D-1000
GENERAL INFORMATION
EXPLODED VIEWS - PARTS LISTS
Webedition 08/2001
ENGLISH
Attention! 3 minutes delay on all units with 'Alfa-14'
controller. When starting or restarting the unit, it will take
3 minutes before the compressor and the fan will start
running.
Achtung! Wenn Sie das Gerät (wieder) in Betrieb setzen,
wird bei allen Geräten, die mit einem Zeitschaltuhr 'Alfa-14'
ausgestattet sind, der Anlauf des Kompressors und der des
Ventilators um 3 Minuten verzögert.
Attention! Quand vous mettez ou remettez votre appareil
en fonctionnement, le compresseur et le ventilateur de tous les
appareils equipés d'une horloge électronique 'Alfa-14'
commencent à fonctionner après 3 minutes.
Attentie! Wanneer u het apparaat wilt (her)starten en het
apparaat is uitgevoerd met een 'Alfa-14' tijdschakelaar, dan
duurt het 3 minuten voordat compressor en ventilator starten.
Advertisement
Related Manuals for Amcor D-1000
Summary of Contents for Amcor D-1000
- Page 1 D-1000 GENERAL INFORMATION EXPLODED VIEWS - PARTS LISTS Webedition 08/2001 ENGLISH Attention! 3 minutes delay on all units with ‘Alfa-14’ controller. When starting or restarting the unit, it will take 3 minutes before the compressor and the fan will start running.
- Page 2 - by heat pumps. You simply set the dial and the air humidity remains at The Amcor dehumidifier is designed as a heat pump and the required level. has, through energy saving, a considerable advantage And, the Amcor dehumidifier is an energy saver.
-
Page 3: Electrical Wiring
HOW THE “AMCOR” DEHUMIDIFIER WORKS The fan (1) sucks the humid air through the evaporator (2). There the air is cooled and the moisture in the air condenses into water. This water is collected in the tray (3) and drained away through the sump and piping. - Page 4 AMCOR MODEL D-1000 The Amcor D-1000 is a large capacity unit designed to run highly efficiently in a domestic, commercial or industrial environment. The D-1000 keeps air dry and comfortable, prevents condensation, and creates a better climate to prevent damages caused by exessive humidity, such as: rusting of equipment, dry rot of walls, mould growth in store romms, etc.
- Page 5 PROCEDURE ON START UP D-1000 PROCEDURE ON START UP When the installation has been completed, carry out the following procedure: 1. Make sure that the air filter has been fitted and that unfiltered air cannot be drawn in. 2. Check the condensate drain system for leaks.
- Page 6 EXPLODED VIEW / D-1000 32/56...
- Page 7 EXPLODED VIEW / D-1000 MOISTURE REMOVAL / D-1000 “AMCOR” D1000 - MOISTURE REMOVAL AT DIFFERENT ROOM TEMP. EN R.H.% (kg water/24h) RELATIVE HUMIDITY % ROOM TEMP. °C...
- Page 8 PARTSLIST / D-1000 DRAWING NO. PART NO. QTY. PART NAME A2-1827-011 A414274 TOP COVER-RIGHT A3-1827-015 O77001 PANEL-RIGHT A1-1827-014 A382904 FRONT PANEL A1-1827-046 A338666 LOUVERS A3-1827-032 A442545 HOLDER-LOUVERS R A2-1827-064 A433345 WALL-RIGHT A3-1827-006 A431004 DRIAN PAN 7+21 429152/3 DIFFUSER 271264 SCROLL-BLOWER...
- Page 9 WIRING DIAGRAM / D-1000 BLACK MOTOR COMP. BLACK CAPACITOR WHITE BROWN CAPACITOR BLUE GREEN/YELLOW GREEN/YELLOW BLUE BLUE BLUE BROWN BROWN BLACK DEFROST TIMER ALFA - 14/1 SNS1 SNS2 TO CONDENSATOR TO EVAPORATOR TO HYGROSTAT DEHUMIDIFIER D-1000 274838...
- Page 10 1422 AL UITHOORN - Holland Tel. +31 (0)297 56 00 79 Fax +31 (0)297 52 30 62 Internet: www.amcorex.com e-mail: info@amcorex.com Amcor (Appliances) Ltd. 9 Ryan Drive, West Cross Centre Great West Road, Brentford Middlesex TW8 9ER United Kingdom Tel. +44 (0)20 8560 4141 Fax +44 (0)20 8232 8814 e-mail: amcor@amcorintl.co.uk...
