R-90GCH
8
7
1. Control panel
2. Waveguide cover (DO NOT REMOVE)
3. Oven lamp
4. Oven cavity
5. Coupling
6. Door latches
7. Door opening handle
(To open the door, pull the handle down and forward.
Never hold the door handle when moving the oven.)
8. Door seals and sealing surfaces
9. Ventilation cover (DO NOT REMOVE)
10. Outer cabinet
1
2
3
4
Operatiing keys:
1 MICRO COOK key
By pressing this key you can select the
MICRO COOK menu.
2 LESS/MORE keys
3 WEIGHT keys
4 MICRO DEFROST key
By pressing this key you can select
theMICRO DEFROST menu.
5 BASIC COOK key
6 RECIPES key
7 COMBI MENU keys
For selecting the menu of BASIC
COOK andRECIPES.
NOTE:
Some one-touch cooking features such as "
oven is not in use. These features are automatically enabled when the door is opened and closed or the
STOP key is pressed.
APPEARANCE VIEW
5
6
CONTROL PANEL
COMBI
18
19
20
5
6
7
8 TIME keys
9 LANGUAGE key
10 STOP key
11 DUAL MODE keys
There are two Dual modes:
Dual 1: Microwave and Grill with high
speed air circulation.
Dual 2: Microwave and Convection with
high speed air circulation.
12 GRILL key
13 CONVECTION key
By pressing this key you can adjust
the convection temperature.
OVEN
1
2
3
12
4
13
15
14
5
11. Power cord
12. Air-vent openings
13. Turntable
14. Turntable support
15. Low rack
16. High rack
17. Splash guard
21
22
23
11
(START)+1min" are disabled after three minutes when the
6
9
10
11
17
16
8
9
12
13
14
15
16
14 MICROWAVE POWER LEVEL key
By pressing this key you can adjust
the Microwave power level.
15 INFO key
16 TIMER/CLOCK SETTING key
17
(START)+1min key
Digital display and indicators:
18 HIGH SPEED indicator
19 GRILL indicator
20 CONVECTION indicator
21 MICROWAVE indicator
22 COOKING IN PROGRESS indicator
23 MORE/LESS indicator
10
17
