PRODUCT SPECIFICATIONS
Maximum seating capacity:
Water capacity:
Inner/outer diameter:
Height:
Jet pump:
Filter pump fl ow rate:
Heater power:
Temperature range:
Temperature rise:
Number of Water Jet Nozzles:
Spa tub recommended working air pressure:
Cord-connected spa with pump, heater, water jet, built-in hard water treatment and control panel.
This product requires a minimum of 13 Amps. If the circuit breaker trips, please check that no other
appliances or other large loads are on the same circuit as the spa.
Site preparation and requirements
•
The spa can be installed indoor or outdoor. For household use only.
•
Make sure the area is free of sharp objects under or around the spa.
•
Provide a properly located power outlet to connect the spa and allow easy access for periodic testing of the cord
mounted RCD.
•
Make sure there is enough clearance around the spa for full access to the spa equipment for maintenance and/or
service.
•
The area shall facilitate draining purposes during long term spa storage.
Additional requirements for indoor installation
•
Make sure the fl oor can support the full weight of the fi lled spa with the maximum number of occupants. Check with a
qualifi ed contractor or a structural engineer to verify this requirement.
•
Make sure the fl oor is water resistant and non-slip surface. Do not install the spa on carpet or other materials that will be
damaged by moisture, condensation.
•
Do not install the spa indoors on a second fl oor above fi nished living space due to the possibility of water and humidity
damage.
•
Humidity is a natural side effect of indoor spa installation. The room shall be properly ventilated to allow moisture to
escape. Install a ventilating system to prevent excess condensation, moisture in the room.
Additional requirements for outdoor installation
•
Spa owners may need to comply with local or states laws relating to childproof fencing, safety barriers, lighting, and
other safety requirements. Contact your local building code enforcement offi ce for further details.
•
Make sure the surface is level, fl at, smooth and strong enough to support the full weight of the fi lled spa.
•
Do not setup the spa on grass or dirt, as this increases the amount of debris entering the spa, and damage the spa fl oor.
•
Do not expose the spa to direct sunlight for extended period of time.
•
It is possible to install and leave the spa outside at a temperature not lower than 4°C (39°F) provided the water
temperature inside the spa is higher than 4°C (39°F) and the water inside the circulation system, pump, pipe are not
frozen. Put a "temp barrier mat" between the spa fl oor and the ground to prevent heat loss from the bottom of the spa
and to provide better heat retention.
S AVE THESE INSTRUCTIONS
(297IO) SPA (JET + HARD WATER) ENGLISH 7.5" X 10.3" PANTONE 295U 07/26/2016
4 adults
210 gal (795 L)
57/77 in (145/196 cm)
28 in (71 cm)
0.9 HP / 220-240 V / 50 Hz
460 gal/hr (1,741 L/hr)
2,200 Watts / 220-240 V / 50 Hz
20ºC – 40ºC (68ºF – 104ºF)
1.5-2.5ºC/hr (3ºF – 4.5ºF/hr)
4
0.083 bar (1.2 psi)
SET UP
297
English
A
