...
Page 333 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Inspect the brake linings. Inspect the engine air cleaner filter, replace if necessary. * Replace the engine air cleaner filter. Inspect the tie rod ends and boot seals. (Front & Rear) Check the PCV valve and replace, if necessary.* Inspect the serpentine drive belt, replace if necessary.
Page 334 334 SCHEDULE “A” WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 335: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......336 Prepare For The Appointment .
Page 336: Suggestions For Obtaining Service For Your Vehicle
336 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty, discuss additional charges with the service manager.
Page 337 The manufacturer has empowered its dealers to make warranty and repair decisions that ensure you are not inconvenienced. There is no need for you to wait for a decision from the manufacturer. If a special circumstance occurs that requires information from the manufacturer, we have asked the dealer’s service management to make the contact on your behalf.
Page 338 338 IF YOU NEED CONSUMER ASSISTANCE In Mexico contact: Av. Prolongacion Paseo de la Reforma, 1240 Sante Fe C.P. 05109 Mexico, D. F. In Mexico (915) 729–1248 or 729–1240 Outside Mexico (525) 729–1248 or 729–1240 Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni-...
Page 339: Warranty Information
Contract, and you require service after your manufactur- er’s new vehicle limited warranty expires, please refer to your contract documents, and contact the person listed in those documents. We appreciate that you have made a major investment when you purchased your new vehicle. Your dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with your ownership experience.
Page 340: Reporting Safety Defects
340 IF YOU NEED CONSUMER ASSISTANCE REPORTING SAFETY DEFECTS In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administra- tion (NHTSA) in addition to notifying the manufacturer.
Page 341 • Owner’s Manuals. These manuals have been prepared with the assistance of service and engineering specialists to acquaint you with specific Chrysler group vehicles. Included are starting, operating, emergency and maintenance pro- cedures as well as specifications, capabilities and safety tips.
Page 342: Department Of Transportation Uniform Tire Quality Grades
342 IF YOU NEED CONSUMER ASSISTANCE DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following describes the tire grading categories estab- lished by the National highway Traffic Safety Adminis- tration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your car.
Page 343: Temperature Grades
Temperature Grades The temperature grades are A (highest), B, and C, repre- senting the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.
