- Page 1 CONTROL SURFACE CS-R10 CS-R10-S System Setup Guide...
- Page 2 The above warning is located on the rear of the unit. L’avertissement ci-dessus est situé sur l’arrière de l’unité. Explanation of Graphical Symbols Explication des symboles The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “danger- ous voltage”...
- Page 3 Yamaha Corporation of America or its subsidiaries. of other electronic devices. Compliance with FCC regulations does * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B) ADVARSEL!
- Page 4 Yamaha service personnel. • When setting up the device, make sure that the AC outlet you are using is easily accessible.
- Page 5 The average life of the internal backup cause an explosion and/or damage to the device(s). If the battery is approximately 5 years, depending on operating backup battery power is fully depleted, have qualified Yamaha conditions. service personnel replace the battery.
- Page 6 PA_en_4 3/3 Information Information for users on collection and disposal of old equipment: About copyrights This symbol on the products, packaging, and/or accompanying documents means that used elec- Copying of the commercially available musical data including trical and electronic products should not be but not limited to MIDI data and/or audio data is strictly mixed with general household waste.
-
Page 7: Table Of Contents
Connecting the devices ....35 Conventions in this manual....9 Turning on the power to the RIVAGE PM10 system ...... 36 Accessories (CS-R10, CS-R10-S)..9 Setting the word clock ....36 System Overview....10 Assigning channels to the TWINLANe network ......37 Introducing the devices.... -
Page 8: Introduction
RIVAGE PM10 system, and to enjoy years of trouble-free This guide also serves as a user guide for the CS-R10 use, please read this manual carefully before operating and CS-R10-S. It explains part names and panel your console. -
Page 9: About Utility Software
This Windows application software enables you to • Gooseneck Lamps LA1L access the same functions that are available on the (×4 for CS-R10 , ×3 for CS-R10-S) control surface. You can use your computer to perform • System Setup Guide (this book) -
Page 10: System Overview
System Overview Introducing the devices The RIVAGE PM10 system consists of the following components: Control surfaces DSP engine I/O racks CS-R10 DSP-R10 RPio622 CS-R10-S RPio222 The control surfaces enable you to perform general The DSP engine handles mixing and plug- The I/O racks transfer analog and operations on the RIVAGE PM10 system. - Page 11 • For detailed information on I/O card settings, refer to the owner’s manual for the I/O card. For the latest information on which I/O cards can be used with the system, visit the Yamaha Pro Audio website at: http://www.yamahaproaudio.com/ RIVAGE PM10 System Setup Guide...
- Page 12 NOTE Yamaha recommends that you use opticalCON DUO fiber cable made by Neutrik. In general, fiber optic cables are susceptible to bending or pulling. Use a fiber optic cable that features a strong...
-
Page 13: About Network Card
Ring connection Device Device Device Device TWINLANe TWINLANe TWINLANe TWINLANe ..Network Card Network Card Network Card Network Card ■ When a cable is broken A TWINLANe network uses a ring topology, which provides redundancy in case of broken cables. If a cable in the network breaks down for some reason, the signal will be automatically re-routed and audio will flow without interruption. -
Page 14: Part Names & Functions
Part Names & Functions Top panel CS-R10 CS-R10-S Touch Screen section ➔ page 22 Channel Strip section ➔ page 23 Selected Channel section ➔ page 15 UTILITY section ➔ page 19 SCENE MEMORY section ➔ page 20 USER DEFINED KEYS/KNOBS section ➔ page 21... - Page 15 Selected Channel section This section enables you to adjust parameters for the selected channel. 1 [ISOLATE] key Switches Isolate on or off. The Isolate function enables you to protect the entire selected channel strip, with just one key press, from any recall operations for scenes or libraries, regardless of the Recall Safe settings.
- Page 16 7 [PAN/BAL] knob @ [PASTE] key Sets the panning/balance of the signal sent to the Pastes the copied channel parameter. stereo buses. # Channel name display 8 [Fn] (Function) key Indicates the channel number and name, fader value, Executes the pre-assigned function. etc.
