- Page 1 www.smarterglass.com 978 997 4104 sales@smarterglass.com...
- Page 2 This DATA SHEET is updated document from DOD-PD-0884(3). All information is subject to change without notice. Please confirm the sales representative before starting to design your system. Document Number: DOD-PD-1318 (4th edition) NEC LCD Technologies, Ltd. Published date: February 2006 CP(N) 2004-2006 All rights reserved.
-
Page 3: Introduction
The Copyright to this document belongs to NEC LCD Technologies, Ltd. (hereinafter called "NEC"). No part of this document will be used, reproduced or copied without prior written consent of NEC. NEC does and will not assume any liability for infringement of patents, copyrights or other intellectual property rights of any third party arising out of or in connection with application of the products described herein except for that directly attributable to mechanisms and workmanship thereof. -
Page 4: Table Of Contents
NL204153BM21-01/01A CONTENTS INTRODUCTION ............................2 1. OUTLINE..............................4 1.1 STRUCTURE AND PRINCIPLE......................4 1.2 APPLICATION............................4 1.3 FEATURES.............................4 2. GENERAL SPECIFICATIONS ........................5 3. BLOCK DIAGRAM ...........................6 4. DETAILED SPECIFICATIONS .......................7 4.1 MECHANICAL SPECIFICATIONS......................7 4.2 ABSOLUTE MAXIMUM RATINGS ....................7 4.3 ELECTRICAL CHARACTERISTICS....................8 4.3.1 LCD panel signal processing board ....................8 4.3.2 Backlight lamp ..........................9... -
Page 5: Outline
1. OUTLINE 1.1 STRUCTURE AND PRINCIPLE Monochrome LCD module NL204153BM21-01 and NL204153BM21-01A are composed of the amorphous silicon thin film transistor liquid crystal display (a-Si TFT LCD) panel structure with driver LSIs for driving the TFT (Thin Film Transistor) array and a backlight. -
Page 6: General Specifications
LCD panel signal processing board: 12.0V Edge light type: 6 cold cathode fluorescent lamps (without inverter) Replaceable part Backlight Backlight unit: Type No. 213LHS06 for NL204153BM21-01 213LHS11 for NL204153BM21-01A At IBL= 6.0mArms/lamp, Checkered flag pattern Power consumption 34.2 W (typ., Power dissipation of the inverter is not included.) Note1: When the product luminance is 800cd/m , t he gamma characteristic is designed to =DICOM. -
Page 7: Block Diagram
NL204153BM21-01/01A 3. BLOCK DIAGRAM LCD module (Product) DA0+/– DA1+/– DA2+/– CKA+/– DA3+/– H-driver DB0+/– DB1+/– DB2+/– CKB+/– DB3+/– 6,144 lines DC0+/– DC1+/– TFT LCD panel DC2+/– CKC+/– DC3+/– 1,536 lines DD0+/– H: 2,048 3 (L, C, R) DD1+/– V: 1,536 DD2+/–... -
Page 8: Detailed Specifications
NL204153BM21-01/01A 4. DETAILED SPECIFICATIONS 4.1 MECHANICAL SPECIFICATIONS Parameter Specification Unit Module size Note1, Note2 457.0 0.5 (W) 350.0 0.5 (H) 25.0 0.5 (D) Display area 433.152 (H) 324.864 (V) Note2 Weight 3,800 (typ.), 4,000 (max.) Note1: Excluding warpage of the signal processing board cover and the connection board cover. -
Page 9: Electrical Characteristics
NL204153BM21-01/01A 4.3 ELECTRICAL CHARACTERISTICS 4.3.1 LCD panel signal processing board (Ta = 25 C) Parameter Symbol min. typ. max. Unit Remarks Supply voltage 10.8 12.0 13.2 1,100 Supply current at VDD=12.0V Note1 Note2 Ripple voltage mVp-p for VDD High +100 Differential input threshold at VCM= 1.2V... -
Page 10: Backlight Lamp
NL204153BM21-01/01A 4.3.2 Backlight lamp (Ta=25 C, Note1) Parameter Symbol min. typ. max. Unit Remarks at IBL= 6.0mArms: Lamp current mArms 800 cd/m Note3 Lamp voltage VBLH Vrms Note2, Note3 Ta = 25 C 1,220 Vrms Note2, Note3 Lamp starting voltage... -
Page 11: Power Supply Voltage Ripple
NL204153BM21-01/01A 4.3.3 Power supply voltage ripple This product works, even if the ripple voltage levels are beyond the permissible values as following the table, but there might be noise on the display image. Ripple voltage Note1 Power supply voltage Unit (Measure at input terminal of power supply) 12.0 V... -
Page 12: Power Supply Voltage Sequence
NL204153BM21-01/01A 4.4 POWER SUPPLY VOLTAGE SEQUENCE VDD ON VDD OFF VDD ON 10.8V 10.8V 10.8V Note1 9.6V VDD dip < 20ms Toff > 50ms 5ms < Tr < 80ms LVDS Signals *1,*2 Note2 VALID period Note3 t 20ms CS, SCLK, SDAT... -
Page 13: Connections And Functions For Interface Pins
NL204153BM21-01/01A 4.5 CONNECTIONS AND FUNCTIONS FOR INTERFACE PINS 4.5.1 LCD panel signal processing board CN1 socket (LCD module side): FI-WE41P-HFE (Japan Aviation Electronics Industry Limited (JAE)) Adaptable plug: FI-W41S (Japan Aviation Electronics Industry Limited (JAE)) Pin No. Symbol Signal Remarks... - Page 14 NL204153BM21-01/01A CN2 socket (LCD module side): FI-WE31P-HFE (Japan Aviation Electronics Industry Limited (JAE)) Adaptable plug: FI-W31S (Japan Aviation Electronics Industry Limited (JAE)) Pin No. Symbol Signal Remarks Signal ground Note1 DD3+ Pixel data D3 LVDS differential data input Note2 DD3-...
