OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions carefully. This will
simplify installation and ensure that the product is installed correctly and
safely. Leave these instructions near the product after installation for future
reference.
EN
ENGLISH
RC8*U2*V*W
RC9*U2*V*W
MFL69702088
Rev.02_053118
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG RC8 U2 V W Series
Summary of Contents for LG RC8 U2 V W Series
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH RC8*U2*V*W RC9*U2*V*W www.lg.com MFL69702088 Rev.02_053118 Copyright © 2018 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Control Panel .................... 19 Programme Table ..................20 Option Programme ................... 22 Rack Dry ....................24 SMART FUNCTIONS .............25 Using LG SmartThinQ Application ............25 Using Smart Diagnosis™ ................. 29 MAINTENANCE ..............30 Cleaning the Lint Filter ................30 Emptying the Water Container..............31 Cleaning the Cool Air Inlet Grill .............. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 For use in Europe: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 •This appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance, in such a way that a full opening of the appliance door is restricted. •This appliance must be grounded.
- Page 6 Improper use can cause fire or explosion. •In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. •Do not push down the door excessively, when the appliance door is open.
- Page 7 Maintenance •Securely plug the power plug in the socket outlet after completely removing any moisture and dust. •Disconnect the appliance from the power supply before cleaning the appliance. Setting the controls to the OFF or stand by position does not disconnect this appliance from the power supply. •Do not spray water inside or outside the appliance to clean it.
- Page 8 •The lint trap has to be cleaned frequently. •Lint must not to be allowed to accumulate around the appliance. •Do not spray dry cleaning detergent directly onto the appliance or use the appliance to dry clothes left with dry cleaning detergent. •Do not dry clothes stained with oil substances.
-
Page 9: Disposal Of Your Old Appliance
WEEE collection point. For the most up to date information for your country please see www.lg.com/global/recycling. •This dryer contains fluorinated greenhouse gases. R134a (GWP: 1430): 0.500 kg / 0.715 t CO2-eq. Hermetically... -
Page 10: Installation
8 kg 9 kg • Appearance and specifications may vary without notice to improve the quality of the appliance. Accessories Please contact the LG Electronics Customer Information Centre for purchase. Condensing Drain Hose Dry Rack Stacking Kit and Hose Holder... -
Page 11: Installation Place Requirements
Installation Place Positioning Requirements • Install the appliance on a flat hard floor. • Make sure that air circulation around the Location appliance is not impeded by carpets, rugs, etc. • Never try to correct any unevenness in the floor with pieces of wood, cardboard or similar materials under the appliance. -
Page 12: Stacking Installation Instructions
• Do not use an extension cord or double Stacking Kit adapter. • Always unplug the appliance after use. In order to stack this dryer an LG stacking kit is required. • Connect the appliance to an earthed socket in accordance with current wiring regulations. - Page 13 Installation Procedure WARNING • Incorrect installation can cause serious Place the LG dryer on the LG washing accidents. machine. • The weight of the appliance and the height of installation make the stacking procedure too risky for one person. This procedure should...
- Page 14 Condensed Water Drain-out Leveling the appliance Normally, condensed water is pumped up to the Leveling the appliance prevents unnecessary water container where water is collected until noise and vibration. Place the appliance on a manually emptied. Water can also be drained solid, level floor.
-
Page 15: Reversing The Door
Reversing the door Remove 8 screws on the hinge assembly from the door. You can reverse the door for your convenience. • There are 6 screws on the front and 2 screws on the side. WARNING • Do not reverse the door while the appliance is stacked on a washing machine. - Page 16 Remove the door catch from the appliance Install the door with the screws removed in frame by removing 2 screws and then step 1 and then check the door closes assemble them on the opposite side. properly. Door catch Remove the 2 decorative screws from the appliance frame and then assemble them on opposite side.
-
Page 17: Operation
OPERATION Using the Appliance CAUTION • Be careful not to trap laundry between the Before the first cycle, set the appliance to dry door and rubber seal. for five minutes to warm up the drum. Open the door between loads the first few times you use Turn the power on. -
Page 18: Sorting Laundry
Rubber and Plastics CAUTION • Do not dry any items made from or containing • Be careful! The drum inside may still be hot. rubber or plastics such as: • The appliance must not be used for purposes − Aprons, Bibs and Chair Covers other than those for which it was designed. -
Page 19: Control Panel
Control Panel Display Power Button : This icon indicates that the lint filter • • Press the Power button to turn power on should be cleaned or is clogged. and off. − Cleaning notice: When you press the Power • Press the Power button to cancel the button, the icon will become displayed. -
Page 20: Programme Table
Programme Table Drying Programme Sensor Dry Programmes Programme Laundry Type Detail Drying Capacity Level 8 kg / 9 kg Towels, dressing gowns For thick and quilted Extra 8 kg / 9 kg and bed linen fabrics Bath towels, tea towels, For fabrics that do not underwear and cotton Cupboard... - Page 21 Sensor Dry Programmes Programme Laundry Type Detail Drying Capacity Level 8 kg / 9 kg Soccer kit and training Sports Wear For polyester material 2 kg wear Wool Wool For wool fabrics 1 kg For fabrics that are Silk, fine fabrics and Delicate heat-sensitive, such as 1.5 kg...