- Page 17 EQUALIZER 2 EQUALIZER [ON] key Switches EQ on or off. 3 EQUALIZER [SHELF] key Switches peaking filter to shelving filter. 4 EQ display Indicates parameters for each EQ band. 5 EQUALIZER [Q] knob Specifies the Q value. 6 EQUALIZER [FREQUENCY] knob Sets the frequency.
- Page 18 DYNAMICS 1 DYNAMICS 1/2 IN LED Indicates the Dynamics input level. 2 DYNAMICS 1/2 GR LED Indicates the amount of Dynamics gain reduction. 3 DYNAMICS 1/2 [<]/[>] keys Switch parameters that are indicated on the DYNAMICS display. 4 DYNAMICS 1/2 setting knobs Set parameters that are indicated on the DYNAMICS display.
- Page 19 USB flash drive’s write-protect setting is turned off before you save data onto the USB flash drive. For the latest information on which USB flash drives can be used with the system, visit the Yamaha Pro Audio website at: http://www.yamahaproaudio.com/...
- Page 20 SCENE MEMORY section 1 [OVERLAY] key Press this button to display the OVERLAY SETTING screen. While pressing and holding down the [SHIFT] key, press the [OVERLAY] key to switch Overlay on or off. While Overlay is turned on, press and hold down the [OVERLAY] key to enter Overlay edit mode.
- Page 21 USER DEFINED KEYS/KNOBS section 1 USER DEFINED [A]/[B]/[C]/[D] BANK keys Select the bank ([A], [B], [C], or [D]) for the USER DEFINED knobs or USER DEFINED keys. 2 USER DEFINED KNOBS displays Indicate the functions assigned to the USER DEFINED knobs. 3 USER DEFINED KNOBS [1]/[2]/[3]/[4] Control the functions as assigned by the user.
- Page 22 Bay C A “bay” consists of a group of 12 faders located across the Touch Screen section and the Channel Strip section. The CS-R10 contains three bays; the CS-R10-S contains two bays. You can control these bays independently. Bay R...
- Page 23 Channel Strip section (Bay L, Bay R, Bay C) 1 Screen encoder (Bay L and C only) Controls the knob currently selected on the touch screen. The knob function varies depending on the screen currently displayed. 2 Channel strip encoder Adjusts the gain, pan, and the other parameters of the channel.
- Page 24 ) Fader @ SAFE M indicator This is a touch-sensitive 100mm motorized fader. In Lights if the channel is set to Mute Safe. SENDS ON FADER mode, this fader adjusts the send # ISOLATE indicator level of the signal sent from each channel to the Lights if the channel is “Isolated.
-
Page 25: Front Panel
• Current screen • Selected channel/parameter on the screen • Selected layer Front panel CS-R10 1 Brightness control knob Adjusts brightness of the light below the console. 2 Headphone hanger To use the hanger, pull out the knob, and then turn it counter-clockwise. -
Page 26: Rear Panel
This switch is set to LOW when the unit is initially shipped from the factory. As long as the unit is operated within the used to supply power to Yamaha LA1L gooseneck specified ambient temperature range either the LOW or lamps supplied with the unit. - Page 27 This indicator lights up or flashes red if an error inputting analog audio signals from line level devices occurs. or microphones. They feature SILK digital In such an event, please contact your Yamaha dealer. processing. % LINK indicator 1 (Ground)
- Page 28 Before you turn off the power to the control surface, cords. First connect the AC power cords to this unit, Yamaha recommends that you store the current status to and then insert the power cord plugs into AC outlets. scene memory.