-
Page 15: Backlight Lamp
NL204153BM21-01/01A 4.5.2 Backlight lamp Attention: VBLH and VBLC must be connected correctly. Wrong connections will cause electric shock and also break down of the product. (1) NL204153BM21-01 CN201 plug (LCD module side): BHSR-02VS-1 (J.S.T. Mfg Co., Ltd.) Adaptable socket: SM02B-BHSS-1-TB(LF)(SN), SM02B-BHSS-1-TB (J.S.T. - Page 16 NL204153BM21-01/01A (2) NL204153BM21-01A CN201 plug (LCD module side): BHSR-02VS-1 (J.S.T. Mfg Co., Ltd.) Adaptable socket: SM02B-BHSS-1-TB(LF)(SN), SM02B-BHSS-1-TB (J.S.T. Mfg Co., Ltd.) Pin No. Symbol Function Remarks VBLH1 Upper side lamp, High voltage (Hot) Cable color: Red VBLC1 Upper side lamp, Low voltage (Cold) Cable color: Gray CN202 plug (LCD module side): BHSR-02VS-1 (J.S.T.
-
Page 17: Positions Of Plug And Socket
NL204153BM21-01/01A 4.5.3 Positions of plug and socket CN201 CN202 CN203 Insert direction CN204 CN205 CN206 DATA SHEET DOD-PD-1318 (4th edition) -
Page 18: Method Of Connection For Lvds Transmitter
NL204153BM21-01/01A 4.6 METHOD OF CONNECTION FOR LVDS TRANSMITTER LVDS data input map is selectable by BSEL0 and BSEL1 terminal. Bit mapping Transmitter Pin Assignment BSEL[1 0] Note1 Dual type LVDS TX Single type Output [H:H], [H L] [L H] THine... - Page 19 NL204153BM21-01/01A BSEL[1 0] Note1 Dual type LVDS TX Single type Output [H:H], THine [H L] [L H] LVDS Tx Connector [L:L] Pin No Signal name THC63LVD823 DS90C387 Mode A Mode B Mode C Note2 CTA- DC0- CTA+ DC0+ Pixel data...
-
Page 20: Display Gray Scale And Input Data Signals
NL204153BM21-01/01A 4.7 DISPLAY GRAY SCALE AND INPUT DATA SIGNALS This product can display 256 gray scales in each LCR sub-pixel and 766 gray scales per 1 pixel. Also the relation between display gray scale and input data signals is as the following table. -
Page 21: Input Signal Timings
NL204153BM21-01/01A 4.8 INPUT SIGNAL TIMINGS 4.8.1 Timing characteristics Parameter Symbol min. typ. max. Unit Remarks Frequency 1/ tc 60.0 65.0 66.0 15.38ns (typ.) Duty See the data sheet of LVDS transmitter. Rise time, Fall time 10.34 10.34 10.77 96.72kHz (typ.) -
Page 22: Lvds Data Taransmission Method
NL204153BM21-01/01A 4.9 LVDS DATA TARANSMISSION METHOD LA(7:0) D0 (7:0) D2 (7:0) D4 (7:0) CA(7:0) Pixel Data A RA(7:0) LB(7:0) D1 (7:0) D3 (7:0) D5 (7:0) CB(7:0) Pixel Data B RB(7:0) LC(7:0) D1024 (7:0) D1026 (7:0) D1028 (7:0) CC(7:0) Pixel Data C... -
Page 23: Pixel Arrangnment
NL204153BM21-01/01A 4.11 PIXEL ARRANGNMENT 2,047 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 1,535 DATA SHEET DOD-PD-1318 (4th edition) -
Page 24: Ten-Bit Look Up Table For Gamma Adjustment
NL204153BM21-01/01A 4.12 TEN-bit LOOK UP TABLE FOR GAMMA ADJUSTMENT Adjustment of gamma characteristics for each 8-bit LCR data is possible by using built-in 10-bit LUT (look up table) for Gamma characteristics. The LUT is set with the serial data. The combination of the control command determines Random/Sequential Address WRITE and Individual/Simultaneous LCR setting. - Page 25 NL204153BM21-01/01A Table2: Command table (CMD5 to CMD0: 6-bit) DATA name Parameter Remarks CMD5 Must be set to "1". CMD4 Must be set to "1". Selection of Random/Sequential Address WRITE CMD3 "1": Random Address WRITE "0": Sequential Address WRITE CMD2 Must be set to "1".