-
Page 22: Option Programme
Option Programme Favorite Delay End The Favorite option allows you to store a customized dry programme for future use. You can use the Delay End option to delay the Turn the appliance on. finishing time of the drying cycle. Maximum Delay End is 19 hours. - Page 23 Child Lock Use this option to disable the controls. This feature can prevent children from changing cycles or operating the appliance. Locking the Control Panel Press and hold the Favorite and Delay End button simultenesouly for three seconds. A beeper will sound, and CL will appear on the display.
-
Page 24: Rack Dry
Rack Dry Close the door. The dryer rack is placed inside the appliance, as in the picture below. Remove and discard Turn power on and select Rack Dry. packing material before use. The Rack Dry is designed for use with laundry Press the Start/Pause button. -
Page 25: Smart Functions
• For appliances with the logo manual. Check the distance between the appliance • LG SmartThinQ is not responsible for any and the wireless router (Wi-Fi network). network connection problems or any faults, • If the distance between the appliance and... - Page 26 Installing LG SmartThinQ Smart Diagnosis™ This function provides useful information for Search for the LG SmartThinQ application from diagnosing and solving issues with the the Google Play Store or Apple App Store on a appliance based on the pattern of use.
- Page 27 20 cm between the device and the • Once the Remote Start mode is enabled, you body. can start a cycle from the LG SmartThinQ smartphone application. If the cycle is not started, the machine will wait to start the cycle Standby power consumption 0.42 W...
- Page 28 Smart Diagnosis™ Using a Smart Phone • For appliances with the logo Hereby, LG Electronics declares that the radio Use this function if you need an accurate equipment type Dryer is in compliance with diagnosis by an LG Electronics customer Directive 2014/53/EU.
-
Page 29: Using Smart Diagnosis
Use this function if you need an accurate • If the call centre agent is not able to get diagnosis by an LG Electronics customer an accurate recording of the data, you information center when the appliance may be asked to try again. -
Page 30: Maintenance
MAINTENANCE WARNING • Open the second lint filter. • Remove the power plug when you clean the appliance. Not removing the plug may result in electric shock. Cleaning the Lint Filter Clean the lint filter before each drying cycle. It should also be cleaned if the icon becomes illuminated and the buzzer sounds while the... -
Page 31: Emptying The Water Container
Emptying the Water Container Cleaning the Cool Air Inlet Grill Condensed water is collected in the water container. Vacuum the Cool Air Inlet grill 3 – 4 times a Empty the water container after every use. Not year to make sure there is no build up of lint or doing so will affect the drying performance. -
Page 32: Troubleshooting
TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason... - Page 33 Symptoms Reason Solution • Reset circuit breaker or replace fuse. House fuse is blown, circuit breaker Do not increase fuse capacity. If the has tripped, or power outage has problem is a circuit overload, have it occurred. corrected by a qualified electrician. •...
- Page 34 Symptoms Reason Solution • Over drying a load of laundry can Clothes have dried too long lead to wrinkled clothes. Try a (overdried). shorter drying time. Clothes are wrinkled. Clothes have been left in the appliance for too long after cycle •...
- Page 35 • Check if laundry or foreign substance is caught laundry or foreign in the door before using the appliance. If water substance is caught in the leaks continuously, contact the LG Electronics door. Customer Information Centre. • If items are too tightly packed or too sparse the sensor may have trouble reading the dryness level of the load.
-
Page 36: Error Codes
Error Codes Symptoms Reason Solution The door has been opened while the appliance is in operation or the • Close the door completely. appliance is being operated without • If dE is not released, call for service. the door being closed properly. Door switch detection is not •... -
Page 37: Warranty
• Costs associated with removal of your Product from your home for repairs. • The removal and reinstallation of the Product if it is installed in an inaccessible location or is not installed in accordance with published installation instructions, including LG’s owner’s and installation manuals. -
Page 38: Operating Data