-
Page 29: Power Supply
Turn off both power switches A and B on the Pro Audio website to see whether your CS-R10 or unit. CS-R10-S supports that card, and to verify the number of Connect one of the supplied power cords to other Yamaha cards or third-party cards that can be used AC IN connector (A), and the other to AC IN in conjunction with this card. -
Page 30: Removing The Mini-Ygdai Card
Align both edges of the card with the guide Touch Screen rails inside the slot, and then insert the card into the slot. Push the card all the way into the slot so that the Basic touch screen connector at the end of the card is correctly inserted into the connector inside the slot. - Page 31 List windows Popup windows Windows similar to the following enable you to select When you press a button or field for a specific parameter items from a list, such as a list of USER DEFINED keys. in a screen, a window showing details or a list for that parameter will appear.
-
Page 32: Viewing A Touch Screen
Console Network The setup procedure is explained using a system comprised of the following devices: • Control surface (CS-R10) ×1 • DSP engine (DSP-R10) ×1 • I/O rack (RPio622) ×1 • HY card (HY256-TL) ×2 • RY card (RY16-ML-SILK) ×1 •... -
Page 33: Installing An Optional Card
Installing an optional card Push the card all the way into the slot so that the connector at the end of the card is correctly inserted into the connector inside the slot. HY card installation Install a TWINLANe network card into HY card slot 1 on both the DSP engine and I/O rack. - Page 34 RY card installation Align both edges of the card with the guide rails inside the slot, and then insert the card Install an RY16-ML-SILK mic/line input card into RY card into the slot. slot 1 on the I/O rack. Push the card all the way into the slot so that the Install an RY16-DA analog output card into RY card slot 2 connector at the end of the card is correctly inserted on the I/O rack.
-
Page 35: Setting The Unit Id
Connecting the control surface and DSP engine DSP engine: 1 or 2 Use Ethernet cables to connect the TO ENGINE OUT/IN connectors on CS-R10 the control surface to the TO ENGINE OUT IN TO CONSOLE OUT/IN connectors on the DSP engine. -
Page 36: Turning On The Power To The Rivage Pm10 System
Setting the word clock Audio I/O connections The entire system must synchronize to the same word Analog input clock. connections RPio622 Connect a microphone and/ Press the WORD CLOCK button in the SETUP or line level devices to the screen. input jacks on the RY card (RY16-ML-SILK). -
Page 37: Assigning Channels To The Twinlane Network
Assigning channels to the Press the channel select buttons to turn them TWINLANe network For this example, select STA L and STA R. On the DSP engine and I/O rack, you can select channels to be output to the TWINLANe network, and make settings to reserve certain bandwidth on the network. -
Page 38: Patching The Input Ports
Patching the input ports Press the Channel assign popup button. For this example, select RY card slot 1. This section explains how to patch an input channel to the input jack to which a microphone was connected in the “Connecting the devices” section. NOTE The PATCH screen displays the input/output jacks assigned to the TWINLANe network. -
Page 39: Patching The Output Ports
Patching the output ports Press the desired grid cell to patch a desired channel. This section explains how to patch output channels to the For this example, press the grid cell on which the output jacks to which the speaker system has been input jack (M1/RY SLOT1/1) intersects with input connected in the “Connecting the devices”... -
Page 40: Setting The Analog Gain For Ha (Head Amp)
Setting the analog gain for Press the desired grid cell to patch a desired channel. HA (Head Amp) For this example, press the grid cells on which the output jacks (M1/RY SLOT2/1,2) intersect with This section explains how to set the analog gain for the HA output channels (ST A L, R). -
Page 41: Sending An Input Channel Signal To The Stereo Bus
Sending an input channel Raise the input channel fader to obtain an appropriate volume. signal to the STEREO bus This section explains how to route an input channel to the STEREO bus. In the top panel’s Channel Strip section, press the [SEL] key for the input channel that you want to control. -
Page 42: Check List
Check list You can use the following list to check whether the basic connections for the RIVAGE PM10 system are working properly. Both power A and B for each device must be turned on. Make sure that two power cords are connected to each device and that both power switches A and B on each device are turned on. -
Page 43: Other Operations
Adjusting the faders Other Operations (Calibration function) Depending on the environment in which you use the Initializing the unit to system, discrepancies may occur in the motion of the motorized faders. You can use the Calibration function to factory default settings correct these discrepancies. - Page 44 If MOTOR DRIVE is selected: If POSITIONING is selected: For the specified faders in the Channel Strip section and For the specified faders in the Channel Strip section and Master section, the motorized fader movement will be Master section, the fader position will be calibrated. automatically calibrated.
