Panasonic KX-TG1100 Operating Instructions Manual

Hide thumbs Also See for KX-TG1100:

Advertisement

Quick Links

Charge the batteries for about
7 hours before initial use.
You must subscribe to Caller ID service to use this
feature.
Caller ID
Please read these operating instructions before using the unit and save them for future
reference.
KX-TG1100

Table of Contents

Introduction ............................................................ 2
Preparation ............................................................. 4
Making/Answering Calls ...................................... 10
Phonebook............................................................ 11
Useful Telephone Settings .................................. 12
Caller ID Service ................................................... 15
Multi-unit Operation ............................................. 16
Useful Information................................................ 17
Operating Instructions
Digital Cordless Phone
KX-TG1100
Model No.
KX-TG1102
KX-TG1103

Advertisement

loading

Related Manuals for Panasonic KX-TG1100

Summary of Contents for Panasonic KX-TG1100

  • Page 1: Table Of Contents

    Operating Instructions Digital Cordless Phone KX-TG1100 Model No. KX-TG1102 KX-TG1100 Charge the batteries for about KX-TG1103 7 hours before initial use. Table of Contents Introduction ............2 Preparation ............. 4 Making/Answering Calls ........10 Phonebook............11 Useful Telephone Settings ........12 Caller ID Service ...........

  • Page 2: Introduction

    L In the event of problems, you should contact your equipment supplier in the first instance. Declaration of Conformity: L Panasonic Communications Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC.
  • Page 3 Introduction Included accessories Quantity No. Accessory items KX-TG1100 KX-TG1102 KX-TG1103 AC adaptor for base unit Part No. PQLV19EY (PQLV19E) Telephone line cord Part No. PQJA87S or PQJA10180Z (for UK) Rechargeable batteries AAA (R03) size Part No. HHR-55AAAB or HHR-4EPT (Order No. P03P) Handset cover Part No.

  • Page 4: Preparation

    Preparation Warning: Preparation Important information L To prevent the risk of electrical shock, do not expose this product to rain or any other type of moisture. General L Unplug this unit from power outlets if it L Use only the AC adaptor included with this emits smoke, an abnormal smell or makes product, noted on page 3.
  • Page 5 Preparation Union. Information on Disposal for Users of If you wish to discard this product, please Waste Electrical & Electronic Equipment contact your local authorities or dealer and (private households) ask for the correct method of disposal. This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste.
  • Page 6 Preparation Panasonic sales shop can offer you more Connections information about connection possibilities. L To turn the power on, press {ih} for about 1 second. Base unit L To turn the power off, press {ih} for Hooks about 2 seconds.
  • Page 7 7 hours before initial use. Battery strength Battery icon Battery strength Fully charged. High Medium Needs to be charged. Panasonic Ni-MH battery performance Operation Operating time A Receiver In continuous use 10 hours max. B Display C {k} (Phonebook) In continuous standby 120 hours max.
  • Page 8 Preparation Icons Meaning Charger (KX-TG1102 and KX-TG1103 only) If “HS NO” is selected for standby mode display (page 12) and the current handset number is 2, “[2]” is displayed. A Charge contacts 4 new calls When new calls have been received, the display will show the number of new calls.
  • Page 9 Preparation Display language {j/OK} Press {e} or {v} to select “SETTING HS”. i {>} Press {e} or {v} to select “DISPLAY OPT”. i {>} Press {e} or {v} to select “LANGUAGE”. i {>} Press {e} or {v} to select the desired language.

  • Page 10: Making/Answering Calls

    Making/Answering Calls Making/Answering Calls Making calls Storing: {>} i “SAVE TEL NO” i {>} i {j/OK} i Enter the name (9 Dial the phone number. i {C} characters max.; page 11). i When finished talking, press {ih} or {j/OK} place the handset on the base unit or Editing before calling: charger.

  • Page 11: Phonebook

    Phonebook Phonebook Making calls/Editing/Erasing Adding entries to the {k} i Press {e} or {v} to display phonebook the desired entry. The phonebook allows you to make calls Making calls: without having to dial manually. You can add 50 names and phone numbers to the Editing: phonebook.

  • Page 12: Useful Telephone Settings

    Useful Telephone Settings Useful Telephone Settings Guide to handset settings To customise the handset: {j/OK} Press {e} or {v} to select “SETTING HS”. i {>} Press {e} or {v} to select the desired item in the handset settings menu. i {>} Press {e} or {v} to select the desired item in the sub-menu.
  • Page 13 Useful Telephone Settings Handset settings Sub-menu Feature (default setting) menu Change handset PIN (“0000”). OTHER OPT HSPIN CHANGE − Enter the current 4-digit handset PIN. − Enter the new 4-digit handset PIN. − Enter the new 4-digit handset PIN again. Auto talk on/off (“OFF”) AUTO TALK —————...
  • Page 14 Useful Telephone Settings Code No. Feature (Default setting) Call restriction Setting call restriction − Enter base unit PIN (default: “0000”). i Press the desired handset numbers. i {>} − Enter the phone number to be restricted (8 digits max.). L To select a different memory location, press {>} and enter a number.

  • Page 15: Caller Id Service

    Caller ID Service the second call by pressing {R}. The first Caller ID Service Using Caller ID service caller will be placed on hold. Press {R} again to switch back to the first caller. Consult your service provider/telephone Important: company for details of this service. L This unit is Caller ID compatible.

  • Page 16: Multi-Unit Operation

    Multi-unit Operation Multi-unit Operation Intercom between Transferring calls handsets (KX-TG1102 and between handsets, KX-TG1103 only) conference calls (KX- TG1102 and KX-TG1103 Intercom calls can be made between only) handsets in the same radio cell. Example: When handset 1 calls handset 2 Outside calls can be transferred between 2 Handset 1: people in the same radio cell.

  • Page 17: Useful Information

    Useful Information Useful Information Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the AC adaptor and turn off the handset, then reconnect the AC adaptor and turn on the handset. Problem Cause & solution w is flashing.
  • Page 18 Useful Information Problem Cause & solution I cannot make or receive calls. L The AC adaptor or telephone line cord is not connected. Check the connections. L The call bar feature is turned on. Turn it off (page 12). L You dialled a call restricted number (page 14). L The key lock feature is turned on.
  • Page 19 Useful Information Problem Cause & solution I cannot remember the PIN. L Change the PIN using the following method. Handset PIN: {j/OK} “SETTING HS” i {>} “OTHER OPT” i {>} “HSPIN CHANGE” i {>} Press {*}{7}{0}{0}{0}. Enter the new 4-digit handset PIN. Enter the new 4-digit handset PIN again.
  • Page 20 Useful Information actual product. Specifications Wall mounting Standard: DECT (Digital Enhanced Cordless Telecommunications) Base unit Number of channels: 120 Duplex Channels 80 mm Frequency range: 1.88 GHz to 1.9 GHz Duplex procedure: TDMA (Time Division Multiple Access) Screws Channel spacing: 1,728 kHz Hooks Hook Bit rate: 1,152 kbit/s...
  • Page 21 8. The guarantee period applicable to this product shall be 12 months. Please keep these operating instructions with your receipt. Panasonic Business Systems U.K. Receipt No. Date of purchase Model No.
  • Page 24 L Or go on line through our Internet Accessory ordering application at www.panasonic.co.uk L Most major credit and debit cards accepted. L All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd. L It couldn ’ t be simpler! L Also available through our Internet is direct shopping for a wide range of finished products, take a browse on our website for further details.