- Page 26 NL204153BM21-01/01A Table5: Data table (DATA15 to DATA0: 16bit) DATA DATA name Parameter Remarks DATA15 Dummy DATA14 Dummy Dummy Data DATA13 Dummy Must be set to "0". DATA12 Dummy DATA11 Dummy DATA10 Dummy DATA9 DATA9 DATA8 DATA8 DATA7 DATA7 DATA6 DATA6...
-
Page 27: Lut Serial Communication Timings
NL204153BM21-01/01A 4.13 LUT SERIAL COMMUNICATION TIMINGS (1) Timing chart SCLK SDAT Invalid Invalid CMD[5:0] ADD[9:0] DATA[15:0] Random Address WRITE timing chart Invalid Invalid SDAT Invalid DATA DATA Sequential Address WRITE timing chart SDAT Invalid Invalid DATA DATA DATA DATA SHEET DOD-PD-1318 (4th edition) - Page 28 NL204153BM21-01/01A (2) Timing specifications Parameter Symbol min. typ. max. Unit Remarks SCLK Frequency 1/Tsck SCLK Pulse Twsck SDAT-SCLK Setup Time SDAT-SCLK Hold Time CS-SCLK Setup Time CS-SCLK Hold Time Tsck Twsck Twsck 1.9V(V+) SCLK 1.25V 0.4V(V-) 1.9V(V+) SDAT 0.4V(V-) 1.9V(V+) 0.4V(V-)
-
Page 29: Optics
NL204153BM21-01/01A 4.14 OPTICS 4.14.1 Optical characteristics (1)NL204153BM21-01 (Note1, Note2) Measuring Parameter Condition Symbol min. typ. max. Unit Remarks instrument White at center BM-5A Luminance cd/m or SR-3 R = 0 , L = 0 , U = 0 , D = 0... - Page 30 NL204153BM21-01/01A Note1: These are initial characteristics. Note2: Measurement conditions are as follows. Ta = 25 C, VDD = 12.0V, IBL = 6.0mArms/lamp, Display mode: QXGA, Horizontal cycle = 1/96.72kHz, Vertical cycle = 1/60.0Hz Optical characteristics are measured after 20 minutes from working the product, in the dark room.
-
Page 31: Definition Of Contrast Ratio
NL204153BM21-01/01A 4.14.2 Definition of contrast ratio The contrast ratio is calculated by using the following formula. Luminance of white screen Contrast ratio (CR) = Luminance of black screen 4.14.3 Definition of luminance uniformity The luminance uniformity is calculated by using following formula. -
Page 32: Reliability Tests
NL204153BM21-01/01A 5. RELIABILITY TESTS Test item Condition Judgment Note1 High temperature and humidity 2 C, RH = 60%, 240hours (Operation) Display data is white. 3 C 1hour Heat cycle 3 C 1hour No display malfunctions (Operation) 50cycles, 4hours/cycle Display data is white. -
Page 33: Precautions
NL204153BM21-01/01A 6. PRECAUTIONS 6.1 MEANING OF CAUTION SIGNS The following caution signs have very important meaning. Be sure to read "6.2 CAUTIONS" and "6.3 ATTENTIONS", after understanding these contents! This sign has the meaning that customer will be injured by himself or the product will sustain a damage, if customer has wrong operations. -
Page 34: Environment
Pack the product with original shipping package, in order to avoid any damages during transportation, when returning the product to NEC for repair and so on. The LCD module by itself or integrated into end product should be packed and transported with display in the vertical position. -
Page 35: Outline Drawings
NL204153BM21-01/01A 7. OUTLINE DRAWINGS 7.1 FRONT VIEW Note1: Not shown tolerances of the dimensions are 0.3mm. Unit: mm Note2: The torque for product mounting screws must never exceed 0.735N m. Note3: The length of product mounting screws from surface of plate must be 5.3mm. -
Page 36: Rear View
NL204153BM21-01/01A 7.2 REAR VIEW Unit: mm Note1: Not shown tolerances of the dimensions are 0.3mm. Note2: The torque for product mounting screws must never exceed 0.735N m. Note3: The values in parentheses are for reference. DATA SHEET DOD-PD-1318 (4th edition)