-
Page 45: Troubleshooting
❍ Make sure that the power switches are turned ON. ❍ Make sure that the AC power cords are connected. ➥ If the power still does not turn on, contact your Yamaha dealer. The unit is not receiving an audio input signal. -
Page 46: Specifications (Cs-R10, Cs-R10-S)
Specifications (CS-R10, CS-R10-S) General Specifications At the time of measurement, all faders are set to nominal. Output impedance of the signal generator is 150Ω. Frequency response Fs= 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz @20 Hz–20 kHz, reference to the nominal output level @1 kHz... - Page 47 Crosstalk @1 kHz Fs= 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz from/to to/from Conditions Min. Typ. Max. Unit OMNI IN n OMNI IN (n-1) or (n+1) OMNI IN 1-8 –100 adjacent inputs, GAIN: –6 dB OMNI OUT n OMNI OUT (n-1) or (n+1) OMNI OUT 1-8, input to output –100 * A 22 kHz, 30 dB/octave low pass filter is used to measure crosstalk.
- Page 48 These measurements were obtained when the PHONES A/B LEVEL knobs are set 10 dB lower than the maximum. Connectors are unbalanced. (Tip=LEFT, Ring=RIGHT, Sleeve=GND) 0 dBu=0.775 Vrms for all specifications All DA converters are 24-bit linear. PHONES A,B 1/2 (CS-R10), PHONES A,B (CS-R10-S) Digital I/O characteristics Jack Format...
- Page 49 Dimensions (WxHxD), weight CS-R10: 1549 mm × 417 mm × 848 mm (including the rubber feet), 86 kg CS-R10-S: 1128 mm × 417 mm × 848 mm (including the rubber feet), 67 kg Accessories CS-R10: System Setup Guide, AC power cords ×2, Dust cover, Gooseneck Lamps LA1L ×4 CS-R10-S: System Setup Guide, AC power cords ×2, Dust cover, Gooseneck Lamps LA1L ×3...
-
Page 50: Pin Assignment Table
Pin Assignment Table M2.6 x 0.45 mm pitch LAMP Pin No. Signal Pin No. Signal Pin No. Signal GPO1 GPO2 N.C. GPO3 GPO4 N.C. GPO5 GPO6 GPO7 RLY_NC +12V RLY_C RLY_NO OPTO- OPTO+ GPI1 GPI2 GPI3 GPI4 GPI5 GPI6 GPI7 N.C. -
Page 51: Dimensional Diagrams
Dimensional Diagrams CS-R10 1549 Unit: mm Approximate Munsell value of exterior color: N5 RIVAGE PM10 System Setup Guide... - Page 52 Approximate Munsell value of exterior color: N5 * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. RIVAGE PM10 System Setup Guide...
-
Page 53: Index
Index Calibration..............43 Screen encoder..............23 Channel strip encoder..........23 Shutting down ..............28 Check list............... 42 SILK................16 Console Network ............12 Top panel Channel Strip section ..........23 Front panel ..............25 SCENE MEMORY section ........20 Selected Channel section........15 Touch Screen section..........22 HA (Head Amp) ............ - Page 55 Valletta Road, Mosta MST9010, Malta JAFZA-16, Office 512, P.O.Box 17328, Tel: +356-2133-2093 Jebel Ali FZE, Dubai, UAE Tel: +971-4-801-1500 PA50 Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan (For European Countries) Importer: Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany...
- Page 56 Yamaha Pro Audio global website http://www.yamahaproaudio.com/ Yamaha Downloads http://download.yamaha.com/ Manual Development Group © 2015 Yamaha Corporation Published 06/2017 IPTO-D0 Printed in Japan ZZ29780...
