Cable your router
Power on your router and connect it to a modem.
Figure 6. Cable your router
To cable your router:
1. Unplug your modem, remove and reinsert the backup battery if it uses one, and
then plug the modem back in.
2. Use the Ethernet cable to connect the modem to the yellow Internet port on the
router.
Note: If your Internet connection does not require a modem, connect your main
Ethernet cable to the yellow Internet port on the router.
3. Connect the power adapter to your router and plug the power adapter into an outlet.
4. Press the Power On/Off button on the rear panel of the router.
The router's Power LED lights solid white when the router is ready.
Hardware Setup
Nighthawk AX5 AX2200 5-Stream WiFi Router
16
User Manual
